MICRO COMPONENT SYSTEM
MODEL
XL-S10
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product,
please read this manual carefully. It will guide you in
operating your SHARP product.
XL-S10 Micro Component System consisting of XL-S10
(main unit) and CP-S10 (speaker system).
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Sharp XL-S10
Summary of Contents for Sharp XL-S10
-
Page 1: Micro Component System
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. XL-S10 Micro Component System consisting of XL-S10 (main unit) and CP-S10 (speaker system). -
Page 2: Special Notes
NOTE It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be ob- tained from copyright owners whenever necessary. -
Page 3: Important Safety Instructions
Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug. XL-S10 0304... - Page 4 IMPORTANT SAFETY INSTRUCTIONS XL-S10 Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/...
-
Page 5: Table Of Contents
Specifications ........30 CONSUMER LIMITED WARRANTY ....Back cover XL-S10 Page... -
Page 6: Precautions
Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified. -
Page 7: Controls And Indicators
38. AC Power Cord ........10 XL-S10... -
Page 8: Controls And Indicators
Controls and indicators (continued) XL-S10 1. Full-Range Speaker 2. Speaker Wire 3. Remote Control Transmitter ......11 4. -
Page 9: System Connections
" Do not mistake the right and the left channels. The right speaker is the one on the right side when you face the unit. XL-S10 < Attaching to the wall > Wall Screws (not supplied) Incorrect... -
Page 10: System Connections
System connections (continued) XL-S10 ! Placing the speaker system There is no distinction between the right and the left speakers. Left speaker Notes: " The speakers are magnetically shielded. Therefore, they do not affect the display even if you use them near the TV. -
Page 11: Remote Control
! Test of the remote control Face the remote control directly to the remote sensor on the unit. Press the ON/STAND-BY but- ton. Does the power turn on? Now, you can enjoy the music. XL-S10 Remote sensor 8" - 20' (0.2 m - 6 m) -
Page 12: Sound Control
Sound control XL-S10 ! Adjusting the volume Main unit operation: When the VOLUME control is turned clockwise, the volume will increase. When it is turned counterclockwise, the volume will decrease. Remote control operation: Press the VOLUME + button to increase the volume and the VOL- UME - button to decrease the volume. -
Page 13: Setting The Clock
To change the 12-hour or 24-hour display: 1 Clear all the programmed contents. [Refer to "Clearing all the memory (reset)" on page 28 for details.] 2 Perform "Setting the clock" from the beginning. XL-S10 ) button to ad- ) button to ad-... -
Page 14: Listening To A Cd
Listening to a CD XL-S10 This system can play audio CDs, and CD-R/RW discs but can not record CDs. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording. - Page 15 "End" will appear on the display and CD operation will be paused. When the beginning of the first track is reached during fast reverse, the disc will start playback automatically. button on the main unit or the but- button on the main unit or the but- ) or ) but- XL-S10...
-
Page 16: Repeat Or Random Play
Listening to a CD (continued) XL-S10 " Repeat or Random play You can select one of the CD playback mode; "Repeat play", "Ran- dom play" and "Normal play". When in the CD mode, press the RANDOM/REPEAT button on the remote control repeatedly to select the playback mode. -
Page 17: Programmed Play
! Even if you press the ON/STAND-BY button to enter the stand-by mode or the function is changed from CD to some other function, the programmed selections will not be cleared. ! During program operation, random play is not possible. XL-S10 button to select... -
Page 18: Listening To The Radio
Listening to the radio XL-S10 After use: Press the ON/STAND-BY button to enter the power stand-by mode. Press the ON/STAND-BY button to turn the power on. Press the FUNCTION button until "FM" or "AM" appears on the display. When operating with the remote control, press the TUNER (BAND) button to select "FM"... -
Page 19: Listening To The Memorized Station
) button again when the desired station is located. " To clear a memorized station 1 Recall the memorized station. 2 While it is displayed, press the MEMO- RY/SET (MEMORY) button. 3 Within 5 seconds, press the CLEAR but- ton on the remote control. XL-S10... -
Page 20: Listening To A Cassette Tape
Listening to a cassette tape XL-S10 Before playback: ! For playback, use normal or low-noise tapes for the best sound. (Metal or CrO tapes are not rec- ommended.) ! Do not use C-120 tapes or poor-quality tapes, as they may cause malfunctions. -
Page 21: Recording To A Cassette Tape
! When recording important selections, make a preliminary test to ensure that the desired material is properly recorded. ! SHARP is not liable for damage or loss of your recording arising from malfunction of this unit. ! The volume and sound controls can be adjusted with no effect on the recorded signal (Variable Sound Monitor). - Page 22 Recording to a cassette tape (continued) XL-S10 " Recording from the radio Tune in to the desired station (see page 18). Load a cassette into the cassette compartment with the side to be recorded on facing you. Wind past the leader of the tape, on which recording cannot be performed.
-
Page 23: Timer And Sleep Operation
! " " will light up and the current time will be displayed. To cancel the timer playback: Press the ON/STAND-BY button to turn the power on. Continued to the next page XL-S10 ) button to ) button to... -
Page 24: Timer And Sleep Operation
Timer and sleep operation (continued) XL-S10 When the preset time is reached, playback will start. The volume will increase gradually until it reaches the volume you were listening at before your system enters the timer stand- by mode. The unit will enter the stand-by mode one hour after the timer playback starts. -
Page 25: Enhancing Your System
Press the FUNCTION button until "AUX" appears on the display. When operating with the remote control, press the VIDEO/AUX button. Press the button. Press the button, which also engages the Press the button again to cancel the pause mode. Play the VCR, DVD, etc. XL-S10 button. - Page 26 Enhancing your system (continued) XL-S10 " Subwoofer connection When a commercially available speaker with a built-in amplifier is connected to this unit, you can enjoy sound with emphasized bass. Connect an RCA cord from a commercially available speaker with a Speaker with a built-in amplifier to the SUBWOOFER OUT jack.
-
Page 27: Troubleshooting Chart
Troubleshooting chart Many potential problems can be resolved by the owner without call- ing a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center. " General Symptom Possible cause... -
Page 28: Troubleshooting Chart
Troubleshooting chart (continued) XL-S10 " If trouble occurs When this product is subjected to strong external interference (mechanical shock, excessive static electricity, abnormal supply voltage due to lightning, etc.) or if it is operated incorrectly, it may malfunction. If such a problem occurs, do the following: 1 Set the unit to the stand-by mode and turn the power on again. -
Page 29: Maintenance
CDs can cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a soft, dry cloth, wiping straight out from the center, along the radius. Erase head Recording/Playback head Capstan Pinch roller Correct XL-S10... -
Page 30: Specifications
Specifications XL-S10 As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification fig- ures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 31: Consumer Limited Warranty
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
