Seiko VD 52 B Operation Manual

Stopwatch second hand
(Move in second increments)
Minute hand
Hour hand
Stopwatch minute hand
(Move in minute increments)
* The measured time is indicated by the stopwatch hands that move independently of the center and 24-hour hands.
Before setting the time, check if the Stopwatch second and minute hands are at the "0"(12 o'clock) position.
If the stopwatch is in use, press the button in the following order to reset it, and then, check if the hands return to "0" position.
(For details, see "HOW TO USE THE STOPWATCH")
If the stopwatch is counting: (A)
If the stopwatch is stopped: (B)
If the split time is displayed: (B)
* If either of the stopwatch hands are not at the "0" position, reset them following the procedure below:
Crown
1. Pull out the crown to the
second click.
* Before setting the time, check that the chronograph measurement is stopped.
Crown
2. Turn the crown
1. Pull out the crown to the
first click.
* Do not set the date between 9:00 P.M. and 1:00 A.M.
Otherwise, the day may not change properly. If it is necessary to set the date during that time period, first change the time to any time
outside it, set the date and then reset the correct time.
<<OPERATION -- VD 52 B >>
DISPLAY AND CROWN/BUTTON OPERATION
Second hand
ADJUSTING THE STOPWATCH HAND POSITION
(B)
(A) (B)
Stopwatch
second hand
Stopwatch
minute hand
2. Press button (A) or (B) to reset the stopwatch second and
minute hands to "0" position.
* By pressing button (A), set the stopwatch second hand.
* By pressing button (B), set the stopwatch minute hand.

TIME SETTING

3. Pull out the crown to the second click
clockwise until the
when the second hand is at the
previous day's date
12 o'clock position.
appears.
It will stop on the spot and advance
the hour and minute hands by
turning the crown.
(Check that 24-hour hand is set
correctly.)
* When the crown is at the second
click position. Do not press any
button. Otherwise, the
chronograph hands will move.
24-hour hand
(Indicates the time on a 24-hour basis)
Button (A) *In stopwatch function Start/Stop
Crown at normal position
Second click *Time setting
First click *Date setting
Button (B) *In stopwatch function Split/Split release/Reset
A
B
3. Push the crown back to the normal
position.
4. Push the crown back in to the
normal position in accordance
with a time signal.
VD52-P.1
