Philips MBD3000/93 Service Manual
Hide thumbs Also See for MBD3000/93:

Advertisement

Blue-Ray Disc Player
Contents
.............................................................1-1 to 1-2
2 Laser Beam Safety Precautions................................. 2-1
3 Important Safety Precautions .................................... 3-1 to 3-2
4 Safety Check After Servicing .................................... 4-1
Requirement ...................................... 5-1
7 Direction of Use ........................................................ 7-1 to 7-9
8 Cabinet Disassembly Instructions ............................ 8-1 to 8-2
9
Troubleshooting ..................................................... 9-1
11 Block Diagram ....................................................... 11-1
12 Wiring Diagram ...................................................... 12-1
Circuit Diagram ................................ 13-1
Layout Diagram ............................... 13-1
© Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by LX-KM 1036 AVM
Version 1.1
Page
Printed in the Netherlands
Contents
Circuit Diagram ................................. 13-2
Layout Diagram ................................ 13-3
15 VFD Display Board
Circuit Diagram .................................. 13-4
Layout Diagram ................................. 13-5
16 Decoder Board
Circuit Diagram ................................ 13-6 to 13-17
Layout Diagram ................................13-18
Circuit Diagram ............................... 13-19
Layout Diagram .............................. 13-20
18 Exploded View ...................................................... 14-1
19 Revision List ......................................................... 15-1
VERSION VARIATION
Type /Versions:
/12
Service policy
Board in used:
DISPLAY BOARD
C
C
USB BOARD
HEDAPHONE BOARD
C
M
BLURAY MAIN BOARD
POWER BOARD
M
M
MCU BOARD
Type /Versions:
Features
Feature diffrence
/
12
RDS
VOLTAGE SELECTOR
ECO STANDBY
DTS
* TIPS : C -- Component Lever Repair.
M -- Module Lever Repair
-- Used
Subject to modi cation
MBD3000/12/93
Page
MBD3000
/93
/73
/98
C
C
C
M
M
MBD3000
/93
/73
/98
EN
3141 785 35441

Advertisement

Table of Contents
loading

Summary of Contents for Philips MBD3000/93

  • Page 1: Table Of Contents

    POWER BOARD MCU BOARD Type /Versions: MBD3000 Features Feature diffrence © Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands. √ VOLTAGE SELECTOR All rights reserved. No part of this publication may be reproduced, stored in a ECO STANDBY √...
  • Page 2: Technical Specification And Connection Facilities

    Technical Specification and Connection Facilities 1. Technical Specification and Connection Facilities PCB Locations VFD Display Board Headphone Board USB Board Power Board MCU and AMP Board Decoder Board 1.2 General Coaxial Power supply : 110-240V, 50Hz~60Hz Power consumption : 50W DC Output voltage : <...
  • Page 3 Technical Speci cations and Connection Facilities :USB2.0 Compatibility Type of connector : Series A Connector Class support : UMS(USB Mass Storage Class) File System : FAT12,FAT16,FAT32 HDMI Output Compatibility : HDMI Version 1.4 Type of connector : Type A Connector(19pins) 1.5 Dimension and Weight Set Dimension WxHxD : 277x98x247(mm)
  • Page 4: Laser Beam Safety Precautions

    Laser Beam Safety Precautions This Blu-Ray player uses a pickup that emits a laser beam. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on.
  • Page 5: Important Safety Precautions

    Remove discs from the disc compartment and the wall mount. Koninklijke Philips if you are not using the product for an Electronics N.V. bears no responsibility extended period of time.
  • Page 6 CD supplied with your home theater. For Your product is designed and manufactured a printed copy of the complete user manual, with high quality materials and components, contact Philips Consumer Care in your country. which can be recycled and reused. To access the user manual Caution When this crossed-out wheeled bin symbol The user manual CD is for PC or Mac only.
  • Page 7: Safety Check After Servicing

    Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, and wires have been returned to their original positions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety standards. 1.
  • Page 8: Safety Information General Notes & Lead Free Requirement

    Safety Information, General Notes & Lead Free Requirements Safety Instructions Warnings General Safety General Safety regulations require that during a repair: All ICs and many other semiconductors are susceptible to Connect the unit to the mains via an isolation transformer. electrostatic discharges (ESD, ).
  • Page 9: Standard Notes For Servicing, Lead Free Requirements & Handling Flat Pack Ic

    When soldering, be sure to use the Pb free solder. indicated as shown. Information about lead-free soldering Top View Bottom View Philips CE is producing lead-free sets from 1.1.2005 onwards. Input IDENTIFICATION Regardless of special logo (not always 2. For other ICs, pin 1 and every fifth pin are indicated) indicated as shown.
  • Page 10 2004), containing leaded solder-alloy and components, all needed spare-parts will be available till the end of the service-period. For repair of such sets nothing changes. On our website www.atyourservice.ce.Philips.com you find more information to: Fig. S-1-1 BGA-de-/soldering (+ baking instructions) 2.
  • Page 11 Standard Notes for Servicing, Lead Free Requirements & Handling Flat Pack IC 3. The flat pack-IC on the CBA is affixed with glue, so 4. Release the flat pack-IC from the CBA using be careful not to break or damage the foil of each tweezers.
  • Page 12 Standard Notes for Servicing, Lead Free Requirements & Handling Flat Pack IC 2. Installation Instructions for Handling Semi- 1. Using desoldering braid, remove the solder from conductors the foil of each pin of the flat pack-IC on the CBA Electrostatic breakdown of the semi-conductors may so you can install a replacement flat pack-IC more occur due to a potential difference caused by easily.
  • Page 13: Direction Of Use

    Direction of Use The following excerpt of the DFU/QSG serves as an introduction to the set. The Complete Direction for Use can be download in different languages from the internet site of Philips Customer care Center : www.Support.philips.com Product overview Main unit Disc compartment Headphone socket.
  • Page 14 Direction of Use Remote control Turn on this product or switch to the Eco Power standby mode. When EasyLink is enabled, press and hold for at least three seconds OPEN/CLOSE to turn all connected HDMI CEC compliant devices to standby. TOP MENU MP3 LINK DISC...
  • Page 15 Direction of Use Remote control AUDIO Mute or restore volume. Select an audio language or channel on a disc. VOL +/- Adjust volume. Adjust time. Stop play. Move the paused picture one step Alphanumeric buttons forward. Select an item to play. Enter values.
  • Page 16 Direction of Use 3 Connect Analog stereo system FM antenna USB flash drive Wired/Wireless network Make the following connections to use this product. Note Refer to the type plate at the back or bottom of the product for identification and supply Preparations ratings.
  • Page 17 HDMI button repeatedly to select the best resolution the TV can support. If this product connects to a TV compatible with 1080p or 1080p/24Hz, Philips recommends HDMI category 2 cable, also known as High Speed HDMI cable, for optimal video and audio output.
  • Page 18 Direction of Use Option 2: Connect to the component Option 3: Connect to the composite video jacks video jack AUDIO IN AUDIO IN VIDEO IN VIDEO LINE OUT Pr/Cr ANTENNA Pb/Cb DIGITAL AV OUT COAXIAL COMPONENT Pr/Cr Pb/Cb OPTICAL DIGITAL AUDIO OUT W i - F i COMPONENT LINE...
  • Page 19 Direction of Use Route audio to other devices Connect a coaxial cable (not supplied) to: the COAXIAL jack on this product. the COAXIAL/DIGITAL input jack You can route the audio from this product to on the device. other devices. Connect to optical jack Connect to an HDMI-compliant AV ANTENNA DIGITAL AV OUT...
  • Page 20 Press AUX to select the audio output of software update/BD Live. your connection. Note Internet access to Philips website for software update may not be allowed, depending on Connect FM antenna the router you use or the Internet Service Provider’s policy. Contact your Internet Service Provider for more information.
  • Page 21 Direction of Use Connect the AC power cable to: this product. the wall socket. This product is ready to be set up for use. ANTENNA DIGITAL AV OUT COAXIAL Pr/Cr Pb/Cb OPTICAL COMPONENT DIGITAL AUDIO OUT W i - F i AC ~ LINE S P E A K E R O U T...
  • Page 22: Cabinet Disassembly Instructions

    Cabinet Disassembly Instructions 1. Disassembly Flowchart Note: (1) Identification (location) No. of parts in the figures This flowchart indicates the disassembly steps to gain (2) Name of the part access to item(s) to be serviced. When reassembling, (3) Figure Number for reference follow the steps in reverse order.
  • Page 23 Cabinet Disassembly Instructions Fig. D6 Fig. D3 Fig. D7 Fig. D4 Fig. D8 Fig. D5...
  • Page 24 Cabinet Disassembly Instructions Fig. D9...
  • Page 25: Troubleshooting

    Troubleshooting The ECO power LED isn't bright, Not sound Don’t Loading No picture output Remote control have no function Can not power on Confirm inside Re-Insert Remove stumbling Check the Power Cord Confirm Whether has stumb- Adjust the volume Insert the Disc Confirm output cable the machine Try to conne-...
  • Page 26 Software Upgrading Procedure 1. Download the Software from Philips support Website: http://www.philips.com/support. 2. Copy the Software upgrade file into USB device. A. Connect to TV and Turn on Main Unit, D. When Software Upgrading finish,TV screen display Select Upgrad from USB,TV Screen Display: Press OK on Remote Control, Software Upgrade finish.
  • Page 27: Software Version Check &Upgrad

    Software Version Check 1. Select the “INFO”, like below show: 4. Press BACK on Remote Control: OPEN/CLOSE OPEN/CLOSE TOP MENU MP3 LINK TOP MENU MP3 LINK DISC RADIO DISC RADIO MENU OPTIONS MENU OPTIONS DISC/ DISC/ POP-UP POP-UP BACK INFO BACK INFO TV Screen display:...
  • Page 28: Block Diagram

    Block Diagram Head phone MP3 LINE IN Ethernet Ethernet Headphone AMP TRV412VH5 SMSC8710 RC + 4556 Collimator II TPC1391G4 WIFI DONGLE PWM HL WIFI DONGLE PWM HR DDRII AABBUVWC AUX1 Audio switch U V W COM IIS_A Motor Driver Y U V A+A-B+B- 4052 PCM1808...
  • Page 29: Wiring Diagram

    Wiring Diagram USB Board VFD Display Board Headphone Board 12-1 12-1...
  • Page 30: Usb And Headphone Board

    USB and Headphone Board -- Circuit and Layout Diagram USB Board Headphone Board 3P/2.0 CN502 CN501 4P/2.0 CN401 C502 C501 222 J501 SP-2JCK 13-1 13-1...
  • Page 31: Circuit Diagram

    AMP & MCU Board -- Circuit Diagram P28V +12V TO MCU AMP_PDN CE13 CD11X/100UF16V/D6.3H7 AMP_PROTECT FB/0805/120R +3V3 CD263/1000uF/35V 100K +3V3 R211 R212 100 *12.288MHz +3V3 3904 R213 2K7 TO MCU MSCL C188 MSDA C189 R7 1K DOUT PWM_RST 47uF/25V RFIN C139 C140 0.47uF...
  • Page 32: Amp And Mcu Board

    AMP and MCU Board -- Layout Diagram 13-3 13-3...
  • Page 33: Circuit Diagram

    VFD Display Board -- Circuit Diagram R306 DCM713D-1.GB VFD301 2.2R 1/2W R323 10K 1/8W R305 2.2R 1/2W C309 104p S301 R324 10K 1/8W REMOTE L305 200UH R321 47 C311 C312 104p 47uf/16v T902 DZ301 3V R379 Q301 CN302 S12/KS12 C301 D965 2P/2.0 S11/KS11...
  • Page 34: Layout Diagram

    VFD Display Board -- Layout Diagram 13-5 13-5...
  • Page 35: Circuit Diagram

    Decoder Board -- Circuit Diagram 1 PWR1 AP1538/SOP-8 CON8P-2.5 VCC_P 1.1V 5V_VCC FB51 FB/0805/600R VCC_P SOP8/SMD -12V_IN -12V FB52 FB/0805/600R L9 TC5026B#470M-U0-B-47uH-3A FB1 FB/0805 +12V_IN 1.1V_FB +12VA 0904 FB 100R DIP FB54 FB/0805/33R/2A FB3 FB/0805 -12V FB53 FB/0805/33R/2A 4.7K NS/100nF NS/100nF 909R-1% +5V_IN...
  • Page 36 Decoder Board -- Circuit Diagram 2 1.8V A_DQ13 A_RA0 A_DQ16 A_RA0 A_DQ9 A_RA1 A_DQ22 A_RA1 1.8V A_DQ8 A_RA2 A_DQ21 A_RA2 A_DQ11 A_RA3 A_DQ19 A_RA3 C101 C102 C103 C104 C105 C106 C107 A_DQ14 A_RA4 A_DQ20 A_RA4 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V A_DQ10...
  • Page 37 Decoder Board -- Circuit Diagram 3 B_DQ0 B_RA0 B_DQ18 B_RA0 B_DQ4 B_RA1 B_DQ20 B_RA1 B_DQ2 B_RA2 B_DQ23 B_RA2 B_DQ1 B_RA3 B_DQ19 B_RA3 B_DQ6 B_RA4 B_DQ17 B_RA4 1.8V B_DQ7 B_RA5 B_DQ16 B_RA5 B_DQ0 B_DQ3 B_RA6 B_DQ22 B_RA6 AR39 DVSS B_DQ0 B_DQ1 B_DQ5 B_RA7 B_DQ21...
  • Page 38 Decoder Board -- Circuit Diagram 4 1.2V U100C FB300 0ohm MT8530_DDR2 AVDD12_APLL D300 C301 C302 0.1uF RClamp0524P 3.3V TX2+ F_TX2+ TX2- AVDD33_VDACR AOMCLK_R F_TX2- FB301 0ohm AVDD33_VDACY AVDD33_VDACR AOMCLK AOBCK_R F_TX1+ AVSS33_VDACR AOBCK AOLRCK_R AOLRCK AVDD33_VDACY AOSDATA0_R F_TX1- C303 C304 AVDD33_VDACY AOSDATA0 TP306...
  • Page 39 Decoder Board -- Circuit Diagram 5 3.3V 1.2V U351 SFCS AVDD12_STX1 FB350 0ohm SFCS AVDD12_STX1 SFCK AVDD12_SRX1 FB351 0ohm NAND08GW3B2A SFCK SFCK AVDD12_SRX1 TP95 SFDI AVSS12_ST1 TP96 SFDO C354 C353 USBP0 USBP0 0.1uF 0.1uF SATA_RXP1_C SVCTST TP353 SRXP_1 NFALE SATA_RXN1_C SFCS USBM0 USBM0...
  • Page 40 Decoder Board -- Circuit Diagram 6 3.3V 3.3V VCC3IO_STB ETTXD1 FB358 0ohm VCC3IO_S ETCOL ETTXD0 ETCOL R390 VCC3IO_STB ETCOL R389 ETCRS VCC3IO_STB ETCRS ETCRS NC/10K NC/10K ETMDC 3.3V_VCC ETMDC ETMDC ETMDIO ETMDIO ETMDIO NFCEN2 FESFDI ETRXCLK ETRXCLK ETRXCLK AVDD33_LDO ETRXD0 ETRXD0 AVDD33_LDO ETRXD0...
  • Page 41 Decoder Board -- Circuit Diagram 7 1.1V VCC3IO 1.1V VOUTVSYNC VCCK VOUTVSYNC VOUTHSYNC AB20 VCCK VOUTHSYNC AD20 VCCK VOUTCLK1 AF20 TP369 VCCK VOUTCLK1 VOUTCLK2 AH20 VCCK VOUTCLK2 C395 C396 C397 AK20 VCCK 0.1uF 0.1uF 10uF/6.3V VCCK VOUT0 AL21 VCCK VOUTD0 TP371 VOUT1 AB22...
  • Page 42 Decoder Board -- Circuit Diagram 8 R451 150 COAXOUT +5VV FB452 C451 0.1uF/16V FB500/0603 FB450 FB/0805 RCA JACK_1 C1053 R450 TP92 10uF/10V C452 0805-C 10pF COAXOUT TP93 ASPDIF_OUT TP94 VCC_SPDIF VCC_SPDIF ASPDIF ASPDIF_OUT ASPDIF R452 33 LOUT5 C454 0.1uF/16V CE450 ROUT5 10uF/16V L451 1.8uH...
  • Page 43 Decoder Board -- Circuit Diagram 9 3.3V CB24 102/1uF R145 R145 PCM1789 R144 NC/10K R131 R131 +5V_DAC AOLRCK_R R133 LRCK ADR5/ADR1/RSV 78L05 R134 AOBCK_R MS/ADR0/RSV 100R 120 OHM +12VA R136 R139 NC/0 AOSDATA4 MC/SCL/FMT R147 R140 NC/0 DAC_RST# MD/SDA/DEMP 100R CE16 R142 R143 0/22K...
  • Page 44 Decoder Board -- Circuit Diagram 10 LAN_VDDA LAN-3.3V LAN-3.3V LAN_VDDA R1294 R1294 FB700 FB/0603 0805-R 0805-R C702 C704 C705 C703 0.1uF C701 10uF 0.1uF/16V 0.1uF PWFBOUT1 0.1uF 3.3V R1404 R1405 PWFBOUT2 1,2,4,5,6,7,11 3.3V R707 49.9 49.9 LAN_VDDA 1.5K C595 C595 0.022uF/50V 0.022uF/50V TP_RX-...
  • Page 45 Decoder Board -- Circuit Diagram 11 5V_VCC 1,4,9 5V_VCC LGO1N TRINA FE_SFCS# USFCS# A3.3V TP30 TP37 LGO2N TRINB USFCS# A1.2V TP31 TP38 LGO3P TRINC 5V_VCC TP32 TP39 AVCC LGO3N TRIND FE_SFDO USFDO A3.3V TP40 F_C14 0.1uF TP33 LGO4P FOIP USFDO TP41 TP34 F_R128...
  • Page 46 Decoder Board -- Circuit Diagram 12 AVCC FOC2+ F_FB1 0 FOC2- AVCC FOC1+ MVCC F_R96 MVCC V14REF F_R97 F_R98 F_FB2 0 F_CE12 V14REF F_R99 F_R100 10K FOC1- 100uF/16V FOC1- F_C62 F_R101 10K + F_CE11 FOC1+ +12V FOC1+ 0.1uF F_R102 10K FOC2- 220uF/16V FOC2-...
  • Page 47 Decoder Board -- layout Diagram 13-18 13-18...
  • Page 48: Power Board

    Power Board -- Circuit Diagram 1KR 0805 4.7KR 0805 SS8050 FR107 2.2KR 0805 4800 103/630V SS8550 BAND FR107 1040 3UH 3*15 68K/1W 1N4148 33R 1206 821/1206 100R 1206 1KR 1206 15R 0805 FR107 LD7535 10KR 1206 104/0805 FR107 EL817 TL431A EL817 0R 1206 22KR 1206...
  • Page 49: Layout Diagram

    Power Board -- Layout Diagram 13-20 13-20...
  • Page 50: Exploded View

    Exploded View PCB1 PCB2 PCB3 14-1 14-1...
  • Page 51: Revision List

    Revision List Revision List Version 1.0 * Initial Release 15-1...
