- Page 1 Spinner® Chrono Console User Guide...
-
Page 2: Spinner® Chrono™ Power Console
SPINNER® CHRONO™ POWER CONSOLE Operator's Guide The Spinner® Chrono™ Power console displays power level, interval tracking, simultaneous current and average data for workout and summary, and lets you pair your smartphone to Bluetooth® applications. IMPORTANT Important Before using the equipment, read all documentation included with your console and bike Attach the console to the bike To attach the console: 1. -
Page 3: Activate The Console
Setup/Service mode Use the console Setup/Service mode to configure settings in ways that benefit exercisers. NOTE The information provided in this section is intended for system administrators and Precor service technicians. DO NOT share it with exercisers or non-administrative staff. Button... -
Page 4: Modify The Club Parameter Settings
Modify the Club Parameter settings Use Club Parameter settings to choose the type of information you want exercisers to see on the console while working out. Setting Description Setting options (default in bold) UNITS Speed and distance measurements MPH, KPH BACKLIGHT Three is the brightest setting 3, 1, 2... -
Page 5: Informational Settings
Informational Settings The Information Settings contain the information required when you contact Precor Customer Support including serial numbers, software program versions, odometer and error log summary, and model numbers. NOTE It is possible to record system information and the error log on a properly formatted USB stick. -
Page 6: Service Tests
Service Tests Perform tests to help you troubleshoot systems including torque, WATTS, RPM, battery and generator voltage and amps, and display elements. Press the white button to move from one test to the next. Setting Description DISP TEST Tests the display to make sure all elements are working. Select YES to test the display. No is the default. BAT VOLT Battery voltage: While you pedal or if you have an external charger installed, the voltage will appear high because the battery is charging. -
Page 7: Connect To Other Devices
Connect to other devices Use the following information to connect ANT+™ and Bluetooth® compatible devices to the console. ANT+™ Heartrate display • User heartrate detection is only available with ANT+ compatible sensors displaying the ANT+™ icon. • The console detects the closest sensor and displays the 4-digit ID number. - Page 8 CHRONO_Console_Troubleshooting Error Information Error Possible causes displays? error change? log? Serious You cannot use the Error • Connected to wrong lower error console number • Communication error Minor Console continues RPM sensor stops working or strain error to function gauge fails causing WATT inaccuracy, but a functioning console.
-
Page 9: Console Care
Important DO NOT use any acidic cleaners to clean the console. Doing so will weaken paint, powder coatings, and other surface finishes and will void the Precor Limited Warranty. Never pour water or spray liquids directly onto the screen Precor strongly recommends performing the following maintenance after each use: •... -
Page 10: Trademark Notice
TRADEMARK NOTICE Precor is a registered trademark of Precor Incorporated. Other names in this document and all documents included in this purchase may be the trademarks or registered trademarks of their respective owners. The Spinner Family of Marks—Spin®, Spinner®, Spinning®, Spin Fitness®, and the Spinning logo ® are registered trademarks owned by Mad Dogg Athletics, Inc., a California corporation.
