PARTS LIST

REF NO.
IR INPUT 1 ASSEMBLY
1200
METAL MATERIALS
1201
1202
1203
1204
1206
PCB BOARD
1205
WAFER
J501A
JACKS
M501
M502
M503
IR INPUT 2 ASSEMBLY
1300
METAL MATERIALS
1301
1302
1303
1304
1306
PCB BOARD
1305
CAPACITORS
C5101
C5102
WAFER
J502A
JACKS
M506
M507
M508
M510
M511
M512
ICs
U5101, U5102
REGULATOR ASSEMBLY
2300
PCB BOARD
2301
ICs
U111
U115
REPEATER ASSEMBLY
1600
PCB BOARD
1601
DESCRIPTION
IR INPUT 1 ASSEMBLY
L-BRACKET
3X6MM B-TITE (BLK.ZN)
SCREW M3X10 (BLK)
M3 NUT
ME 2*8 4.0MM BK/RH JHC023-00
PCB RM2/RM3/TUNER/MISC. A0190C
6P ST. WAFER P=2.5 COULOMB
DIN 5P 180DEG SOCKET
PHONE JACK D3.5 BK JY-3537-01-140
4P TERMINAL BLOCK
IR INPUT 2 ASSEMBLY
L-BRACKET
3X6MM B-TITE (BLK.ZN)
SCREW M3X10 (BLK)
M3 NUT
ME 2*8 4.0MM BK/RH JHC023-00
PCB RM2/RM3/TUNER/MISC. A0190C
CE 16V 10µF 20% RL 4x7
CE 16V 10µF 20% RL 4x7
WAFER 10P P2.5 ST. COULOMB
DIN 5P 180DEG SOCKET
PHONE JACK D3.5 BK JY-3537-01-140
4P TERMINAL BLOCK
DIN 5P 180DEG SOCKET
PHONE JACK D3.5 BK JY-3537-01-140
4P TERMINAL BLOCK
IC NJM78L05A 826
REGULATOR ASSEMBLY
PCB RM2/RM3/TUNER/MISC. A0190C
IC 7812H 12V REG, T0220F
IC 7805 REG 5V 1.5A
REPEATER ASSEMBLY
PCB RM2/RM3/TUNER/MISC. A0190C
4
GTP-506
PART NO.
PCB-A0190C-IR1
4152-0451-0
2954-3006-3000
2904-3010-3000
2640-3022-0540
2954-2008-3000
1724-660A-0001
2102-061S-004
2113-1682-0
2113-1179-0
2113-1668-0
PCB-A0190C-IR2
4152-0451-0
2954-3006-3000
2904-3010-3000
2640-3022-0540
2954-2008-3000
1724-660A-0001
157D-106M-5-GM
157D-106M-5-GM
2102-101S-004
2113-1682-0
2113-1179-0
2113-1668-0
2113-1682-0
2113-1179-0
2113-1668-0
3130-0640-0
PCB-A0190C-REG
1724-660A-0001
3130-2520-2
3130-2020-3
PCB-A0190C-REP
1724-660A-0001
