- Page 1 WHIRLPOOL OF INDIA LTD Service Manual Top Mount No Frost Refrigerator...
-
Page 2: Table Of Contents
INDEX Sno. Detail Page No. MODEL RANGE SAFETY PRECAUTIONS FEATURE/ TECHNICAL SPECIFICATION ELECTRONIC CONFIGURATION AND TROUBLESHOOTING 7 ELECTRONIC CONFIGURATION COOLING CONTROL SAFE MODE ROUTINE BOARD LEVEL DIAGNOSTIC WIRING DIAGRAM EXPLODED VIEWS SERVICE PART LIST... -
Page 3: Model Range
NO FROST REFRIGERATOR MODEL RANGE: 290L SUSLITE – WIE105 USS... -
Page 6: Feature/ Technical Specification
TECHNICAL /FEATURE SPECIFICATION: MODEL 290L Type Frost free Capacities (L) total net 290L Product Dimensions (mm) Width Height 1714 Depth Gross Weight (kg) 70Kg Voltage / Hz 220-240V/60Hz Compressor ASD65 Oil Capacity 180 cu.cm Comp. Run Capacitor PTC Relay QP2-15G... -
Page 7: Electronic Configuration And Troubleshooting
Electronic Configuration, Logic & Troubleshooting GENX Controls & Electronics Configuration Product Configuration 290L Product Control RC Controlled Software User interface Auto cool mode Quick Chill/Fast Forward Ice Auto Power save mode Door Alarm RC Illumination Yes(Lamp) Control Board Defrost heater... - Page 8 CONTROLS & ELECTRONICS CONFIGURATION: Top Mount: Deluxe models: This refrigerator is managed by an Electronic System, mainly consisting of the components: • Electronic Control Board (Hercules- Dlx (BEE)) • POT (Potentiometer) in case of Dlx (BEE) models only. • Temperature Sensors {refrigerator, Defrost} •...
- Page 9 The Electronic Control is located at the rear of the refrigerator, next to the cabinet and besides the Compressor, inside a plastic box. Cables going inside the product, using connectors that do not permit an assembling failure do its connection to the mains and its components. Note: For more details see wiring Diagram.
- Page 10 Identification of connectors: Connector 3 Connector 2 Connector 1 CN1 (Connector 1)(6 pin MLX) – Compressor, Heater and Power Cord CN2 (Connector 2)(8 pin minifit) – Temperature Sensors/POT CN3 (Connector 3)(6 pin minifit) – RC/FC LED WARNING Electrostatic Discharge Risk Do not touch the Circuit components, because you can damage fuse/burned or weaken the board.
- Page 11 Disassembly Procedure of coreboard box: Disconnect the Power cord from the Mains supply. Remove the Mounting Screws and connectors. Mounting screws IMPORTANT Be careful when using the Multimeter measuring probes, as they may damage the Connector terminals.
-
Page 12: Cooling Control
Cooling control: Adaptive Defrost Control The defrost cycle shall be started after the Defrost timer has expired. According to the following defrost procedure: Defrost must be executed every time one of the following event occurs: 1. After 8 hours (+/-10 minutes) of compressor running, calculated considering just the thermostat function. 2. -
Page 13: Safe Mode Routine
Safe mode routine During Constant fault condition, the Electronic Control will assume a safety routine, as in normal cycle, trying to keep food conservation, however will work as follows: • Compressor and Fan Motors will be on for 25 minutes and then will turn off for 20 minutes. •... -
Page 14: Board Level Diagnostic
Board Level Diagnostics for : Thermistor Failure FC/RC Potentiometer Failure First Turn Off the Product & disconnect the Plug. Remove the 3 connectors of Control Board. For Thermistor Failure FC/RC Check resistance on pin no. 4 & 8 of CN2 (8 pin connector) for RC Thermistor. Check resistance on pin no. -
Page 15: Wiring Diagram
WIRING DIAGRAM:... -
Page 16: Exploded Views
EXPLODED VIEWS:... - Page 19 70 W10483536 HERCULES 2 ASSEMBLY FOR L60 & GEN-X II 1 EA...
-
Page 20: Service Part List
SERVICE PART LIST: PART NO. DESCRIPTION W10415631 OIL CHARGED COMPRESSOR ASSEMBLY ASD65 1 EA W10533545 FC FOAMED DOOR REAL STEEL ELT GENX-2 1 EA W10530157 GASKET SUB-ASSY FC GENX 1 EA W10533940 305L RC FOAMED DOOR REAL STEEL GENX-2 1 EA W10473472 PUSH IN GASKET (B) - RC 292L GENX 1 EA... - Page 21 W10426650 CENTRE HINGE ASSY, L60T 1 EA W10558889 Freezer Damper Control GENX- AUS MAROON 1 EA W10444347 Hinge top sub assy - ELT, L60T 1 EA A2240510000 EGG TRAY - ONYX 1 EA W10463830 FAN MOTOR BRACKET 1 EA W10461849 Cover Hinge Top Elite NEO/L60 1 EA W10536372...
