Instruction manual INNOVA
1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
The „INNOVA" display case is a universal cooling device for displaying and storage of short-term confectionery: tarts, ca-
kes, biscuits, desserts, etc. at temperatures between +2°C / +15°C with ambient temperature +16°C / +25°C and relative
air humidity of up to 60%.
2.2. Description of the device
„INNOVA" is equipped in dynamic cooling, automatic condensation evaporation and defrosting. The display case is also
equipped with an electronic thermostat, which works optionally with the temperature registration module that enables
registration and signalling high and low temperatures in the unit. Display cases are adapted to connect in sequences and
can be powered by an internal unit within the temperature range of +2°C / +15°C. It is possible to control the humidity
of the display case ranging from 40 to 90%. The exhibition part of the display case are glass shelves placed on a rack.
The exposition shelves are able to change the position and angle of suspension. The glass elements are made of insu-
lating glass filled with argon and black silk-screen printing. The „INNOVA" display cases use energy-saving LED back
lighting. „IGLOO" Units are made in accordance with modern technology and possess the certificates required by law.
Contents
1. UNLOADING
2. PROPERTIES OF THE DEVICE
2.1. Purpose
2.2. Description of the device
This sign signifies information of particular meaning for user security and for proper device
exploitation.
www.igloo.pl
List of Figures
13
Fig.1 Section of the device
13
Fig.2 Control panel
13
13
15
Fig.6 Cleaning the condenser
16
16
16
16
17
17
17
17
19
19
20
List of tables
20
20
21
en
en
14
14
15
17
18
19
20
21
User manual INNOVA
2
13
Advertisement
Table of Contents
Related Manuals for Igloo INNOVA series
Summary of Contents for Igloo INNOVA series
-
Page 1: Table Of Contents
The exposition shelves are able to change the position and angle of suspension. The glass elements are made of insu- lating glass filled with argon and black silk-screen printing. The „INNOVA” display cases use energy-saving LED back lighting. „IGLOO” Units are made in accordance with modern technology and possess the certificates required by law. Contents List of Figures 1. - Page 2 Rys.2 Control panel 1 – Main switch (switches on / off the unit) 2 – Light switch 3 – Electromagnetic lock the front glass extension 4 – Thermostat panel (temperature controller) (the details of operating in Chapter 7 User manual INNOVA www.igloo.pl...
-
Page 3: Technical Data
Rated voltage Rated lighting Max shelf load Usable surface consumption [m2] „INNOVA” [V/Hz] power [W] [kg/mb] [kWh/24h] INN70.110 230/50 26,4 INN100.110 230/50 34,2 INN140.110 230/50 42,9 10,8 INN70.140 230/50 INN100.140 230/50 40,2 INN140.140 230/50 49,5 11,1 www.igloo.pl User manual INNOVA... -
Page 4: Preparing The Device For Exploitation
(condensate) during defrosting. • After transporting the device, wait about 2 hours before its actuation. • In order to ensure proper conditions for the stored products, do not load the shelves completely. It is neces- User manual INNOVA www.igloo.pl... -
Page 5: Temperature Regulation
• Make sure whether the front panel is properly closed and whether it fits tight to the body of the device. 4.1. Temperature regulation Service of “Igloo” and “Carel” thermostat (temperature regulators) is described in chapter 7 (p. 20 and 21) The basic aim of a thermostat is to control the cooling aggregate to obtain the set temperature within the device and maintain it within the determined temperature ranges. - Page 6 (also includes various stainless steel) During maintenance services it is necessary to pay attention not to damage the data place of the device Fig.13 (p.10), which contains significant information for servicing organs and waste removal companies. User manual INNOVA www.igloo.pl...
-
Page 7: Service
The main switch is turned on • Thermostat is turned on (This concerns the Igloo thermostat – If only two spots are visible on the display – turn on the thermostat) The device is operating, but the lighting is off...– Make sure that: •... -
Page 8: Service
If after checking points described in chapter 6.1 “Fault identification and repair” the device still does not work properly, please contact Technical Service of the Igloo company, stating the data from the data plate Fig.13 (p.10) • Serial number (NS) •... -
Page 9: Temperature Regulation
The above figure shows a demonstrative data plate and the data stated on the plate are exemplary data, which are not related with INNOVA device! 7. THERMOSTAT SERVICE 7.1. „IGLOO” thermostat Fig.13 „Igloo” thermostat control panel 1 – Cooling on/off switch 2 – Manual defrosting switch 3 – Aggregate and defrosting operating control diode 4 –... -
Page 10: Carel" Thermostat
DED IN THIS MANUAL, THE PRODUCER SHALL RESERVE THE RIGHT TO RECEDE FROM OBLIGATIONS OF THE GUARANTOR!!! Information included in this document may be altered by “IGLOO” without noticing the user. Copying the present manual without the consent of the producer is forbidden. - Page 11 Correspondence: Stary Wiśnicz 289, 32-720 Nowy Wiśnicz Poland NIP: 868-000-50-40 Tel.: +48 14/662 19 10, fax: +48 14/662 19 12, e-mail: info@igloo.pl www.igloo.pl www.igloo.pl User manual INNOVA...
