Senco FramePro 700XL Specification Sheet

The New FramePro 700XL is designed with the Pro in mind. The
®
"X-tended Life" FramePro has all the great features of the original
FramePro 600, with improved durability and reliability. These
compact framers are easy to handle, and easy on the arm. The 30˚
short, in-line magazine, provides excellent maneuverability and
line of sight. These powerful framers drive a wide range of fasten-
ers in 4 gauges (.113 – .148) from 2" to 3
any job. And a two year warranty provides "X-Tended" Protection.
Applications:
For framing, truss building, subflooring, sheathing, decking, sid-
ing, fencing, pallets and crate assembly.
.
Features and Benefits:
• Two full year warranty
• Improved internal design for "X-tended Life"
• New guidebody/drives for a truer driver
• Improved comfort grip handle reduces vibration and fatigue
• Aggressive sawtooth safety that really digs in for toenailing
• Drives ring, screw and smooth shank nails in 4 gauges
(.113 –.148) from 2" to 3 1 ⁄ "
2
• Straight-line 30˚ magazine for better line of sight and
maneuverability
• Adjustable exhaust
• Depth-of-drive control and EZ Clear
For additional information on how Senco fastening systems will save
you time, reduce costs and increase quality, call your nearest Authorized
Senco Dealer or Distributor listed in the Yellow Pages under "Staples," or
call our toll-free Action Line: 1-800-543-4596.
©2000 Senco Products, Inc. Order MK464
FramePro
1 ⁄ " to handle virtually
2
Litho in U.S.A.
700XL Nailer
®
Tool Specifications:
Weight: 8.0 pounds (3.6 kg)
Height: 13 ⁄ " (336.55 mm)
1
4
Length: 15" (381 mm)
Width:
Nail Capacity: 56-80, depending on gauge
Reg. Operating Pressure: 70-120 psig
Mode of Operation: Available with either Restrictive Trigger or
Dual Action activating mechanisms.
Fastener Specifications:
FramePro 700XL nailers drive 2" to 3
(Sencote or plain); 2" to 3" ring-shank nails; 3" screw-shank and
®
clipped "D" head nails. Shank diameters include .113", .120",
.131" and .148"
HF
GE HE
GC HC KC MC
* "Restrictive Trigger" activated tools are used for applications where precision nail or staple
placement is desired. You must first depress the safety element where you want to drive a
nail or staple and then pull the trigger. After each nail or staple is driven, completely release
the trigger and lift the tool off the work surface.
"Dual Action" activated tools are used for applications where high-production work is
desired. There are two modes of operation.
Bottom Fire Method: This method of operation is sometimes called bounce firing. You
must keep the trigger pulled while moving the tool along the work surface with a bouncing
motion, depressing the safety element where you want to drive a nail or staple.
Trigger Fire Method:first depress the safety element where you want to drive a nail or
staple and then pull the trigger.
For instructions on safe use of tools, please refer to the Operating Instructions or
Customer Satisfaction and Safety Reminder contained in your tool carton.
www.senco.com
®
1 ⁄ " smooth shank nails
2
3
⁄
2
3
8
1 ⁄ 1 ⁄
2 2 2
4 2
1 ⁄ 1 ⁄
3 3
4 2
®
Safety First. The only way to work.
