AT&T Business in a Box®

Quick Start Guide

Please ensure that you have set-up the equipment before the date scheduled
with your AT&T Order Manager for Test and Turn Up of your service
© 2014 AT&T Intellectual Property. All rights reserved. AT&T, Globe logo and other marks are trademarks of AT&T Intellectual Property.

Advertisement

loading

Related Manuals for AT&T Business in a Box

Summary of Contents for AT&T Business in a Box

  • Page 1: Quick Start Guide

    AT&T Business in a Box® Quick Start Guide Please ensure that you have set-up the equipment before the date scheduled with your AT&T Order Manager for Test and Turn Up of your service © 2014 AT&T Intellectual Property. All rights reserved. AT&T, Globe logo and other marks are trademarks of AT&T Intellectual Property.

  • Page 2: What's In The Box

    If required, up to three 8 Port Analog Telephone Adapter(s) (ATA) will be included in your router package. Each device will provide 8 additional analog ports to connect to your phone system. AT&T Business in a Box® ATA Add-On Additional Components: •...
  • Page 3 If required, up to three 8 Port POE switch(s) will be included in your router package. Each device will be used to provide 8 additional Ethernet switch ports for your PC’s, Printers, Servers, etc. AT&T Business in a Box® 8 Port POE Add-On Additional Components: •...
  • Page 4 If required, up to three 24 Port POE switch(s) will be included in your router package. Each device will be used to provide 24 additional Ethernet switch ports for your PC’s, Printers, Servers, etc. AT&T Business in a Box® 24 Port POE Add-On Additional Components: •...
  • Page 5 Understanding your AT&T Business in a Box® Equipment AT&T Business in a Box® 12 or 24 Port Base Unit Router (24 port depicted) is always included in your initial shipment. Add-on devices will connect directly to the Ethernet Ports. Instructions will be provided in the shipping box as to which Add-on device will connect to which Ethernet port.

  • Page 6: Step 1 - Wall Mounting Instructions

    Step 1 – Wall Mounting Instructions (optional to Rack Mounting) The AT&T Business in a Box® Add-On’s may be wall mounted on a ¾” or thicker plywood backing. Use the two (2) rack-mount brackets, eight (8) bracket screws (included) and four (4) 1 ½”...
  • Page 7 Step 2 - Attach Power Cord to the Add-on (ATA Depicted)* Plug in power cord to the Add-on device * Note: Each of the three Add- on types will require external power. This example is for the To power strip, ATA Add-on device.
  • Page 8 Step 3 - Connect the Add-on to the Base Unit (ATA Depicted)* Connect the Add-on device to the Base Unit using the provided cable. Instructions will be provided as to which Add-on device will connect to which Ethernet port on the Base Unit Router. Interconnect Included Orange cable to orange ports * Note: The same...
  • Page 9 Step 4 - Connect Your device(s) to the Add-on’s Connect your Key System or Ethernet devices using customer provided cables to the Add-on Devices Connect your analog Connect your Ethernet phones/Key System to the devices to the Ethernet green ports on the right switch ports on the left using RJ11 cables using RJ45 cables.
