ENFORCER
Relay Module
SR-2224-C5
Features:
Two separate sets of Form-C dry contacts.
Perfect for a variety of general switching purposes.
Can be connected for load switching, dry contact, latching
output, reverse polarity, line seizure, and other uses.
6/12/24 VDC operation, programmable by on-board
jumpers.
Red LED indicates relay is energized.
Large terminal blocks for easy installation.
Small size, easily fits inside alarm panel enclosures
or other hidden areas.
Foam mounting tape included.
Specifications:
SR-2224-C5
+/- 20% of operating voltage
ENFORCER
Power Supplies
Four Models to Choose From
Model #
Current
Voltage (DC)
ST-1206-1.5A
6,12
1.5A
ST-2406-2A
6,12,24
1.5A
ST-2406-3A
6,12,24
2.5A
ST-2406-5A
4.0A
6,12,24
®
SECO-LARM
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
®
Current (peak)
2.0A
2.0A
3.0A
5.0A
®
Connection Diagram
JP1 ON ON OFF
JP2 ON OFF OFF
ENFORCER
Timer Modules
SA-025
7
1
8
2
6V 12V 24V
Preset 12V
®
Power input
12/24VDC (auto sensing).
Current drain
Relay type
Form-C relay
Contact ratings
8A @ 120VAC/24VDC.
Low
