Page 1: Installation Instructions
QTM-DC Power Supply (DC and DC+CAP) Installation Instructions Must be installed by licensed electrician. - Page 2 NOTE: Primary Input - connect the 120V hot into block labeled Hot. Connect the neutral wire into Tap 1 - Tap 5 depending on desired output Voltage.(Not to exceed 12V or 24V) " 0 QTM-DC/DC+CAP Model Input Voltage Input Current Frequency Nominal Output Nominal Output Voltage (VDC) Wattage (W) WIRE CONNECTION QTM60 120 / 277 0.67 / 0.29 50/60 12/24 Yellow QTM100 120 / 277 1.1 / 0.49 50/60 12/24 QTM120 120 / 277 1.3 / 0.58...
- Page 3 NOTE: Primary Input - connect the 120V hot into block labeled Hot. Connect the neutral wire into Tap 1 - Tap 5 depending on desired output Voltage.(Not to exceed 12V or 24V) " 0 QTM-DC/DC+CAP Model Input Voltage Input Current Frequency Nominal Output Nominal Output Voltage (VDC) Wattage (W) WIRE CONNECTION QTM60 120 / 277 0.67 / 0.29 50/60 12/24 Yellow QTM100 120 / 277 1.1 / 0.49 50/60 12/24 QTM120 120 / 277 1.3 / 0.58...
- Page 4 Installation Instructions QTM-DC & DC+CAP Housing Mounting This face of bracket mounts to: Wall Surface Wall Surface Stacking Surface Spacing Note: Surface Mounting can be done on six different planes. 16” O.C. PRIMARY Minimum ” O.C. More units Minimum can be stacked More units can be spaced 9“...
