Summary of Contents for AT&T Osprey
- Page 1 User Manual—Streaming Device and Remote Control Streaming Device and Remote Control User Manual Version 1.0 11/2018...
- Page 2 User Manual—Streaming Device and Remote Control Introduction Product manuals are intended to help customers understand the workings of the hardware devices. This product manual provides overview information of the streaming device and remote control and addresses specific functions of the devices. It is posted online at att.com/userguides for customer access. For information on setting up and operating your equipment, the following URLs may be helpful: att.com/atttvsetup att.com/atttvremote...
-
Page 3: Table Of Contents
User Manual—Streaming Device and Remote Control TABLE OF CONTENTS I. OVERVIEW ........................... 05 II. HARDWARE INFORMATION .....................06 A. Specifications..........................................06 B. Client Hardware........................................07 1. Front Panel ..........................................07 2. Side Panel ..........................................07 3. Rear Panel ..........................................07 C. Other Associated Hardware ..................................08 1. - Page 4 User Manual—Streaming Device and Remote Control Terminology Term Description DIRECTV Home Network High Value Content e.g., in-theater PPV movies Over-the-Top, the delivery of video via the Internet directly into user-connected devices, allowing access to services anywhere, anytime and on any device Picture-in-Picture RF4CE Radio frequency for consumer electronics...
-
Page 5: Overview
User Manual—Streaming Device and Remote Control I. OVERVIEW The streaming device is a game-changing, proprietary "Over-the-Top" (OTT) streaming device that delivers video and integrated content to your TV over the internet. It enables you to watch DIRECTV NOW and online videos, listen to music, use thousands of third-party apps (such as Netflix or Instagram ) and play ®... -
Page 6: Hardware Information
User Manual—Streaming Device and Remote Control II. HARDWARE INFORMATION A. Specifications Streaming Device Specifications Size and Weight (not including feet) Power • Height: 19 mm • EPS10 External PSU • Width: 158.6 mm • AC External PSU -120v~60 HZ, 18W •... -
Page 7: Client Hardware
User Manual—Streaming Device and Remote Control B. Client Hardware 1. Front Panel • Blue Power Status Indicator LED • Green / Yellow / Red Network Status Indicator FIGURE 1: STREAMING DEVICE—FRONT PANEL 2. Side Panel • Red Reset Button FIGURE 2: STREAMING DEVICE—SIDE PANEL 3. -
Page 8: Other Associated Hardware
User Manual—Streaming Device and Remote Control C. Other Associated Hardware 1. Mounting Cables The streaming device (C71KW) can be set on a tabletop or mounted to a wall by attaching a cable tie to the recess in the bottom cover. 2. -
Page 9: Figure 5: Remote Control Showing Button With Descriptions
User Manual—Streaming Device and Remote Control MIC / STATUS LED Turns both streaming device and TV ON Turns both streaming device and TV at the same time OFF at the same time INPUT INPUT Cycle through and select the equipment connected to your TV MUTE VOL + / VOL - MUTE the sound... -
Page 10: Features
User Manual—Streaming Device and Remote Control III. FEATURES A. Audio & Video Hardware Features Feature Streaming Device SWiM/Multi-Switch capable Ethernet MoCA Wireless (802.11ac) Digital Audio Output HEVC DIRECTV WPS Button RC7x RF remote BLE Remote Front Touch Panel / Resolution LED Power Button Menu/Guide/Arrows/Select/Res buttons... -
Page 11: Software Features
User Manual—Streaming Device and Remote Control Software Features Category Feature Streaming Device 3DTV 3D Video Playback Ultra HD (4K) 4K Video Playback Audio Digital Audio Audio Dolby Digital Audio Secondary/Alternate Audio Cloud DVR Accessing cloud content ... -
Page 12: Appendix
User Manual—Streaming Device and Remote Control IV. APPENDIX A. LED STATES Front Panel “Network” LED Color State Booting / Standby Green RSSI is > -75 dBm. Excellent signal strength Yellow RSSI is between -75 and - 82 dBm. Borderline signal strength RSSI is <... -
Page 13: Federal Communications Commission Interference Statement
User Manual—Streaming Device and Remote Control B. Federal Communications Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 14 User Manual—Streaming Device and Remote Control If this streaming device causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
