Summary of Contents for Schumacher BT-250
Page 1
OWNER’S MANUAL Model: BT-250 Digital Battery Tester For 12 Volt Batteries Questions? Call Customer Service ELECTRIC CORPORATION MT. PROSPECT, IL 60056 Send Warranty Product Repairs To: Customer Returns P.O. Box 280 1025 E. Thompson Avenue Hoopeston, IL 60942-0280 1-800-621-5485 00-99-000439/1004...
Page 2
WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. TEST PROCEDURES / OPERATING INSTRUCTIONS IMPORTANT: 1.
WARNING 1. Working in the vicinity of a lead acid battery is dangerous. Batteries generate explosive gases during normal battery operation. For this reason, it is of utmost importance that each time before using your tester, (if you have any doubts) you read these instructions very carefully.
BATTERY TEST: BT-250 (12 Volt Batteries Only) 1. Before you test a battery in a vehicle, turn off the ignition, all accessories and loads. Close all the vehicle doors and the trunk lid.
Page 5
Pressing “ENTER” will move to the next step. Press the battery capacity of CCA: SAE: 200–1200, ENC2: 180–1280, DIN: 110–770 Press “ENTER” to begin the test. Test the battery for 5–7 seconds. When the test is complete, The display shows the actual volts and the actual CCA.
Page 6
LOAD ERROR: The tested battery is larger than 1200CCA or 120AH. Or the clamps are not connected properly. Press “ENTER” return to step 4 or remove the test clamps from the battery posts after completion of testing. * The operator is asked if any accessories are left on as a possible cause.
ORIGINAL PURCHASER AT RETAIL OF THIS PROD- UCT. THIS LIMITED WARRANTY IS NOT TRANSFER- ABLE. Schumacher Electric Corporation warrants this battery tester for one year from date of purchase at retail against defec- tive material or workmanship. If such should occur, the unit will be repaired or replaced at the option of the manufac- turer.
