Planet WL-U356L Quick Installation Manual

Thank you for purchasing PLANET 802.11g Wireless USB
Adapter, WL-U356L. This quick installation guide illustrates
the driver and utility installation steps. For more information,
please refer to the User's manual in the bundled CD.
Package Content
WL-U356L x 1
Quick Installation Guide x 1
CD Disk x 1
USB Cable x 1
This guide
installation for WL-U356L in Windows XP system.
The installations for other Windows systems are
Note
similar.
Installation Procedures
1. If you had ever installed the other Wireless
Cards before, please uninstall the existed
drivers and utilities first.
2. Please install the configuration utility before
Note
insert WL-U356L into the USB port of the
computer.
1. Insert the bundled CD into the CD-ROM driver. The Wizard
should run automatically to display the menu screen.
2. Select suitable utility link according to your system. In this
example, Windows 98/ME/2000/XP utility is selected.
leads you through the
3. Follow the Install Shield Wizard steps, and click "Finish"
when done.
proper
4. Insert WL-U356L into a vacant USB port of your PC. Win-
dows will detect this device automatically. When the "Found
New Hardware Wizard" dialog box appears, select "No, not
this time", and click "Next" to continue.
5. Choose the "Install the software automatically" and click
"Next".
