Sanyo WUXGA PLC-ZM5000L Brochure & Specs

Network
A Wired LAN Network
Standard function
control function is included
as standard equipment.
A centralized management and control system can be easily con gured.
Featuring the PJ-Net Organizer
(OPTION ITEM)
Real Time Capture function*
To display the screen image of the
The PJ-Net Organizer (POA-PN03C) is provided as optional
computer by the projector through
equipment, for centralized control of projectors over a wired the network in real time.
network. Installing the optional PJ Master into a PC or server
also lets you manage the PJ-Net Organizer-mounted projectors
over a network.
Network Communication function*
Network Viewer function*
PJ 1
To communicate by sharing the
To acquire the JPEG image data
captured image of a computer
from the le servers placed in the
with multiple computers and a
network and project them by the
projector. User can draw the text
projector.
and gure on the captured image
by using a drawing tool. PC 6
Capture a screen
PC 1 PC 2 PC 5
image of PC5
and make marking
with a tool.
* Image transmission is compatible up to WXGA.
Responding to a Host of Large-Screen Needs
Conventions and Other Events
Project crisp, sharp images from a variety of sources - PCs, document cameras, BD Player and more.
With the PLC-ZM5000's high output and brightness, there's no need to dim the room lights - so
viewers can read handouts and take notes comfortably during the presentation. Using a PC gives
you total control over image source switching, for easy, exible large-screen presentations.
Interface
PC 1
Interface
PC 2
Interface
VOD
Document Camera
PC for System Control
Theaters and Halls Stack two PLC-ZM5000 units, and you can project images from high-de nition sources onto a large
screen at an even higher brightness level. Using a system control PC, all facets of the presentation -
from start-up and brightness adjustment to image source switching - can be handled
automatically. The PLC-ZM5000 is also ideal for "Cinema Advertising" -- Works such as business
commercials can be easily projected before or between movies.
Server
BD Player
PC for
System
S-VHS VTR
Control
DVD Player
Lighting Control
Monitor Control
You can con gure a large-screen monitor system by using multiple PLC-ZM5000's in a rear
projection system to project images onto a multi-screen display. Use it to reproduce complex
visual information, such as network control schematics, maps, and images from surveillance
cameras. Using a system control PC makes it easy to operate and manage this kind of system.
Interface
Workstation 1
(Monitoring)
Interface
Workstation 2
(Monitoring)
Interface
Workstation 3
(Monitoring)
Interface
PC 1
PC for System Control
Speci cations
Product Number
Panel
Projection Lens
Projection Lamp
Brightness * 1
Uniformity * 1
Screen Size
Contrast Ratio * 1
Speaker
Power Lens Shift (Max)
Keystone Correction (Max)
Projector-1·········ON
Signal Compatibility
Projector-2·········OFF
Projector-3·········ON Color Systems
Temp A·········****°C
Terminal
PJ 1 PJ 2
PC 1 PC 1
Fan Noise
Operating Temperature
Scanning Frequency (input)
PC 3 PC 4 PC 6
PC 5 Power Source
Power Consumption
Dimensions ( W x H x D)
PJ 1 PJ 2 Weight
Main Accessories
PC 1 PC 2
Replacement Lamp Type No. : 6103469607
*1 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards. Measurement method / conditions are based on Appendix 2. *2 USB interface does not guarantee that every USB device is compatible. * All product names and company names are
trademarks or registered trademarks of their respective companies. * Product appearance and speci cations are subject to change without notice.
Throw Distance: unit (m, ft) (Aspect ratio horizontal: vertical = 16:10)
PC 3 PC 4 PC 6
Type Short Fixed Lens
PC 5
Part Number LNS-W21
Zoom / Focus Fixed / Power
Focal Length (mm / inch)
13.05 0.51 20.4-27.6 0.80-1.09
F value 2.0
Lens Aperture (ømm / øinch)
101.6 4.00
Lens Weight (kg / lbs) 1.08 2.38
Projection H1:H2 1:1 (Fixed)
Light Axis 1:1 (Fixed)
W1:W2
Signal Center ZM5000 Throw Ratio 0.8:1
Throw Distance m ft
Inch W x H (m) Fixed Wide Tele Wide Tele
TBC
40 0.9 x 0.5 0.63 2.07 1.0
60 1.3 x 0.8 0.97 3.19 1.6
Video Switcher Screen
80 1.7 x 1.1 1.32 4.32 2.1
100 2.2 x 1.3 1.66 5.45 2.7
120 2.6 x 1.6 2.00 6.57 3.2
Teleconference Security CS/BS DVD BD 150 3.2 x 2.0 2.52 8.26 4.0
System Camera Tuner Player Player
200 4.3 x 2.7 3.38 11.08 5.3
System
250 5.4 x 3.4 4.24 13.90 6.7
Video Signal (Digital)
300 6.5 x 4.0 5.10 16.72 8.0
Video Signal (Analog)
Control Signal 350 7.6 x 4.7 5.95 19.54 9.4
400 8.6 x 5.4 6.81 22.35 10.7
* Approximate projection distances are calculated based on lens speci cations. Individual lenses may diverge from this
gure by up to 5% due to slight variations in lens size and shape.
ZM5000 x 2
RGB Switcher
TBC
Scan Converter
RGB Switcher
Screen
Video Signal (Digital)
Video Signal (Analog)
Control Signal
RGB Matrix Switcher
ZM5000 ZM5000
Double Speed
Converter
TBC
PLC-ZM5000L
Video Switcher
Screen Screen
WUXGA 5000Im
Security Camera CS/BS DVD
System Tuner Player
Video Signal (Analog)
Control Signal
PLC-ZM5000L
Size 0.76 inch TFT p-Si x 3 (inorganic)
No. of pixels 6,912,000 (1920 x 1200 dots x 3)
Optional Lenses
NSHA 330 W
5,000 lm (Lamp mode: Auto / Normal, Image mode: Dynamic)
90 % (corner to center)
40 - 400 inch (Dependent on Lens)
2000 : 1 (Iris: on, Lamp mode: Auto / Normal, Image mode: Dynamic)
10 W, Monaural x 1
Up / Down: +/- 60 %, Left / Right: +/- 10 %
Vertical +/- 30 degrees, Horizontal +/- 30 degrees
Video 1080p/50,1080p/60,1080i/50, 1080i/60, 720p/50,720p/60,480i, 480p, 575i, 575p
Computer WUXGA / UXGA / WSXGA+ / SXGA+ / SXGA / WXGA / XGA / SVGA / VGA / MAC
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N
Input 1 Signal input DVI-D(HDCP) x 1, HDMI (Ver.1.3 with Deep color ) x 1 (Digital), Signal input D-sub15 x 1 (Analog RGB) (with SCART RGB)
Input 2 Signal input 5-BNC x 1 (G,B,R,H/V,V ) ( VIDEO/Y,Pb/Cb,Pr/Cr)
Input 3 Signal input RCA x 1 Yellow (VIDEO/Y ), Signal input RCA x 1 Blue (Pb/Cb), Signal input RCA x 1 Red (Pr/Cr), Signal input Mini DIN 4-pin x 1 (S-Video)
Monitor Out Analog RGB Signal Output D-sub15 x 1 (*Analog input only, *Except several signals)
Audio Input : Mini jack x 1 (stereo), : Mini jack x 1 (stereo), : RCA x 2 (stereo, L (Mono) / R) x 1
Audio Output Mini jack x 1 (stereo) (*Variable out)
Control LAN (RJ-45) x 1,D-sub9pin x 1
Other D-sub25pin for Optional Network box (Back of cabinet), USB* 2 : Type-B x1, Wired R / C: Mini jack x 1
29 dBA (Eco1)
5 - 40 celsius degrees
Horizontal: 15 kHz - 120 kHz, Vertical: 48 Hz - 100 Hz, Dot Clock162 MHz (Analog)
AC 100 - 240 V, 50/60 Hz
100-120 V Normal: 519 W Standby: 0.4 W (Eco) / 24 W (Network)
200-240 V Normal: 488 W Standby: 0.6 W (Eco) / 26 W (Network)
19.3 inch x 6.5 inch x 14.6 inch
19.8 lbs
Removable power cord x 1, D-sub 15 cable x 1, PIN code-locking label, Owner's manual (Quick Manual & CD-ROM), Remote control x 1 (AAA battery x 2)
External Dimensions (unit: mm (inch))
Short Zoom Lens Standard Zoom Lens Long Zoom Lens Long Zoom Lens 109.4 (4.3)
LNS-W20 LNS-S20 LNS-T20 LNS-T21
131.4 84.7
(5.2) (3.3)
x1.3 / Power x1.7 / Power x1.6 / Power x1.6 / Power
26.9-45.4 1.06-1.79 45.6-73.8 1.80-2.91 73.9-117.1 2.91-4.61
1.8-2.3 1.7-2.3 1.8-2.3 1.8-2.3
115.0 4.53 93.5 3.68 88.5 3.48 88.5 3.48
1.20 2.64 0.85 1.87 1.18 2.60 1.20 2.64
11:-1 - -1:11(approx.) 11:-1 - -1:11(approx.) 11:-1 - -1:11(approx.) 11:-1 - -1:11(approx.)
3:2-2:3 (approx.) 3:2-2:3 (approx.) 3:2-2:3 (approx.) 3:2-2:3 (approx.)
1.3-1.7:1 1.7-2.8:1 2.8-4.6:1 4.6-7.2:1
m ft m ft m ft m ft
Wide Tele Wide Tele Wide Tele Wide Tele Wide Tele Wide Tele 2.0 (0.1)
14.0 (0.6)
150.0 (5.9)
1.4 3.3 4.6 1.4 2.3 4.6 7.5 2.3 3.8 7.5 12.5 3.7 6.0 12.1 19.7 344.9 (13.6)
2.1 5.2 6.9 2.1 3.5 6.9 11.5 3.5 5.7 11.5 18.7 5.7 9.1 18.7 29.9 164.0 (6.5)
371.1 (14.6)
2.8 6.9 9.2 2.8 4.7 9.2 15.4 4.7 7.7 15.4 25.3 7.7 12.2 25.3 40.0
434.8 (17.1)
3.6 8.9 11.8 3.5 5.9 11.5 19.4 5.9 9.6 19.4 31.5 9.6 15.3 31.5 50.2
4.3 10.5 14.1 4.2 7.1 13.8 23.3 7.1 11.6 23.3 38.1 11.6 18.5 38.1 60.7
5.4 13.1 17.7 5.3 8.9 17.4 29.2 8.9 14.5 29.2 47.6 14.5 23.1 47.6 75.8
7.2 17.4 23.6 7.0 11.9 23.0 39.0 11.9 19.4 39.0 63.6 19.5 30.9 64.0 101.4
9.0 22.0 29.5 8.8 14.9 28.9 48.9 14.9 24.3 48.9 79.7 24.4 38.7 80.1 127.0
10.9 26.2 35.8 10.6 17.9 34.8 58.7 17.9 29.2 58.7 95.8 29.3 46.5 96.1 152.6 40.9 249.7 (9.8)
12.7 30.8 41.7 12.3 20.9 40.4 68.6 20.9 34.1 68.6 111.9 34.2 54.3 112.2 178.1 (1.6)
14.5 35.1 47.6 14.1 23.9 46.3 78.4 24.0 39.0 78.7 128.0 39.1 62.1 128.3 203.7
Terminals
