Sanyo PLC-XT35 Specification Sheet

5 0 0 0 A N S I L U M E N S
PLC-XT35/L
XGA Portable Multimedia Projectors
* XT35L: Lens sold separately
EASY INSTALLATION
The symmetric Lens Center Design offers unlimited setup options to meet
specific staging requirements. To further increase installation convenience,
the significantly improved Up/Down/Left/Right lens shift ensures flawless
image projection even at the most challenging positions. The many custom
screen adjustments and digital keystone correction (U/D, +/- 40 degrees)
all contribute to optimal installation.
REMARKABLE BRIGHTNESS
The high-tech optical system and the NSH330W lamp deliver an
impressive 5000 ANSI lumens brightness level.
EXCEPTIONAL CONTRAST RATIO
With a high-contrast optical system employing the Micro Lens technology,
the PLC-XT35 achieves a remarkable contrast ratio of 1000:1.
HIGH RELIABILITY
The newly-designed cabinet has a sophisticated One-Way Flow System
design, a system that efficiently controls the temperature that cools the
projector with a single intake and exhaust vent. A Filter Warning function
can alert the user to clean clogged filters, hence increasing picture quality.
EASY MAINTENANCE
The PLC-XT35 embodies both beauty and practicality with its detachable
top cover. The user can effortlessly flip open the top plate to clean and
replace the Prism Block system. Well-maintained LCD panels will
significantly reduce artifact from projected images.
NETWORK CONNECTIVITY
An optional PJ-Net Camera (POA-PN03C) and PJ Master Software (POA-
) allow for control and administration of projectors via a network.
PJNM01
The user can monitor the actual picture and check projector status and
control projector functions via any web browser. A warning notification will
be automatically sent to the registered user's email whenever the projector
encounters problems.
WHISPER QUIET FAN
The Whisper Quiet fan system produces an amazingly low noise level of
only 35 dBA (Eco mode).
Issued 11/07
T R U E X G A
PRESENTATION TECHNOLOGIES
SANYO Canada Inc.
300 Applewood Cres.
Concord, Ont. L4K 5C7
Telephone: (905) 760-9944
www.sanyo.ca
M U L T I M E D I A P R O J E C T O R S
S p e c i f i c a t i o n s
Resolution
Brightness (typical)
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Up/Down & Right/Left Ratio
Digital Keystone Correction
Projection System
Projection Lens
Lens Throw Ratio
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Sound Output
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
Computer Input Terminal 1
Computer Input Terminal 2
Video Input Terminal
Additional Input Terminals
Output Terminals
Included Accessories
Optional Accessories
• POA-PN03C – Optional PJ-Net Camera
• POA-PJNM01 – PJ Master Software
• 610 335 8093– Replacement Lamp
• 945 087 1468– Replacement Remote
• Optional Lenses (see below)
Warranty
Three years parts and labor, 1 year or 500 hours on
original lamp, Quick Repair program under warranty.
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
On Axis Short
Short Fixed Zoom
Part No. LNS-W11 LNS-W10
Zoom Fixed Power
Throw Ratio 0.8:1 1.23-1.62:1
F Stop 2.3 2.3-2.6
Lens Shift
1:1 10:0-1:1
(U/D, L/R) 13:7-7:13
*LNS-S10 Lens can not be used with PLC-XT35/L
PJ-Net Camera
645 087 1467
POA-PN03C
XGA (1024 x 768)
5000 ANSI Lumens
90% (Corner)
1.0" TFT Poly wo/Micro Lens
2,359,296 (786,432 x 3)
1000:1
30"-300"
4:3
3.9'-32.8'
Powered (1:1.3 zoom)
10:0 – 1:1 & 13:7 – 7:13
Vert. + 40°/-40°
Dichroic mirror & X prism system w/PBS
F1.7-2.1 / f1.30"-1.69"
1.6 – 2.1: 1
330W NSHA
H 15-100kHz; V 50-100Hz (auto sense/select)
140MHz(Analog), 100MHz(Digital)
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
UXGA(Only Analog RGB), WXGA, SXGA/+, SXGA, XGA,
SVGA, VGA, MAC
1W
100-240V AC; 50/60/Hz (auto sense/select)
1706
35 dBA (Eco mode)
500W
13.7" x 6.2"x 17.5"(Including Protrusion & Legs)
18.0 lbs.
Clean air filters, replace lamp assembly
RGB (D-Sub15 x1, DVI-D x1) • Audio (stereo mini jack x 1)
RGB/Component/Composite (BNC x 5)
Audio (stereo mini jack x 1)
Composite (RCA) • S-Video (mini DIN4)
• Stereo Audio (RCA x 2)
USB (Type B), Control (Mini Din 8-pin)
Monitor Out (D-Sub 15 x 1) • Audio (stereo mini-jack)
Wireless/Wired I/R Remote Control w/Mouse Pad and Laser
Pointer • AC power cord • VGA Cable • USB Cable •
Owner's manual (Quick manual & CD-ROM)
• 2 "AAA" Batteries • PIN Code label• Serial Cable
Optional Lens Specifications
STD Long
Zoom Zoom
LNS-S11 LNS-T10
Power Power
1.6-2.1:1 2.12-3.39:1
1.7-2.1 2.0-2.6
10:0-1:1 10:0-1:1
13:7-7:13 13:7- 7:13
Rear Back Panel
Remote
Ultra Long
Zoom
LNS-T11
Power
3.4-5.4:1
2.1-2.52
10:1-1:1
13:7-7:13
© 2007 SANYO
