SERVICE MANUAL LCD Television
Contents
Safety Notice..............................................
Chassis Block Diagrams......................... 4-5
Diagrams................................. 6-10
Adjustments................................. 16
Disassembly..................... 17-19
List..................................... 0
Chassis Electrical Parts List................ 1-9
Printed Wiring Board........................... 30-34
Schematic Diagram............................. 35-36
N8JW
System........ 11-15
FILE NO.
Model No. LCD-19XH7
Service Ref.No. LCD-19XH7-00
Product Code: 1-130-3-17
Original Version
Chassis Series: UE7-L
Give complete "SERVICE REF. NO." for
parts order or servicing.It is shown on the
rating lable at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television
transmission system and power source
differ from the design specifi cations.
Refer to the specifi cation table.
REFERENCE NO.
(Argentina)
Advertisement
Table of Contents
Related Manuals for Sanyo LCD-19XH7
Summary of Contents for Sanyo LCD-19XH7
-
Page 1: Table Of Contents
FILE NO. SERVICE MANUAL LCD Television Model No. LCD-19XH7 (Argentina) Service Ref.No. LCD-19XH7-00 Product Code: 1-130-3-17 Contents Original Version Safety Notice.......... Specifi cations..........3 Chassis Series: UE7-L Chassis Block Diagrams......4-5 IC Block Diagrams......... 6-10 On-screen Service Menu System..11-15 Service Adjustments......... -
