CareFusion All-In-One (AIO) PC Platform
DMS-SA1300-A1E user manual
Intel® Atom
D2550 CPU
TM
All In One (AIO) panel PC with 15" TFT LCD
Version
Date
0.1
2013/12/26

TAB Changed
ALL
1
Changes content
1. Establish tab "
 1.2 RF Instructions
2. Establish tab "
2.4 Main Board Jumper
  Setting & Connector List
3. Establish tab "
2.5  Docking Board
Connector List
"
"
CIC"

Advertisement

Table of Contents
loading

Related Manuals for Intel CareFusion DMS-SA1300-A1E

Summary of Contents for Intel CareFusion DMS-SA1300-A1E

  • Page 1 CareFusion All-In-One (AIO) PC Platform DMS-SA1300-A1E user manual Intel® Atom D2550 CPU All In One (AIO) panel PC with 15” TFT LCD Version Date TAB Changed Changes content 2013/12/26 1. Establish tab " "  1.2 RF Instructions 2. Establish tab " 2.4 Main Board Jumper ...

  • Page 2: Table Of Contents

    Table of Contents Introduction ................3     1.1  Safety Instructions ................ 3  1.2  RF Instructions ............. 錯誤! 尚未定義書籤。  1.3  List of Accessories ................. 5  1.4  Additional Information and Assistance .......... 5  General Information ......... 錯誤! 尚未定義書籤。     2.1  Introduction ............錯誤! 尚未定義書籤。  2.2 ...
  • Page 3   3   ...

  • Page 4: Introduction

    1. I NTRODUCTION The document combines text and illustrations, providing a comprehensive overview of the system. The information is presented as sequential steps of action, allowing the user to learn directly how to use the device. The text provides explanations and instructs the user step by- step in the practical use of the product, with short, clear instructions in easy-to-follow sequence.

  • Page 5: Rf Instructions

    CAUTION Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4° F) or above 60° C (140° F). this may damage the equipment. If your computer is losing dramatic time or the BIOS configuration reset to default, the battery has no power.

  • Page 6: List Of Accessories

    and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

  • Page 7: Additional Information And Assistance

    Docking station Adapter Warning No user serviceable parts inside, refer servicing to qualified personnel. Only the accessories indicated on the list of accessories above have been tested and approved to be used with the device. Accordingly it is strongly recommended that only these accessories be used in conjunction with the specific device.

  • Page 8: General Information

    Ethernet ports、Line out and SATA interface, the DMS-SA13 is an user-friendly computer. 2.2 Specifications Platform Specification Description Remark Processor Intel D2550 1.8Ghz with 1MBL2 cache System Chipset NM10 System Memory DDR3 1333MHz slot x 2(Max 2GB/slot) Storage SATA through Docking...
  • Page 9 Through docking station No Button on AIO ID Button Control Mechanical and Environment Dimensions (W x L x H) 368x306x73 Weight 5.5kg 5℃~40℃ Operating Temperature -20℃~60℃ Storage Temperature Operating Humidity 15%~85% relative humidity, non-condensing Storage Humidity 15%~85% relative humidity, non-condensing -20℃~50℃...

  • Page 10: Dimensions

    2.3 Dimensions Unit: mm 10   ...
  • Page 11 VESA Mounting: 100x100mm Warning : Use suitable mounting apparatus to avoid risk of injury Cleaning/Disinfecting During normal use of the DMS-SA13 may become soiled and should, therefore, be cleaned regularly. Agents: Green tinctured soap and Enzymatic detergents Steps: 1. Wipe the DMS-SA13 with a clean cloth that has been moistened in the cleaning solution. 2.

  • Page 12: Main Board Jumper Setting & Connector List

    2.4 Main Board Jumper Setting & Connector List   Main board Top side     12   ...
  • Page 13 Main board Bottom side 13   ...
  • Page 14 VGA Setting Part Number 1653002938 Footprint HD_8x2P_50_BOX Description BOX HEADER 8x2P 1.27mm Pin Name Pin    Part Ref  1  VGA_RED_CONN  2  +V5S_CONN_VGA  3  VGA_GREEN_CONN  4  GND  5  VGA_BLUE_CONN  6  Not Connected to Net  7  Not Connected to Net  8  VGA_DDCSDA_CONN  9  GND  10  CRT_HSYNC_R  11  GND  12  CRT_VSYNC_R ...
  • Page 15 Mini PCIE Part Number 1654002538 Footprint FOX_AS0B226-S68K7F Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H Pin Name Pin    Net Name  Pin    Net Name  1  WAKE_N_R  29  GND  2  +V3.3SB  30  SMB_CLK_RESUME_IO  3  Not Connected to Net  31  PCIE_TX2_C_DN  4  GND  32  SMB_DATA_RESUME_IO  5 ...
  • Page 16 15  GND  43  GND  16  Not Connected to Net  44  LED_WLAN  17  Not Connected to Net  45  Not Connected to Net  18  GND  46  LED_WPAN  19  Not Connected to Net  47  Not Connected to Net  20  WIFI_DISABLE_N  48  +V1.5  21  GND  49  Not Connected to Net  22  PRST_MINI#  50  GND  23  PCIE_RX2_DN  51  BT_DISABLE_N  24  +V3.3SB  52  +V3.3SB  25 ...
  • Page 17 CN10 Speaker Part Number 1655304120 Footprint WHL4H-2M_A Description WAFER BOX 4P 2.0mm 90D(M) DIP 2001-WR-4 RoHS Pin Name AMP_ROUT_N AMP_ROUT_P AMP_LOUT_N AMP_LOUT_P 17   ...
  • Page 18 CN12 Docking Connector (To Docking IO board) Part Number 1654010250 Footprint DOCKING_88P_51720-10107201A Description Docking CONN. 88P 90D(M) DIP 51720-10107201AALF Pin Name Pin    Net Name  Pin    Net Name  Pin    Net Name  A1  MDI3+_1  B4  GND  D15  TUSB1_z_P+  A10  DK_PWRBTN_D#  B5  MDI1‐_1  D16 ...
  • Page 19 A9  +V5_USB67  C3  PLUG_SATA0_RX‐  G6  PGND  B1  MDI3‐_1  C4  LAN2_LED1  G7  PGND  B10  EN_COREPWR  C5  MDI0‐_1  G8  PGND  B11  LED_WXAN#  C6  MDI3‐_2  H1  PGND  B12  SATA_LED_N  C7  MDI1+_2  H2  PGND  B13  USB5_z_P+  C8  USB6_z_P‐  P1  +Vin_a  B14  GND  C9  GND  P2 ...
  • Page 20 CN13 Part Number 1654906400 Footprint WHL6HS-125-85204 Description WAFER 6x1P 1.25mm 90D(M) SMD 85204-06001 Pin Name +12_INV Not connect Not connect MB_LVDS_BKLT_EN MB_LVDS_BKLT_CTRL 20   ...
  • Page 21 CN14 Touch Part Number 1654904503 Footprint WF_4P_49_BOX_RA Description WAFER BOX 4x1P 1.25mm 90D(M) SMD 85204-04001 Pin Name USB+ USB- 21   ...
  • Page 22 CN15 LVDS Part Number 1653920140 Footprint DF19G-20x1H Description CONN. 20P 1.0mm 90D(M) SMD DF19G-20P-1H(54) Pin Name Pin    Net Name  Pin    Net Name  1  +VDD_LCD  12  LVDS_TX2_B_DP  2  +VDD_LCD  13  GND  3  GND  14  LVDS_CLK_B_DN  4  REV_SCAN  15  LVDS_CLK_B_DP  5  LVDS_TX0_B_DN  16 ...
  • Page 23 CN17 EC Debug port Part Number 1654009557 Footprint FPC24H-05M Description FFC/FPC Conn. 24P 0.5mm 90D(F) SMD 52435-2471 Pin Name Pin    Net Name  Pin    Net Name  1  EC_KSI7  14  EC_KSO10  2  EC_KSI6  15  EC_KSO9  3  EC_KSI5  16  EC_KSO8  4  EC_KSI4  17  EC_KSO7 ...

  • Page 24: Docking Board Connector List

    2.5 Docking Board Connector List Pin        Description     Pin        Description     Pin        Description        Pin        Description        P1        VIN       ...

  • Page 25: System Setup

    SYSTEM SETUP 3.1 A Quick Tour of the DMS-SA13 Before you start to set up the DMS-SA13, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.

  • Page 26: Installation Procedures

    3.2 Installation Procedures 3.2.1 Connecting the power cord to system The DMS-SA13 could only be powered by a DC power adapter with docking station. Be sure to always handle the power cords by holding the plug ends only. Follow these procedures in order: 1.

  • Page 27: Running The Bios Setup Program

    Figure 2-4 3.2.2 Switch on the power Press the power button on the right-hand side of docking station to power on the system. 3.3 Running the BIOS Setup Program Your DMS-SA13 is likely to have been properly set up and configured by your dealer prior to delivery.

  • Page 28: Installing System Software

    the power on self-test (POST). If an error occurs, an error message will be displayed on screen, and you will be prompted to run the setup program. The current firmware versions, default settings, and options for the BIOS appear in the Appendix. 3.4 Installing System Software Recent releases of operating systems from major vendors include setup programs which load automatically and guide you through hard disk preparation and operating system installation.

  • Page 29: Addendum

    4. A DDENDUM 4.1 Firmware Version History All-In-One BIOS Notes (project (CFN P/N & Rev) (ADV P/N & Rev) version) 353475-01 A DMS-SA1300-A1E SA13X007 0006 Initial Production Release 353475-01 B DMS-SA1300-A1E SA13X007 0006 Change Antenna to meet FCC certification 4.2 BIOS settings and options Default is the underlined italic where applicable ...
  • Page 30 Super IO Configuration  Selecting item presents new screen for the following options.  *Super IO chip  Display the super IO device  Selecting item to presents new screen containing PC voltage(s) and  *H/W monitor  temperature(s)  Chipset Tab     Host Bridge  Selecting item presents new screen for the following options.  *Memory frequency and timing  Selecting item presents new screen for the following options.  **MRC fast boot  Options: Enable or disable  **Dyn SR  Options: Enable or disable  *Intel IGD configuration  Selecting item presents new screen for the following options.  **IGFX ‐ Boot type  Options: VBIOS default, LFP, EFP, LFP+EFP  Options: VBIOS default, 1024x768, 1280x1024, 1366x768, 1224x600,  **LCD Panel type  1280x800  **Fixed Graphic Memory Size  Options: 128MB. 256MB  *Memory information  Display the frequency, total present, and value per slot  South Bridge  Selecting item presents new screen for the following options.  *Azalia Controller  Options: HD Audio or disable  Boot Tab     Number of seconds to wait for the setup activation key: 1 to 65535  Setup Prompt Timeout  (0xFFFF). Indefinite waiting is invoked by entering 65535.  Bootup Numlock State  Keyboard Num lock state: On or Off.  Determines if the BIOS should hide the normal POST messages with the ...
  • Page 31 　 system boots from the selected path then reverts back to the  default behavior for subsequent boots after USB or PXE is removed. Security Tab     Limits access to changing the BIOS setup. It is only asked when attempting  Administrator Password  to enter BIOS setup if User Password is not assigned.    The default  Password is U$3th3forc3.    User Password  Set User password to access BIOS.    No default password is assigned.  HDD Security configuration  Display header.  The port # and manufacturer name appear for a functional drive(s). If  HDD <port # & mfg name>  device(s) supports security, selecting item presents new screen for the  following options for each drive.  *HDD information  Display the types of security supported and status of each.  *Set User Password  Set User password to access drive. No default password is assigned.  Set Master password to enable drive security. No default password is  *Set Master Password  assigned.  Save & Exit Tab     When you have completed the system configuration changes, select this  Save Changes and Exit  option to leave BIOS setup environment and the new system configuration  parameters can take effect.  Discard Changes and Exit  Leave BIOS setup environment without saving any changes.  Leaves the BIOS setup environment with saving any changes and reboots  Save Change and Reset  the computer so the new system configuration parameters can take effect.  Discard Changes and Reset ...
  • Page 32 Plus/Minus (+/‐)  Change option  F1  General Help  F2  Previous value  F3  Optimized or defaults  F4  Save and Exit  F10  Save and Reset  ESC  Exit        The following capabilites are required for the BIOS if applicable.    Their  Advanced Functionalities  specific location within the BIOS is not critical.  Intel Fast Flash Standby  Selecting item presents new screen for the following options.  *iFFS Support  Options: Enable or Disable  EC version  Display the F/W version of embedded controller  Launch PXE OpROM  Boot option for legacy network device: Enable or disable.  Notes:  “*” – Denotes an item not appearing on the initial “Tab”.    The item is a sub or alternate selection after choosing the higher level option.    32   ...
