18.1 mm
D
Dimensions
(with tube)
H
Typical Characteristics
Charge
1.8
Charge : 2A (- V=10mV)
1.7
Ambient Temp. : 0°C,20°C,40°C
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0
10
20
30
Charge Time (min)
Type : Nickel-Metal Hydride Battery
Capacity
Nominal Voltage
Charging Current x Time
43.2 mm
Ambient Temp.
Internal Impedance
(after discharge to E.V.=1.0V)
Weight
Size
1)Single cell capacity under the following condition.
18.1 mm
2)Use recommended charging system.
43.2 mm
3)After a few charge and discharge cycles under the above 1) condition.
4)With tube.
0°C
20°C
40°C
40
50
60
70
80
Cell Type HR-4/5FAUP
Specifications
Typical
1)
Minimum
Fast Charge
Charge
Fast Charge
Condition
Discharge Condition
Less than
30days
Storage
Less than
Condition
90days
Less than
1year
3)
4)
:(Diameter) x (Height)
4)
Charge : 195mA×16h,
Discharge : 390mA(E.V.=1.0V) at 20°C
Discharge
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
Charge : 2A (-DV=10mV)
Rest : 1h
0.8
Discharge : 0.4A,2A,5A,10A,15A (E.V.=0.6V)
0.7
Ambient Temp. : 20°C
0.6
0.5
0
250 500 750 1000 1250 1500 1750 2000 2250
Discharge Capacity (mAh)
Size : 4/5FA
1950mAh
1800mAh
1.2V
1950 mA x about 1.1h
2)
0°C - 40°C
2)
0°C - 50°C
-20°C - 50°C
-20°C - 40°C
-20°C - 30°C
About5 mΩ(at 1000Hz)
About 39 g
18.1(D) x 43.2(H) mm
0.4A 2A
5A
10A
15A
