AT&T CLP99286 Quick Start Manual

Quick start guide
CLP99286/CLP99386/CLP99456/CLP99486/CLP99546/CLP99556/
CLP99586
This quick start guide provides you with basic instructions
only. For more complete instructions, please refer to the user's
manual in the package, or download it at
www.telephones.att.com/manuals.
Parts checklist
Your package contains:
• Handset • Battery compartment cover
(2 for CLP99286) (2 for CLP99286)
(3 for CLP99386) (3 for CLP99386)
(4 for CLP99456/CLP99486) (4 for CLP99456/CLP99486)
(5 for CLP99546/CLP99556/ (5 for CLP99546/CLP99556/
CLP99586) CLP99586)
• Charger with power adapter • Battery
(1 for CLP99286) (2 for CLP99286)
(2 for CLP99386) (3 for CLP99386)
(3 for CLP99456/CLP99486) (4 for CLP99456/CLP99486)
(4 for CLP99546/CLP99556/ (5 for CLP99546/CLP99556/
CLP99586) CLP99586)
• Telephone base • Wall-mount bracket
• Telephone line cord • User's manual
• Telephone base power adapter • Quick start guide
Basic steps to set up & operate your phone
Basic installation
1 Install telephone base & charger
Install handset battery
2
3 Install telephone base on the wall (optional)
Common settings
4 Set date and time
Basic answering system setup via voice guide
5
6 Set ringer volume
®
7 Add a Bluetooth cell phone / headset
Record own announcement
8
9 Set number of rings
Operations
10 Directory
Caller ID
11
12 Call block
Download a cell phone directory
13
Remote voice control
14
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by
Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a
member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.
1
Install telephone base & charger
Plug!
Click!
Plug!
DSL filter
If you have DSL high-speed
Internet service, a DSL filter
(not included) is required.
Click!
Click!
2
Install handset battery
1 2
3
4
Light on!
Charge for at least 30 minutes before initial settings.
•
• Charge for 11 hours before initial use.
3
Install telephone base on the wall (optional)
Follow the instructions only if you would like to mount the telephone on
a wall.
1
Unplug!
Unplug!
2
Slide down!
3 If you have DSL high-speed
Internet service, a DSL filter
(not included) is required.
Plug! Align!
Click!
Align!
4
INSTALLATION COMPLETED!
Keep reading for common settings and operations.
4
Set date and time
Set the date/time before using the answering system.
Using a cordless handset or the telephone base:
1. Press MENU -> Press q/p to Set date/time -> Press SELECT.
2. Enter the month (MM), day (DD) and year (YY) -> Press NEXT.
3. Enter the hour (HH) and minute (MM).
4. Press q/p to choose AM or PM -> Press SAVE.
5
Basic answering system setup via voice guide
You can follow the voice guide to record your own announcement, set
the number of rings, and set the message alert tone.
Using a cordless handset or the telephone base:
1. Press MENU -> Press q/p to Answering sys -> Press SELECT.
2. Press q/p to Voice guide -> Press SELECT.
3. Set up your answering system by inputting the designated numbers,
as instructed.
6
Set ringer volume
You can set the ringer volume level to one of the six levels or turn the
ringer off.
Using a cordless handset or the telephone base:
1. Press MENU -> Press q/p to Ringers -> Press SELECT.
2. Press SELECT to select Ringer volume.
3. Press q/p to choose the desired level -> Press SET.
7
Add a Bluetooth cell phone / headset
To use a Bluetooth enabled cellular phone or headset with your
telephone, you must first pair and connect your Bluetooth cellular phone
or headset with the telephone base.
Bluetooth wireless technology operates within a short range (up to 30
feet). Keep the connected device within 15 feet of the telephone base for
optimal performance.
To pair and connect a cell phone using the telephone base:
1. Press MENU -> Press q/p to Bluetooth -> Press SELECT.
2. Press SELECT to select Add device.
3. Press SELECT to select Add cellular.
4. Disconnect the cell phone from any Bluetooth device -> Press NEXT.
5. Place the cell phone next to the telephone base.
6. Press NEXT to turn on the telephone base discoverable mode.
7. Turn on the Bluetooth feature of your cell phone and search for or
add new advices. Once your cell phone finds your AT&T phone
(AT&T DECT 6.0), press the appropriate key on your cell phone to
continue the pairing process.
• Enter the cell phone passcode (typically 0000), if required ->
Press SET.
• Enter the PIN (default PIN: 0000) of the telephone base into your
cell phone, if required.
7
Add a Bluetooth cell phone / headset (Continued)
To pair and connect a headset using the telephone base:
-> Press q/p to Bluetooth -> Press SELECT.
1. Press MENU
2. Press SELECT to select Add device.
3. Press q/p to Add headset -> Press SELECT.
4. Disconnect your headset from any Bluetooth device -> Press NEXT.
5. Set your headset to discoverable mode -> Press NEXT.
6. Press q/p to choose your headset, if required -> Press SELECT.
• Enter the PIN (typically 0000) of your headset, if required ->
Press NEXT.
8
Record own announcement
You can use the preset announcement to answer calls, or replace it with
your own recorded announcement.
Using a cordless handset or the telephone base:
1. Press MENU -> Press q/p to Answering sys -> Press SELECT.
2. Press SELECT to select Announcement.
3. Press SELECT to select Record annc.
4. Facing the handset or telephone base, record your announcement and
press STOP to end recording and save it.
9
Set number of rings
You can set the answering system to answer an incoming call after 2,
3, 4, 5 or 6 rings, or you can select toll saver. If you choose toll saver,
the answering system answers a call after two rings when you have new
messages, or after four rings when there are no new messages. This
feature allows you to check for new messages and avoid paying long
distance charges if you are calling from out of your local area.
Using a cordless handset or the telephone base:
1. Press MENU -> Press q/p to Answering sys -> Press SELECT.
2. Press q/p to Ans sys setup -> Press SELECT.
3. Press q/p to # of rings -> Press SELECT.
4. Press q/p to choose among 6, 5, 4, 3, 2 or Toll saver ->
Press SELECT.
SETUP DONE!
Keep reading for some operations.
