COLOUR
TELEVISION
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PICTURE IN PICTURE
(OPTION)
TELETEXT
Register your product at www.samsung.com/global/register

Advertisement

loading

Related Manuals for Samsung WS-32Z308P

Summary of Contents for Samsung WS-32Z308P

  • Page 1 COLOUR TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PICTURE IN PICTURE (OPTION) TELETEXT Register your product at www.samsung.com/global/register...
  • Page 3 ONNECTING AND REPARING View of Your Television (depending on the model) ... Infrared Remote Control (depending on the model) ... Inserting the Batteries in the Remote Control... Connecting to an Aerial or Cable Television Network ... Switching Your Television On and Off... Placing Your Television in Standby Mode ...
  • Page 4 Contents SING THE ELETEXT EATURE Teletext Feature ... Displaying the Teletext Information ... Selecting a Page by Number... Using FLOF to Select a Page... Storing Teletext Pages ... DDITIONAL NFORMATION ON Connecting to the External Input/Outputs... Connecting to the Audio Output ... Connecting to the RCA Input...
  • Page 5 View of Your Television ➢ The actual configuration on your TV may be different, depending on your model. Control Panels Front of the TV 1) Input Source Selection 2) Menu Display 3) Volume Adjustment 4) Channel Selection ➢ N You can use the mode.
  • Page 6 View of Your Television Connection Panels Side of the TV S-Video Input Video Input Audio Input (L, R) English - 6 (depending on the model) (continued) Rear of the TV SCART Audio/ Video Input/Output 75Ω Coaxial Connector for Aerial/Cable Network ➢...
  • Page 7 Infrared Remote Control TELEVISION STAND-BY PICTURE SIZE SELECTION SOUND MODE SELECTION DIRECT CHANNEL SELECTION ONE/TWO-DIGIT CHANNEL SELECTION VOLUME INCREASE TEMPORARY SOUND SWITCH-OFF VOLUME DECREASE MENU DISPLAY MOVE TO THE REQUIRED MENU OPTION/ ADJUST AN OPTION VALUE RESPECTIVELY SOUND MENU DISPLAY TURBO SOUND STILL PICTURE DNIe DEMO...
  • Page 8 Infrared Remote Control TELETEXT SIZE SELECTION TELETEXT SUB-PAGE TELETEXT PAGE HOLD SUB PICTURE(PIP) NEXT CHANNEL PIP ON/OFF PROGRAMME SELECTION BY NAME SUB PICTURE(PIP) LOCATION SELECTION SUB PICTURE(PIP) SOURCE SELECTION English - 8 (depending on the model) (continued) TELETEXT DISPLAY/ MIX BOTH TELETEXT INFORMATION AND THE NORMAL BROADCAST TELETEXT STORE TELETEXT NEXT PAGE...
  • Page 9 Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: N Purchase the television N Find that the remote control is no longer operating correctly Remove the cover on the rear of the remote control by pressing the symbol ( ) downwards and then pulling firmly to remove it.
  • Page 10 Switching Your Television On and Off The mains lead is attached to the rear of your television. Placing Your Television in Standby Mode Your television can be placed in Standby mode, in order to reduce: The Standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example).
  • Page 11 Becoming Familiar with the Remote Control The remote control is used mainly to: N Change channels and adjust the volume N Set up the television using the on-screen menu system The following table presents the most frequently used buttons and their functions.
  • Page 12 Plug & Play Feature Plug & Play Language English Srpski Deutsch Hrvatski Român™ Français Magyar Nederland Polski Español êÛÒÒÍËÈ Italiano Å˙΄‡ÒÍË Svenska Türkçe Português Norsk ∂ÏÏËÓÈο Dansk âe‰tina Suomi Move Skip Check antenna input. œ œ √ √ Move Skip Auto Store œ...
  • Page 13 Viewing the Demonstration To become familiar with the various menus provided by your television, you can view the inbuilt demonstration. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Setup. Result: The options available in the Setup group are displayed.
  • Page 14 Storing Channels Automatically Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort √ √ Name † † More œ œ √ √ Move Enter Return Auto Store œ œ Belgium √ √ Country Search : -/+ œ...
  • Page 15 Sorting the Stored Channels This operation allows you to change the programme numbers of stored channels. This operation may be necessary after using auto store. You can delete the channels you do not want to keep. Press the MENU ( ) button.
  • Page 16 Storing Channels Manually Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort √ √ Name † † More œ œ √ √ Move Enter Return Manual Store œ œ P 1----- √ √ Programme Colour System : AUTO Sound System...
  • Page 17 Storing Channels Manually If you know the number of the channel to be stored, see the following steps. ◆ Press the ▲ or ▼ button to select Channel. ◆ Press the √ button. ◆ Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel).
  • Page 18 Skipping Unwanted Channels Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort √ √ Name † † More œ œ √ √ Move Enter Return Add/Delete œ œ Added √ √ : Added : Added : Added œ...
  • Page 19 Assigning Names to Channels Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Channel. Result: The options available in the Channel group are displayed.
  • Page 20 Fine Tuning Channel Reception Channel … … More √ √ Fine Tune : Off œ œ √ √ Move Enter Return Fine Tune Reset Move Save œ œ √ √ Adjust Return English - 20 If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation.
  • Page 21 Using the LNA (Low Noise Amplifier) feature This function is very useful in the situation that the TV is used in weak signal. LNA amplifies the TV signal in the weak signal area, but not noise. This feature is working only weak signal condition, and that is memorized on current channel, additional.
  • Page 22 Customizing the Picture Settings Picture œ œ Dynamic √ √ Mode Size : Auto Wide Scan Mode : Natural Digital NR : On DNIe Demo : Off † † More œ œ √ √ Move Adjust Return Mode œ œ Standard √...
  • Page 23 Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements simply by pressing the “P.SIZE ( Depending on the model, the following picture sizes are available: ◆ Auto Wide, 16:9, Panorama, Zoom1, Zoom2, 4:3 ➢...
  • Page 24 Extra Picture Settings Picture Mode : Dynamic Size : Auto Wide œ œ Natural √ √ Scan Mode Digital NR : On DNIe Demo : Off † † More œ œ √ √ Move Adjust Return Picture Mode : Dynamic Size : Auto Wide Scan Mode...
  • Page 25 Setting the Blue Screen If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background. If you wish to continue viewing the poor picture, you must set the “Blue Screen” mode to “Off”. Press the MENU ( ) button.
  • Page 26 Freezing the Current Picture Changing the Sound Standard Sound œ œ Custom √ √ Mode √ √ Equalizer Auto Volume : Off Dolby Virtual : Off Turbo Sound : Off Pseudo Stereo : Off œ œ √ √ Move Adjust Return English - 26 You can freeze the picture when watching a television programme...
  • Page 27 Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Sound. Result: The options available in the Sound group are displayed.
  • Page 28 Extra Sound Settings Sound Mode : Custom √ √ Equalizer œ œ On √ √ Auto Volume Dolby Virtual : Off Turbo Sound : Off Pseudo Stereo : Off œ œ √ √ Move Adjust Return Sound Mode : Custom √...
  • Page 29 Selecting the Melody You can hear clear melody sound when the television is powered on or off. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Setup. Result: The options available in the Setup group are displayed.

  • Page 30: Selecting The Sound Mode

    Selecting the Sound Mode The “DUAL I-II” button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “DUAL-I ” or “STEREO”, depending on the current transmission. NICAM Stereo Stereo ➢...
  • Page 31 Setting and Displaying the Current Time You can set the television’s clock so that the current time is displayed by pressing the “INFO ( )” button. You must also set the time if you wish to use the automatic on or off timers. ➢...
  • Page 32 Setting the Sleep Timer Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off Melody : On √ √ Demonstration œ œ √ √ Move Enter Return Time Clock 11 : 00 œ œ 30min √ √ Sleep Timer Timer -- : -- Off...
  • Page 33 Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: ◆ Switch on automatically and tune to the channel of your choice at the time you select ◆ Switch off automatically at the time you select ➢...
  • Page 34 Setting the Preferred Volume Level/Channel Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off Melody : On √ √ Demonstration œ œ √ √ Move Enter Return Time Clock 11 : 00 Sleep Timer :30min On Timer 06 : 00 On...
  • Page 35 Viewing an External Signal Source/Edit Name Use the remote control to switch between viewing signal from connected equipment, such as VCR, DVD, Set-Top-boxes and the TV source (broadcast or cable) Press the MENU button. Result: The main menu is displayed. Press the œ...
  • Page 36 Viewing the Picture In Picture (PIP) Picture … … More Tilt √ √ œ œ √ √ Move Enter Return œ œ Off √ √ œ œ √ √ Move Adjust Return : On œ œ TV √ √ Source √...
  • Page 37 Viewing the Picture In Picture (PIP) Press the ▲ or ▼ button to select Size. Select a size of sub picture by pressing the œ or √ button. Result: The sizes are displayed in the following order: Large - Small - Double Window - 16 PIP ➢...
  • Page 38 Teletext Feature Most television channels provide written information services via teletext. Information provided includes: This information is divided into numbered pages (see diagram). Displaying the Teletext Information You can display Teletext information at any time on your television. English - 38 N Television programme times N News bulletins and weather forecasts N Sports results...
  • Page 39 Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed.
  • Page 40 Using FLOF to Select a Page The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control. Storing Teletext Pages You can store up to four teletext pages to display them later at leisure.
  • Page 41 Connecting to the External Input/Outputs ➢ “EXT 1 (RGB)” is used for the equipment with an RGB output, such as video game devices or video disc players. Rear of the TV This end can be fitted with: N A SCART connector N Three RCA connectors (Video + Audio-L and R) If you have a second VCR and wish to copy cassettes tape, connect the source VCR to “EXT 1 (RGB)”...
  • Page 42 Connecting to the RCA Input ➢ The RCA (VIDEO and AUDIO-L+R) connectors are used for equipment, such as camcorders, video disc players, and some video game devices. Side of the TV Connecting to the S-Video Input ➢ The S-VIDEO and RCA (AUDIO-L+R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR.
  • Page 43 Connecting to the DVD Player Rear of the TV N Connect the RCA Cable to “L” and “R” on the rear of your television and the other end to “Audio Out” connector of the DVD player. Connect the RCA Cable to “Y”, “P and the other end to the “Component Video Out (Y, P N Only black signal is output from a monitor in Component mode.
  • Page 44 Automatic Degaussing to Remove Colour Patches A degaussing coil is mounted around the picture tube, so you do not normally need to degauss the television manually. If you move the television to a different position and colour patches appear on the screen, you must: N Switch the television off by pressing the “...

  • Page 45: Troubleshooting

    Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. No sound or picture...
  • Page 46 Memo English - 46...
  • Page 47 Memo English - 47...
  • Page 48 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-03554A-00...
