Storage System - Huawei OceanStor 5300 V5 Quick Configuration Manual

Storage system

1b
Share directories
6
5 share
4 File system
Storage pool
3
2 Disk domain
1 Disks
The storage system automatically identifies all
1
disks.
Disk domains are comprised of the same or
2
different types of disks. Services of different
disk domains are isolated from each other.
3 Storage pools are created in disk domains and
comprised of RAID groups formed by disks of
different performance. For OceanStor 5000,
6000, and 18000 series storage systems, a
storage pool can be divided into three storage
tiers based on storage media: high-performance
tier, performance tier, and capacity tier. For
OceanStor 5000F, 6000F, and 18000F series
storage systems, a storage pool contains the
high-performance tier only.
Sharename
CIFS share
File system
Data area
Hot spare area Hot spare area
High-performance tier Performance tier
High-performance tier Performance tier
SSD
3
Username
Homedir share
Data area Data area
Hot spare area
Capacity tier
Capacity tier
SAS NL-SAS
A file system can be created in a storage pool to
4
provide storage space for a CIFS share.
After creating a CIFS share, you can set different
5
access permissions for users.
A shared file system appears as a directory on a
6
Windows-based client when the client accesses the
CIFS share provided by a storage system.
A storage system shares its file system with a user
in CIFS Homedir mode. The shared file system
appears as a directory. The directory name is the
same as the user name. The Homedir directory can
be accessed only by this user.
