Summary of Contents for Curtis FP-10
- Page 1 MODEL FP-10 CURTIS INSTRUMENTS, INC. 200 Kisco Ave. Mount Kisco, New York 10549 914-666-2971 www.curtisinstruments.com Read Instructions Carefully! 53090 Rev B 6/18...
-
Page 2: Table Of Contents
SAFETY INSTRUCTIONS TABLE OF CONTENTS 1. Technical Specifications This product was manufactured and tested according to the 1.1 Electrical applicable technical standards. It complies with all the safety regulations as shipped from the factory. 1.2 Mechanical Installation and startup must be performed by skilled 1.3 Environmental personnel. -
Page 3: Technical Specifications
Rotational cycles: +1,000,000 Wiring Neutral & Full Throttle Switches The Model FP-10 has a 1 meter long, nine circuit cable for ease of wiring into any system. The wiring Type: SPST – NO assignment of the FP-10 is shown in Table 1:... -
Page 4: Mechanical
1.2 Mechanical Chemical Resistance • Engine Oil The molded housing is a glass filled nylon • Diesel Fuel 6/6. It is sealed to IP-67. Refer to Outline & • Hydraulic Fluid Installation Drawings for detailed specifications. The • Ethylene Glycol FP10 is designed to meet 1 million cycles of use. -
Page 5: Installation
2. INSTALLATION NOTES: The Model FP-10 Dimensions (mm): 1. Materials: Case, Cover & Pedal: Glass Filled PA66; Shaft: Stainless Steel. 2. Cable: #18AWG, 9 Wires, PVC Jacket, UL 80 C, SEE NOTE 5 300V Rated. 3. Pedal Travel: 30˚ ±3˚. - Page 6 FP-10 Dimensions cont’d 1,000±150.0 Pedal Travel Angle SEE TABLE 2 70.0 153.0 MAX 140.0...
-
Page 7: Operation
3. OPERATION FP-10 Dimensions cont’d The Model FP-10 includes the following features: • 0 – 5k potentiometer output which easily interfaces with motor controller throttle inputs and avoids the necessity of a dedicated power supply (Curtis 98191 potentiometer). • Dual return springs to ensure safe operation. A sudden reduction of pedal resistance of more than 50% indicates a single spring failure. -
Page 8: Maintenance
• The FP-10 is supplied with a 1 meter length cable which is terminated in flying leads, and a loose foot pedal. • For safety, a mechanical stop between the angular position of 26°... -
Page 9: Warranty
F.O.B. our factory. There is no further warranty or implied representation, guarantee, promise or agreement as to any Curtis Instruments product and/or component. Curtis Instruments, Inc., cannot assume responsibility or accept invoices for unauthorized repairs to its products and/or components, even though defective.
