bianco dipuro GUSTO Pro Instruction Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

c o m m e r c i a l

Table of Contents

Summary of Contents for bianco dipuro GUSTO Pro

Page 1 c o m m e r c i a l...
Page 2: Description
Description Measuring cup [1] Lid [2 ] Seal Ring [3 ] Mixing Container [4] Blades [5] [6] Blade Holde r [7] Connector for Blade Drive Lower Cover [8 ] Locking Mechanism of the [10] Sensor for Mixing Containe Mixing Container [9 ] [11] Start / Stop butto n [12] Control Panel Motor Block [13 ]...
Page 3: Table Of Contents
REQUIREMENTS OF THE INSTALLATION LOCATION ........................10 ELECTRICAL CONNECTION ................................10 CONTROL PANEL OVERVIEW ............................... 11 OPERATING PROGRAM BUTTONS ............................... 13 OPERATING GUSTO PRO ................................14 SELF RECORD PROGRAMMES ..............................15 MEASURING CUP, LID AND SEAL RING ............................16 SAFETY GUIDELINES FOR CLEANING ............................17 CLEANING THE MIXING CONTAINER (INCL.
Page 4 Contents TECHNICAL DATA ..................................33 DISPOSAL NOTE ..................................34 CONTACTS AND CUSTOMER SERVICE ............................35 INDEX ......................................36...
Page 5: Introduction
Introduction Dear Customer, We are pleased that you have decided to care for your health, with the aid of GUSTO PRO! You have bought an acknowledged quality product, and we thank you for your purchase. The green smoothies are the perfect way for healthy nutrition.
Page 6: Information About This User Manual
If the motor should switch off for that reason, the overheating protection of your GUSTO PRO is activated. Let your GUSTO PRO cool off for about 45 minutes in a well-ventilated area, afterwards you can use your GUSTO PRO as usual.
Page 7: Safety Precautions
Please observe the following safety precautions for the safe use of the device: • Check the your GUSTO PRO before the frst use for visible externally damages of the housing, electrical connection as well as the power plug. Do not operate a damaged device.
Page 8 Safety Precautions Children and frail persons must always be supervised by a person responsible for their safety when using the GUSTO PRO. • • Always store the device and the mixer attachment in a place inaccessible to children. • Always disconnect the power cord by pulling the plug from the power socket, not by pulling the power cord.
Page 9: Operating Notes
• When preparing hot drinks, soy milk or soups, please take care that the lid is closed properly and your GUSTO PRO is standing securely. It is advisable to start frst at low speed and to increase it gradually. Alternatively, you can use the Pulse mode or one of the preset programmes (bisque, see page 15).
Page 10 Unpacking Please proceed as follows to unpack your GUSTO PRO: • Remove the device and all accessories from the carton • Remove all packing material from the device and the accessories • Keep the packaging material during the warranty period, in order to pack appropriately for warranty case.
Page 11: Requirements Of The Installation Location
Before connecting, compare the technical data of the device, printed in the rating plate, including voltage and frequency, with your power supply. This data must conform, so that the GUSTO PRO is not damaged. In case of doubt ask your electrician.
Page 12 Overview Control Panel...
Page 13: Operating Program Buttons
Pulse Mode At standby mode, press to activate your GUSTO PRO to run at the highest speed. Motor will stop when the pulse key is released. Or at the program mode or manual running mode, press to temporarily running at the highest speed. After releasing the pulse key your GUSTO PRO will resume running at the original program speed.
Page 14 In order to use your GUSTO PRO, it is necessary to place on the mixing container on the motor block properly. Without the mixing container your GUSTO PRO does not start. If you put the container on the engine block, you will hear a long beep and the display as well as the buttons light up briefly.
Page 15 User can add an alternative self-written program onto each of the 5 program buttons (to be indicated in RED LED light). Press and for 2 seconds, your GUSTO PRO will enter Self Recording Mode where the 5 Program LED will start blinking. Press and select hold the program button which you need to write in the alternative program.
Page 16: Operating Gusto Pro
There are 5 factory default programs indicated by WHITE color LED light. Select your desired program by pressing the program button. The chosen program is shown by the flashing white LED light. By pressing , the remaining time and the speed level is shown at the display. Upon completion the program your GUSTO PRO stops automatically. Symbol Preset program...
Page 17: Measuring Cup, Lid And Seal Ring
You can remove the seal ring from the lid for easy cleaning. Please take care. that the seal ring is fixed back in the lid after cleaning. Safety Guideline for Cleaning This chapter provides important tips for cleaning and maintenance and care of your - GUSTO PRO. Please note the following safety guidelines before and during cleaning of your - GUSTO PRO: •...
Page 18: Cleaning The Mixing Container (Incl. Lid) And Motor Base
Cleaning of the Mixing Container (incl. Lid) and Motor Base Cleaning of the mixing container and lid Take caution when cleaning: The blades can cause injuries! The mixing container is not suitable for the dishwasher! • The mixing container and the lid can be cleaned with a brush or sponge under running water. •...
Page 19: Instructions For General Preparation
It may be that a larger piece stucks at GUSTO PRO the bottom of the mixing container. Turn off the device and try to remove the large pieces with the tamper. Sometimes bubbles are formed, which you can remove with the tamper easily. If necessary add more water.
Page 20 Technical Data - GUSTO PRO Voltage / Frequency 220 - 240 V / 50 - 60 Hz Power 1,200 Watt Motor DC Motor Mixing container 1 Liters Volume, TRITAN plastic, BPA-free, stainless steel blade (nickel free) Max. temperature 125 °C...
Page 21 Disposal of used batteries The packaging protects the device from damage during transportation. The packaging materials have been chosen with consideration of the environment and the disposal and are therefore recyclable. The return of the packaging to the material cycle reduces the generated waste and saves raw materials. Dispose of not needed ackaging materials at the collection facilities of the collection system “Green Point”...
Page 22 - GUSTO PRO Contact and Customer Service...
Page 23 Index PRESET PROGRAMMES ................................15 STANDBY MODE ..................................13 START-UP YOUR GUSTO PRO ..............................13 ENERGY SAVING MODE ................................13 MANUAL MODE ................................... 12 PULSE MODE ....................................12 CLEANING OF MIXING CONTAINER AND LID ..........................17 CLEANING THE MOTOR BASE ..............................17 SENSOR FOR MIXING CONTAINER ...............................
