- Page 1 LE40A4E1FHD LED TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN...
- Page 3 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Warranty Service Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 4 Warranty, the customer shall be charged for the cost of the repair. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
-
Page 5: Table Of Contents
Table of Contents Important Safety Instructions......................2 Safety Information........................... 3 Electrical safety........................3 What is Included/TV Placement Setup..................4 Unit and Accessories......................4 Wall Mounting........................Getting Started..........................5 Front/Back View......................... 5 Button Functions......................... 5 Connecting to External Devices....................7 Connecting external devices to your LED TV.............. 7 Install the Batteries.......................... -
Page 6: Important Safety Instructions
Important Safety Instructions • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. -
Page 7: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. -
Page 8: What Is Included/Tv Placement Setup
USER MANUAL D.MENU A - B GOTO D.TITLE ASPECT SLEEP IMPORTANT ! Base Stand WARRANTY INFORMATION INSIDE. PLEASE READ Trademark of TEAC Corporation JAPAN www.teac.com.au Remote Control 4Screws TV Set with Batteries User’s Manual TV Stand Installation/Removal 200mm 200mm Four mounting holes... -
Page 9: Getting Started
Getting Started Front/Back View Button Functions 1. POWER Button: To turn ON/OFF the TV. 2. SOURCE Button: To select the input source. 3. MENU Button: To enter menu setting page. 4. VOL-: To decrease the volume level. 5. VOL+: To increase the volume level. 6. - Page 10 PC AUDIO HDMI1 RF: Antenna connection HEADPHONES COAXIAL YPbPr: Connect to the YPbPr videooutput terminal of the DVD AUDIO IN R/L: Stereo audio input VGA: PC video input VIDEO: Video input PC AUDIO: Connect it to the audio output terminal of the PC HDMI...
-
Page 11: Connecting To External Devices
Connecting to External Devices Connecting external devices to your LED TV PC AUDIO HDMI1 Audio cable cable VHF/UHF antenna Component RF Coaxial cable cable cable TV company HDMI cable Coaxial cable Composite cable cable receiver/satellite box... - Page 12 Remote Control : Turn on the TV/Standby. : Mute or restore the sound. AUDIO : Switch the audio channel when DVD or multimedia playing. INPUT AUDIO PMODE SMODE INPUT : Press to change signal source. P.MODE : Output image mode selection. S.MODE : Setting audio options.
-
Page 13: Install The Batteries
: Eject disc. : Fast rewind playback. : Fast forward playback. D.SETUP : Open DVD mode system settings menu. : Previous file or chapter. : Next file or chapter. A-B : Press display button to repeat the play in the time of A to B. D.MENU : Display the menu of the DVD. -
Page 14: Settings
Settings Initial Setup 1. Connecting your TV on the poweroutlet; 2. Press the POWER button on the remote to turn on the TV in green for the LED light. CAUTION:Always disconnect the TV from the power outlet when the TV will not be used for a long period of time. - Page 15 Country ◄ / ► User can press button to select the country. And then press OK to enter the next step page. Quick Setup ◄ / ► User can press button to select the Quick Setup And then press OK to enter the next step page. Auto Tuning If you set the DTV type to Terrestrial,you will find the follow menu for search the channel.
-
Page 16: Select Input Source
Select Input Source Press SOURCE button to display the input source list; Press ▲/▼ button to select the input source you want to watch; Press OK button to enter the input source; MainMenu • Press MENU button to display the MAIN OSD MENU; •... -
Page 17: Picture Menu
Picture Menu The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Press ▲/▼ button to select Picture in the main menu, and then press OK button to enter. 1. - Page 18 Brightness Press ▲/▼ button to select Brightness, then press OK button to enter and press ◄ / ► button to adjust. Then press MENU button to return back the previous menu directly. Brightness Press ▲/▼ button to select Brightness, then press OK button to enter and press ◄...
-
Page 19: Sound Menu
SOUND Menu The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Press ◄ / ► button to select Sound in the main menu, and then press OK button to enter. - Page 20 Treble Press ▲/▼ button to select Treble, then press OK button to enter and press ◄ / ► button to adjust. It can only be adjusted under user mode Then press MENU button to return back the previous menu directly. Balance Press ▲/▼...
-
Page 21: Channel
Channel The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Press ◄ / ► button to select Channelin the main menu, and then press OK button to enter. 1. -
Page 22: Atv Manual Tuning
Country Press ▲/▼ button to select Country, and then press ◄ / ► button to select which area you stay. DTV Type Press ▲/▼ button to select DTV Type, then press ◄ / ► button to select. (Available DTV Type: Cable, Terrestrial) Auto Tuning Press ▲/▼... - Page 23 DTV Manual Tuning Press ▲/▼ button to select DTV Manual Tuning, and then press OK button to start the scan. DTV Settings Press ▲/▼ button to select DTV Settings, and then press OK button to enter the sub menu. User can set the local time settings, DST, LCN, subtitle and audioon this options.
-
Page 24: Applications
Applications The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Press ◄ / ► button to select Applications in the main menu, and then press OK or ► enter. PVR Menu 1. -
Page 25: System Lock
System Lock Press ▲/▼button to select System Lock, then press OK button to enter enter the sub menu with the password “0000”: System Lock Press ▲/▼button to select System Lock, then press ◄ / ► button to select ON or OFF. Parental Control Press ▲/▼button to select Parental Control, then press OK or ►... - Page 26 Change Pin Press ▲/▼ button to select Change Pin Code, then press OK to enter and Change Pin Code menu will appear as follows: Input old password at “Old Password”, (if the old password is incorrect, the password will not be allowed to modify.) Input new password at “New Password”.
-
Page 27: Disk Setup
Recoder Press ◄ / ► button to select Recoder then press OK to enterrecord. The function is same as the hot key of REC. Time Shift Press ◄ / ► button to select Time Shift then press OK to time shift. PVR File List Press ◄... -
Page 28: Setup
Disk Press ▲/▼ button to select CEC, then press ◄ / ► button to select ON or OFF. SETUP The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Press ◄... -
Page 29: Guide
Blue Screen Press ▲/▼ button to select Blue Screen, then press ◄ / ► to select On or Off. Then press OK to confirm. Sleep Timer Press ▲/▼ button to select Sleep Timer, and then Press ◄ / ►button to select. (Available Sleep Timer: 00:15, 00:30, 01:00, 01:30, 02:00, 03:00, off), then press OK button to confirm. -
Page 30: Hotel Mode
Hotel Mode Press ▲/▼ button to select Hotel Mode then press OK to enterthe sub menu will appear as follows: 1.How to enter and exit the hotelmode menu: • Enter：You can enter the hotel mode menu by the follow steps： Press password "9173"... - Page 31 Menory How to Direct Record 1. In the DTV source,you can start record function by press the “REC” key while program playing. Before that, you have to make sure the USB storage device is inserted and the device checking and Initialization is done. If you press “REC”...
- Page 32 2. You can press "STOP" key to stop record function after confirm How to Time shift 1. In the DTV source,you can start timeshift function by press the “PLAY/PAUSE” key while program playing. Before that, you have to make sure the USB storage device is inserted and the device checking and Initialization is done.
-
Page 33: Media Operation
MEDIA OPERATION The picture is for a reference only; the actual item is the standard. Note: Before operation MEDIA menu, Plug in USB device or memory card, then press SOURCE button to set the Source to Media. Press ▲/▼ button to select MEDIA in the Source Menu, and then press OK or ► to enter. - Page 34 Note :If you want to set the other function,please press the MENU. Movie The picture is for a reference only; the actual item is the standard. Press ◄ / ►button to select Movie in the main menu, then press OK button to enter. Press EXIT button to return back to the previous menu.
- Page 35 Music The picture is for a reference only; the actual item is the standard. Press ◄ / ►button to select Music in the main menu, and then press OK button to enter. Press EXIT button to return back to the previous menu. Press ▲/▼button to select the sonny you want to listen, and then press OK or ►II or ►...
-
Page 36: Troubleshooting
Troubleshooting Carry out the problem-solving measures described in the following section before contacting customer support. Turn off the device immediately as soon as you suspect a malfunction and unplug the power plug. Do not attempt to repair the device yourself. Other Notes: Static or other external interfere may cause the player to behave abnormally. -
Page 37: Specifications
Specifications Specifications TV System DVB-T- T2 Maximum 1920X1080 Brightness 250 cd/m2 Static Contrast 5000:1 Response Time 8.5ms Consumption Power Supply AC 100-240V- 50/60Hz Connectivity Ypbpr PC Video Input (VGA) PC Audio Input HDMl input RF Antenna Input Headphones Output Coaxial Output Data Interface USB2.0 DC5V/500mA Supported System Files... - Page 38 In the event of a product failure within the warranty period, please call the TEAC Warranty Service Hotline 1300 553 315 Between Monday to Friday - 8.30AM to 5PM AEST *Please have your purchase receipt and the product’s serial number ready For other enquiries and support please visit www.teac.com.au...
