Summary of Contents for Barco GRAPHICS 1208S R9000893
- Page 1 GRAPHICS 1208s R9000893 R9000896 OWNER'S MANUAL...
- Page 2 BARCO PROJECTION SYSTEMS Date : 220197 GRAPHICS R9000893 R9000896 OWNER'S MANUAL 1208s Art. No. : R5975847...
- Page 3 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, January 1997. All rights reserved. Trademarks are the rights of their respective owners. Printed in Belgium BARCO nv/Projection Systems Noordlaan 5...
-
Page 4: Table Of Contents
Table of contents ... i Safety instructions ... 1-1 On safety ... 1-1 On installation ... 1-2 On servicing ... 1-2 On cleaning ... 1-2 On repacking ... 1-2 On illumination ... 1-2 Location and Functions of Control ... 2-1 Rear panel terminology ... - Page 5 Table of Contents Blanking Adjustments ... 6-15 Convergence Adjustment ... 6-16 Service mode ... 7-1 Starting up the Service mode..7-1 Overview flowchart 'Service' mode..7-1 Identification ... 7-2 Copy a block ... 7-2 Deletion of blocks ... 7-3 Deleting block by block ...
-
Page 6: Safety Instructions
OWNER’S RECORD The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided below. Refer to them whenever you call upon your BARCO dealer regarding this product. PART NUMBER : SER. -
Page 7: On Installation
Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replacement parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards. -
Page 8: Location And Functions Of Control
LOCATION AND FUNCTION OF CONTROLS REAR PANEL TERMINOLOGY PORT 4/5 (RGB - HV) Comp/H sync V sync PORT 6 REMOTE PORT 3 COMMUNICATION Communication Port (800 peripherals) * allows communication between the RCVDS switcher and the projector. * allows connection of a remote IR receiver unit to the projector. -
Page 9: Rcu Control Panel Terminology
Location and Functions of Control EXIT ENTER STBY PAUSE TEXT SHARPNESS TINT COLOR BRIGHTNESS CONTRAST b. RCU control panel terminology This remote control includes a battery powered infrared (IR) transmit- ter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set-up. -
Page 10: Connections
CONNECTIONS AC Power (mains) Cord Connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the backside of the projector. Power Check Power voltage indication on sticker on the back side of the projector. The power voltage is indicated by the art. -
Page 11: Signal Input Connection To The Projector
Connections When starting up the projector, with the power switch or via the stand-by key, the projector can start up in two ways if the "CRT run in" cycle option is switched OFF. - full white image (projector warm up) or - immediately image display. -
Page 12: Connecting A Composite Video Source To Port 1
Connecting a Composite Video source to port 1. Composite video signals from a VCR, OFF air signal decoder, etc.. Video input selection : with the RCU or the build in RCU : press digit button 1 * Note : if using the loop-through Video output, then set the Termination Switch to the "OFF"... -
Page 13: Connecting A Rgb Analog Source To Port 3
Always use an interface when a computer and local monitor have to be connected to the projector. See 'Connecting a RGB Analog source to port 3' for a list of BARCO interfaces which can be applied. RGB input selection :... -
Page 14: Connecting A Rgb Analog Source With Tri-Level Sync To Port 4/5.(Option)
Connecting a RGB Analog source with Tri-level sync to port 4/5. (option) RGB analog input terminals with Tri level sync input or with Tri-level sync on green. The projector detects automatically where the sync signal is located. RGB input selection : (RG3sB : R, G, B signals with automatic Tri-level sync detection) with the RCU or the build in RCU : press digit button 7 Connecting a Component Video source to... -
Page 15: Peripheral Equipment
Connections PERIPHERAL EQUIPMENT Connecting a RCVDS 05 switcher to the BARCOGRAPHICS 1208s - Up to 20 inputs with the RCVDS 05 switcher and up to 90 inputs when 10 RCVDS switchers are linked via the expansion modules. - Serial communication with the projector. - Remote control buttons on the RCVDS to control the BARCOGRAPHICS 1208s (source selection and analog settings) - The selected source number will be displayed on a 2 digit display... -
Page 16: Controlling
CONTROLLING Caution : Do not display a stationary image with full brightness and contrast for longer than 20 min., otherwise you risk damage to the CRT's. Battery installation in the RCU. A new battery (not yet installed to save the battery life) is delivered inside the plastic bag with the power cord. -
Page 17: How To Use Your Rcu
Every projector requires an individual address between 0 and 255 which is set with hardware DIP switches inside the projector. To change that address, contact a BARCO authorized technician. b. How to control the projector. The projector's address may be set to any value between 0 and 255. -
Page 18: How To Display A Projector Address
How to display a projector address? Press the ADDRESS key (recessed key on the RCU) with a pencil. The projector's address will be displayed in a 'Text box'. This text box disappears after a few seconds. To continue using your RCU, it is necessary to enter the same address with the digit buttons (address between 0 and 9). -
Page 19: Analog Picture Controls
Controlling Analog Picture Controls The analog picture controls can be adjusted with the RCU. The control keys are located on the lower right side of the key panel of the RCU and indicated with the name of the control and an icon. When an analog picture control is pressed, a text box with bar scale and the function name of the control, e.g. -
Page 20: Start Up Of The Adjustment Mode
RISK OF ELECTRICAL SHOCK NO USER ADJUSTABLE PARTS INSIDE THE FOLLOWING INSTALLATION MENUS ARE RESERVED TO, AND TO BE PERFORMED ONLY BY BARCO PERSONNEL, OR BARCO AUTHORIZED DEALERS IF QUALIFIED, PRESS <ENTER> TO CONTINUE, OR IF NOT, <EXIT> TO RETURN. - Page 21 (Password protection is only available when the password DIP switch on the controller module is in the ON position. Contact a BARCO authorized technician when no password is requested during the adjustment procedure and password protection is desired.) Your password contains 4 digits.
-
Page 22: Random Access Adjustment Mode
RANDOM ACCESS ADJUSTMENT MODE Starting-Up the Random Access Adjustment mode. Push the control stick forward or backward to highlight "RANDOM ACCESS" and then press ENTER . Some items in the Random access mode are password protected (when the password function is enabled). Enter your password to continue. All other password protected items are now also available if you stay in the adjustment mode. - Page 23 Random Access Adjustment Mode From next page RANDOM ACCESS ADJUSTMENT MODE SETUP PATTERN SELECTION From next page H SIZE V LINEARITY V SIZE BLANKING COARSE ADJUSTMENT CONVERGENCE RED ON GREEN BLUE ON GREEN FINE ADJUSTMENT GREEN ONLY RED ON GREEN BLUE ON GREEN FOCUSING GREEN...
-
Page 24: Selecting Setup Pattern
Selecting Setup Pattern If an external source is connected to the projector, this menu will be displayed. Push the control stick forward or backward to highlight the desired setup pattern and then press ENTER . Genlocked pattern : internally generated cross hatch pattern, locked on the external source. Internal # pattern : internally generated cross hatch pattern and locked on internal generated sync signals. -
Page 25: Random Access Adjustment Mode Selection Menu
Random Access Adjustment Mode Random access adjustment mode selection menu. This is the main menu for the Random Access adjustment mode. Through this menu, the following adjustments and features are accessible : - Picture Tuning Enhanced Blue (only for RGB) Sync slow/fast(video/s-video) Color Balance - Focusing... -
Page 26: Sync Fast/Slow Adjustment
Sync Fast/Slow Adjustment The sync function is used to minimize horizontal jittering or tearing at the top to the displayed image. Highlight SYNC by pushing the control stick forward or backward and press ENTER to toggle between FAST and SLOW. Note: SYNC is normally used in the SLOW position. -
Page 27: Port 2 : Video Or S-Video
Random Access Adjustment Mode Port 2 : Video or S-Video Port 2 can be used as a Video or S-Video input. Highlight Port 2 by pushing the control stick forward or backward and press ENTER to toggle between VIDEO and S-VIDEO. Line Doubler (option) Line doubling is only possible for Video, S-Video, Component Video images on standard line frequency and RGB signals on 15... -
Page 28: Focusing
Focusing Before starting the 'focusing' adjustment, be sure the lenses are correctly focused. Push the control stick forward or backward to select 'Focusing' and press ENTER . ENTER continues to the Focusing color select menu. EXIT returns to Internal Crosshatch Selection or Setup Pattern Selection menu. -
Page 29: Geometry Adjustments
Random Access Adjustment Mode Geometry Adjustments The geometry adjustments have to be done only on the green image. These adjustments are automatically implemented for the other color images : Left-right (EW) and Top-Bottom Corrections, Blanking, Horizontal Amplitude, Vertical Amplitude, Vertical Linearity and Horizontal Phase. -
Page 30: Raster Shift Adjustment
Note : Horizontal and Vertical shifts for Red and Blue should be end up with a setting close to 50%. If these settings are significantly greater or lesser than 50%, then contact a BARCO authorized service technician. 5975847 BARCOGRAPHICS 1208S 220197 Random Access Adjustment Mode... -
Page 31: Left-Right (East-West) Adjustments
Random Access Adjustment Mode Left-Right (east-west) Adjustments Left-right adjustments affect only the vertical lines of the projected image. Only the green image is displayed while making left-right adjustments. The red and blue images will automatically be corrected in the same manner. Convergence corrections are automatically disabled for the duration of these adjustments. -
Page 32: Seagull Correction
Seagull correction Use this correction only if, after adjusting the vertical lines with the side bow or side keystone, still a 'S' deformation is visible on the left and the right side of the image. The default value on the bar scale for this correction is 50. Push the control stick forward or backward to highlight SEAGULL CORRECTION on the Left-Right menu and then press ENTER. -
Page 33: Top-Bottom (North-South) Adjustments
Random Access Adjustment Mode Top-Bottom (north-south) Adjustments Top-Bottom and center adjustments affect only the horizontal lines of the projected image. To start up the Top-Bottom and center corrections, follow the next procedure : Push the control stick forward or backward to highlight TOP-BOT- TOM (N/S) on the geometry menu and then press ENTER . -
Page 34: Seagull Correction
Seagull Correction Use this correction after the image has been adjusted with top and bottom bow and keystone. If still a deformation (like a seagull) on top and bottom of the image is visible, proceed to the seagull correction. Due to interaction, it is possible that the top and bottom bow have to be readjusted after adjusting the seagull correction to obtain an improved image. -
Page 35: Vertical Linearity Adjustment
Random Access Adjustment Mode Vertical Linearity Adjustment The vertical linearity adjustment function corrects for vertical non- linearities which extend from the center of the image to the top and bottom of the image. Push the control stick forward or backward to highlight V LINEARITY on the Geometry menu and then press ENTER. -
Page 36: Blanking Adjustments
Blanking Adjustments Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). A 0% on the bar scale indicates no blanking. -
Page 37: Convergence Adjustment
Random Access Adjustment Mode Convergence Adjustment Convergence adjustments affect both the horizontal and vertical lines of the setup pattern. These adjustments are performed on the red image while superimposed on the green image and then on the blue image while superimposed on the green image. Start with the Coarse convergence adjustments and finalise with the Fine convergence adjustment. -
Page 38: Fine Convergence Adjustment
Vertical corners Highlight 'Vertical corners' and press ENTER to start the adjustment. To make a coarse adjustment of the red or blue horizontal lines in zone 10, 14, 18 and 22 simultaneously. Hint : - adjust until the red or the blue horizontal lines are on the green lines or as close as possible to the green lines. -
Page 39: Service Mode
SERVICE MODE Starting up the Service mode. Use the control stick to highlight 'Service' and then press ENTER . Some items in the Service mode are password protected (when the password function is active). Enter your password to continue. All other password protected items are now also free available if you stay in the adjustment mode. -
Page 40: Identification
Service Mode Identification Highlight 'Identification' with the control stick and press ENTER . The 'Identification' screen gives information concerning : - projector address. To change the address of your projector, contact a qualified service technician. - software version. - configuration. possible installations : * front-ceiling * front-table... -
Page 41: Deletion Of Blocks
Deletion of blocks This item is password protected. The delete function is used to clear all data (settings) from an adjustment block. A delete can be given : - block by block - for all blocks. Deleting block by block The delete a block function deletes the settings of a selected block. -
Page 42: Change Password
Service Mode Change password This item is password protected. Highlight 'change password' with the control stick and press ENTER . The current password is displayed. The new password must consist of 4 digits between 0 and 9. Push the control stick to the left or to the right to select the digits to be changed. -
Page 43: Set To Midposition
Set to midposition Item is password protected. Highlight 'set to midposition' with the control stick and press ENTER to set all settings to their midposition. A confirmation menu will be displayed first. ENTER will set all settings to their midposition. EXIT will cancel the operation to set all settings to their midposition. -
Page 44: Dynamic Astigmatism (Spot Shape Adjustment)
Service Mode When undo is pressed all convergence settings are reset to the previous settings. Dynamic Astigmatism (spot shape adjustment) The spot shape adjustments correct the spot shape in 8 different areas on the screen and that for the three colors separately. The spot shape is adjusted according to the axial axises and the diagonal axises when using the arrow keys on the RCU. -
Page 45: G2 Adjust
A safety notice will be displayed on the screen as it is necessary to open the top cover to adjust the G2. 'G2 adjustment should be performed by BARCO personnel, or BARCO authorized dealers'. If you are qualified, press ENTER to continue. If not qualified, press EXIT to return to the Service mode main menu. -
Page 46: Projector Warm Up
Service Mode Projector Warm Up Highlight 'Projector Warm Up' by pushing the control stick forward or backward and press ENTER to select the projector warm up menu. The ON/OFF option can be toggled with the ENTER key. When in the ON position (and the CRT run in cycle is OFF), the projector can start up with a warm up period of 20 minutes. - Page 47 MESSAGES, WARNINGS AND FAILURE CODES When selecting a new source, information about this source will SOURCE 01 be displayed on the screen. Fh= 15.6 kHz Source number, horizontal and Fv= 050 Hz vertical frequencies of the dis- played source. SOURCE 01 Announcement of the selected Fh= 15.6 kHz source.
- Page 48 Messages, warnings and failure codes WARNING : Projector will switch to 'stand-by' when the RCVDS is no longer go to available. stand by WARNING : The entered frequency or ap- invalid plied frequency of the source is frequency out of the projector's range. input WARNING : Adjustment settings are lost.
-
Page 49: Options
BARCO's digitally controlled large screen projectors. It offers the possibility to connect and switch up to 5 different Video sources, 3 different S-Video sources and 1 RGB Analog source to a BARCO projector. In addition, the audio signal proper to the source, can be switched to an audio amplifier. - Page 50 The use of the orbiting kit is described in appendix A. Order number : R9827780 Line Doubler Kit BARCO's line doubler kit consists of a video decoder with a three-line adaptive Comb filter, an enhancement circuit and the line doubler itself.
- Page 51 Orbiting Mode Toggle Switches The orbiting module is provided with a three pin connector for connection with the BARCO's BCl link option module, used in multiple projector installations. For Orbiting, one projector operates as master wheras the others operate as slave.
-
Page 52: Appendix A : Orbiting
Orbiting Orbiting Speed Toggle (only in MASTER Orbiting) Highlight 'SPEED : SLOW' with the control stick and press ENTER to set the ORBITING SPEED to Fast. Highlight 'SPEED : FAST' with the control stick and press ENTER to set the ORBITING SPEED to Slow ENTER continues to Set up Orbiting EXIT returns to path selection menu ADJUST returns to operational mode. - Page 53 Adjustment procedure multiple projector installations : Inportant : to allow corrections in the deviation alignments of the slave projectors, never adjust the deviations of the master projector to its maximum. Default setting of the Master projectorn see 'Stand-Alone projector'. Highlight 'ADJUST DEVIATION' by pushing the control stick forward or backward and press ENTER .
- Page 54 Adjustment Blocks and Source Numbers 90-99 ADJUSTMENT BLOCKS AND SOURCE NUMBERS 90 - 99 Adjustment Blocks (memory blocks) As the projector is digitally controlled, all geometry and convergence adjustments are stored in the projector’s memory as numeric values. These numeric values are used to control digital potentiometers which in turn, control the projector. Each source connected to the projector has a unique set of adjustment data which is automatically downloaded into the projector’s digital potentiometers once the source has been selected.
- Page 55 INSERT CARD 5975847 BARCOGRAPHICS 1208S 220197 INPUT SOURCES INPUT SOURCES PROJECTOR PROJECTOR INPUT SOURCES INPUT SOURCES RCVDS RCVDS Insert Card...
