- Page 1 Instruction Manual AH68-01133B DIGITAL HOME THEATER SYSTEM HT-DL70D HT-DL80D HT-DL70D HT-DL80D COMPACT COMPACT DIGITAL AUDIO DIGITAL VIDEO V I D E O...
-
Page 2: Safety Warnings
Safety Warnings Use of controls, adjustments or performance of procedures other CLASS 1 LASER PRODUCT than those specified herein may result in hazardous radiation KLASSE 1 LASER PRODUKT exposure. LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION-INVISIBLE LASER RADIATION WHEN OPEN CAUTION RISK OF ELECTRIC SHOCK. -
Page 3: Table Of Contents
DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie theater or concert V I D E O hall. -
Page 4: Description
Description Front Panel HT-DL70D Function button Play/Pause ( ) button Power ( ) button Stop ( ) button Open/Close button Disc Tray Standby indicator Tuning Down & Skip ( ) button Tuning Up & Skip ( ) button HT-DL80D Function button... -
Page 5: Remote Control Unit
Remote Control Unit DVD POWER button DVD button TUNER TUNER button Band TUNER Open/Clse Band AUX button Title Menu Remain Step Title Audio Subtitle Repeat Repeat Title button MO/ST A<->B Menu Menu button Display Return Go To Zoom Subtitle Subtitle button DVD/CD/TUNER Audio Audio... -
Page 6: Connecting The Speakers
Connecting the Speakers • Connect the satellite speakers, center speaker, and subwoofer to the terminals on the rear panel using speaker cords supplied. • Insert the end of the speaker cord into the terminal. Match the polarity (colors): Red (+) to red (+) and black (–) to black (–). -
Page 7: Connecting The Fm And Am (Mw/Lw) Antennas
Connecting the FM and AM If FM reception is poor, connect outdoor FM antenna (not supplied). ANTENNA FM Antenna (supplied) R-REAR-L WOOFER CENTER R-FRONT-L SPEAKERS SPEAKERS Cooling fan (See “About Cooling Fan” below.) FM antenna connection 1. Connect the FM antenna supplied to the FM 75 COAXIAL terminal. -
Page 8: Connecting Your System To The Power Supply
Connecting your System to the Power Supply The main lead must be plugged into an appropriate socket. Before plugging your system into an AC outlet, you must check the voltage. 1. Plug the AC Cord on the rear of the system into an appropriate outlet. 2. -
Page 9: Dvd Playback
DVD Playback Press the Open/Close( to open the disc tray. • The button is located on the Front Panel of the player (not on the remote). Insert a disc. • Place a disc gently into the tray with the disc’s label facing up. Press the Open/Close( again to close the disc tray. -
Page 10: Forward/Reverse Searching
Forward/Reverse Searching During playback, you can search quickly through a chapter or track for a specific scene or tune. Multi-Speed Playback Press the button. Each time the button is pressed PLAY Skipping through a Chapter Press the button. • Each time the button is pressed during playback, it moves to the next or previous chapter and plays it. -
Page 11: Repeat Playback
Repeat Playback Repeat playback allows you to repeat a chapter, title, or track. Repeat Playing Repeatedly Press the Repeat button. Each time the Repeat button is pressed • Repeat playback operation is not possible with version 2.0 VCD discs if PBC is turned on. To operate this feature, press the MENU button, and then select "PBC OFF". -
Page 12: Program Playback
Program Playback Use this function to program chapters or tracks in a particular order. To Program Tracks in a particular order Press the Program button. Press the Enter button, then use the Number buttons to select the desired title. • You can also use the Left/Right ) button. -
Page 13: Selecting The Audio Language/Subtitle Language
Selecting the Audio Language/Subtitle Language Audio Selecting the Audio Language MO/ST Press the Audio button. • Depending on the number of languages recorded on a DVD disc, a different audio language (ENGLISH, SPANISH, FRENCH, etc.) is selected each time the button is pressed. V I D E O •... -
Page 14: Mp3 Playback
MP3 Playback This system has a built-in MP3 decoder. You can play back MP3 tracks (files)recorded on CD-Rs, CD-RWs, and CD-ROMs. Starting Playback • It is recommended you turn on your TV when playing back an MP3 disc. Press the Open/Close( ) button to load a disc. -
Page 15: System Setup
System Setup You can use the DVD player's Setup function to select the TV screen ratio, rating limit, or digital output mode. To Set up the System From the stop mode, press Press the Left/Right ( the Setup button. button to select the system. LANGUAGES SYSTEM LANGUAGES... -
Page 16: Setting Up The Language Features
Setting up the Language Features Using the DVD player's Setup function, you can customize the Menu Language, Subtitle Language, and Disc Menu Language. To set up the language feature Press the Up/Down ( Press the Setup button from the stop mode. the desired item. -
Page 17: Speaker Setup
Speaker Setup Setting up Speaker Mode and Delay Time Press the SPK Mode button. • Each time the button is pressed, a different mode selection is displayed on the front panel display as shown below. DIGITAL F SP SMALL Front speaker: Small DIGITAL C SP SMALL Center speaker: Small... - Page 18 Speaker Setup To set up Speaker Balance Use the Left/Right ( Press the Sound Edit button. lower the output level of the chosen speaker(s). • Each time the button is pressed the selection switches as shown below. Example: 5.1CH Sound Setup PRO LOGIC D I G I T A L OFF, range of –...
-
Page 19: Creating Realistic Sound Fields
Creating Realistic Sound Fields You can use the following surround to reproduce a realistic sound field. • Digital Multichannel Surround —Dolby Digital and DTS Digital Surround • Dolby Pro Logic Dolby Digital and DTS Digital Surround To enjoy surround effectively, all the speakers need to be connected and activated. Dolby Digital Used to reproduce multichannel sound tracks of the software encoded with Dolby Digital ( Dolby Digital encoding method (discrete 5.1 channel digital audio format)records and digitally compresses the left front... -
Page 20: Listening To The Radio
Listening to the Radio You can listen to the chosen band (FM, MW or LW broadcast stations) by using either the automatic tuning or manual tuning operation. Remote Press the Tuner(Band) Control button. Unit • The selection toggles back Auto Station 1 and forth between "FM"... -
Page 21: About Rds Broadcasting
About RDS broadcasting Using the RDS (Radio Data System) to receive FM stations RDS allows FM stations to send an additional signal along with their regular program signals. For example, the stations send their station names, as well as information about what type of program they broadcast, such as sports or music,etc. -
Page 22: Sleep Function
Sleep Function Sleep To set up Sleep Press the Sleep button. • Each time the button is pressed the selection toggles as follows: SLEEP 10 SLEEP 20 You can set the sleep time so that SLEEP 30 SLEEP 60 SLEEP 90 the unit powers off automatically SLEEP 120 SLEEP 150... -
Page 23: Cautions On Handling And Storing Discs
Problem • Is the TV power turned on? • Are the video cables properly connected? • The disc revolves but no • Is it the player in PAUSE mode? picture appears. • Is there any dirt on the disc, or is the disc damaged? •... -
Page 24: Disc Type And Protection
Disc Type and Protection Usable Discs Recording Disc Types Marks Types Audio + Video V I D E O COMPACT VIDEO-CD Audio + Video DIGITAL VIDEO COMPACT AUDIO-CD Audio DIGITAL AUDIO Dolby Digital DTS Disc Digital Audio Stereo disc disc disc Disc Size Max. -
Page 25: Reference
Reference Note on Terminology Recorded onto some DVD discs are scenes which have been simultaneously shot from a number ANGLE of different angles (the same scene is shot from the front, from the left , from the right , etc.). With such discs, the Angle button can be used to change the angle of view for specific scenes.
