Panasonic Lumix DC-GX9 Quick Manual

ENGLISH
Digital Camera
Model No.
DVQW1296ZA
Quick Guide for 4K Photo
Catching the moment you really want ([4K Burst] / [4K Burst(S/S)] / [4K Pre-Burst])
You can take burst pictures of approximately 8 million pixels with a burst rate of 30 fps. You can select and save a frame from the burst file.
1
Recording with the 4K Photo function
1 Press [ ] button ( )
2 Press to select the 4K photo icon and press
3 Press to select the recording method and press [MENU/SET]
For capturing the best shot of a fast-moving subject (e.g., sports, aeroplanes, trains)
[4K Burst]
Burst recording is performed while the shutter button is pressed and held. The shutter sound
will be heard repeatedly.
1
Press the shutter button halfway
2
Press and hold the shutter button fully for as long as you want to
perform recording
●
Recording will start approximately 0.5 seconds after you press the shutter button fully. Therefore, press
the button fully slightly in advance.
For capturing unpredictable photo opportunities (e.g., plants, animals, children)
[4K Burst(S/S)]
Burst recording starts when the shutter button is pressed and stops when pressed again.
Start and stop tones will be heard. "S/S" is an abbreviation of "Start/Stop".
1
Press the shutter button fully
2
Press the shutter button fully again
●
When you press the [Fn1] button while recording, you can add a marker.
When selecting and saving pictures from a 4K burst file, you can skip to the positions where you added
markers.
For recording as needed whenever a photo opportunity arises (e.g., the moment when a
ball is thrown)
[4K Pre-Burst]
Burst recording is performed for approximately 1 second before and after the moment that the
shutter button is pressed. The shutter sound will be heard only once.
1 Press the shutter button fully
●
In situations where you want to lock focus and exposure, such as when the subject is not at the
center, use [AF/AE Lock].
Setting Pre-Burst Recording ([4K Burst]/[4K Burst(S/S)])
→ [Rec] → [4K PHOTO] → [Pre-Burst Recording] → [ON]
The camera starts recording approximately 1 second before the shutter button is pressed fully, so you will not miss a photo opportunity.
Setting Loop Recording ([4K Burst(S/S)])
→ [Rec] → [4K PHOTO] → [Loop Recording(4K PHOTO)] → [ON]
You can perform recording while deleting the oldest recorded data, allowing you to keep on recording while waiting for a photo opportunity without replacing the card.
●
Once you start recording, the 4K burst file will be recorded and divided approximately every 2 minutes. Approximately the last 10 minutes (up to approximately 12 minutes)
will be saved. The preceding part will be deleted.
■
2
To cancel the 4K Photo functions: In step , select [ ] ([Single]) or [
●
Burst pictures are saved as a single 4K burst file in the MP4 format.
●
Use a UHS Speed Class 3 card.
●
When recording, the angle of view becomes narrower.
●
If you are using Auto Focus, continuous AF will work while recording. Focus will be adjusted continuously.
●
You can reduce the blur of the subject by setting a faster shutter speed. Approximate shutter speed for outdoor recording in fine weather conditions: 1/1000 seconds or faster.
●
4K burst file will be recorded and played back in separate files in the following cases. (You can continue recording without interruption.)
• When using an SDHC memory card: If the file size exceeds 4 GB
• When using an SDXC memory card: If the continuous recording time exceeds 3 hours and 4 minutes or if the file size exceeds 96 GB
●
If the surrounding temperature is high or 4K photos are recorded continuously, [
down.
●
When [ ] ([4K Pre-Burst]) or [Pre-Burst Recording] is set, the battery drains faster and the camera temperature rises.
Select [ ] ([4K Pre-Burst]) or [Pre-Burst Recording] only when recording.
DC-GX9
] .
] may be displayed and recording may be stopped halfway through. Wait until the camera cools
2
Selecting pictures from 4K burst file and saving
Markers have been set by the camera automatically on a scene in which a face or the movement of a subject is detected during recording, for example, at the scene when a vehicle
passes by or a person turns around. (Auto Marking)
1
Select a picture with the [
●
In the case of recording with [
2 Drag the slide bar to perform rough scene selection
●
You can skip to a marked position by touching the marker.
White marker: Manually set marker / Green marker: Marker set by the camera automatically
3 Drag to select the frame you want to save as a picture
4 Touch [ ] to save the picture
●
The selected picture will be saved as a new picture in the JPEG format separate from the 4K burst file.
Shutter button
Showing movement by combining a sequence of pictures ([Sequence Composition])
1 Select [Sequence Composition] from the [Playback] menu
2 Use to select the 4K burst files and press [MENU/SET]
3
Select frames to combine (from 3 to 40 frames)
4 Press to select [Save], and then press [MENU/SET]
5 Select [Yes] at the confirmation screen and press [MENU/SET]
Press and hold
Recording is performed
Adjusting the focus after recording ([Post Focus] / [Focus Stacking])
You can record 4K burst pictures while changing the focus point and then select a focus point after recording.
Recording using [Post Focus]
Start (First)
Stop (Second)
Recording is performed ●
We recommend using a tripod to perform [Focus Stacking].
1 Press [ ] button
2 Press to select [ON] and press [MENU/SET]
3
Determine the composition and press the shutter button halfway
●
Do not change the composition or the distance to subject before completion of recording.
4 Press the shutter button fully to start recording
●
When the recording progress bar disappears, recording automatically ends.
Approximately 1 second ■
To cancel [Post Focus]: Select [OFF] in step
Recording is performed
Selecting a focus point ([Post Focus])
1 On the playback screen, select the
image with the [
2
Touch the focus point
●
If there are no pictures with the focus on the
selected point, a red frame will be displayed, and
pictures cannot be saved.
●
To enlarge the display, touch [
You can make fine adjustments to the focus by
dragging the slide bar during enlarged display.
3 Touch [ ] to save the picture
●
The selected picture will be saved as a new
separate file in the JPEG format.
] on the playback screen, and press
3
] ([4K Pre-Burst]), proceed to the step .
2 .
Increasing the focus range ([Focus Stacking])
1 Touch [
([Post Focus])"
2 Choose a stacking method and touch it
] icon and press
[Auto Merging] / [Range Merging]
3
(When selecting [Range Merging])
Touch the focus point
●
Select positions at two or more points.
●
Focus points between the selected two positions
will be selected.
●
Positions that cannot be selected, or that would
].
produce an unnatural result will be grayed out.
●
Touch a position again to deselect it.
4 Touch [
●
The picture will be saved in JPEG format.
] on screen in step 2 of "Selecting a focus point
Set/Cancel Set/Cancel
Reset Reset
] to combine and save the picture
