Summary of Contents for Samsung DW21G5
-
Page 1: Teletext Function
DVD TELEVISION DS21G5 DW21G5 Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. FULL FLAT SCREEN DVD / VIDEO-CD / CD / MP3 ON-SCREEN MENUS TELETEXT FUNCTION (depending on the model) -
Page 2: Safety Instructions
Safety Instructions N Do not install the television in a confined space such as a book case or similar unit. Place on a stable stand or table. N Do not expose the television to extreme temperature conditions or to extreme humidity conditions. N Adequate ventilation is essential to prevent failure of electrical components. -
Page 3: Table Of Contents
N Foreword Safety Instructions...2 Caution ...2 Viewing of the Television ...4 Infrared Remote Control ...5 N Connecting and Preparing Your Television Connecting the Aerial or Cable Television Network ...6 Connecting a Decoder...6 Connecting to the Audio/Video Input/Outputs ...7 Connecting to the RCA Input...7 Connecting to the Audio Output (depending on the model) ...7 Connecting Headphones...8 Inserting the Batteries in the Remote Control ...8... -
Page 4: Viewing Of The Television
Viewing of the Television AUDIO INPUT CONNECTORS VIDEO INPUT CONNECTOR HEADPHONE JACK Rear of the TV MENU DISPLAY VOLUME ADJUSTMENT STAND-BY SKIP/SEARCH INDICATOR (TITLE/CHAPTER/TRACK) REMOTE CONTROL SENSOR PLAY/PAUSE 75Ω COAXIAL CONNECTOR FOR AERIAL/CABLE NETWORK RCA AUDIO/VIDEO INPUT/OUTPUT CONNECTORS OPTION DIGITAL AUDIO OUTPUTS CHANNEL SELECTION TELEVISION ON/OFF STOP... -
Page 5: Infrared Remote Control
Infrared Remote Control TELEVISION STANDBY NUMERIC BUTTONS SELECT A CHANNEL STORED AT PROGRAMME POSITION TEN OR HIGHER VOLUME INCREASE TEMPORARY SOUND SWITCH OFF VOLUME DECREASE PICTURE EFFECT SELECTION SOUND EFFECT SELECTION SEARCH BACKWARD THROUGH A DISC/ STOP DISC SKIP THE TITLE, CHAPTER, OR TRACK BRINGS UP THE DISC MENU MENU DISPLAY CHANGE CONFIRMATION... -
Page 6: Connecting The Aerial Or Cable Television Network
Connecting the Aerial or Cable Television Network Rear of the TV option Cable Television Network Connecting a Decoder Rear of the TV DECODER To view television channels correctly, a signal must be received by the set from one of the following sources: N An outdoor aerial N A cable television network Connect the aerial or network input cable to the 75Ω... -
Page 7: Connecting To The Audio/Video Input/Outputs
Connecting to the Audio/Video Input/Outputs ➢ The A/V connectors are used for equipment with an RGB output, such as VCRs, video game devices, video disc players, and camcorders. Rear of the TV Connecting to the RCA Input ➢ The RCA connectors are used for equipment, such as VCRs, camcorders, video disc players, and video game devices. -
Page 8: Connecting Headphones
Connecting Headphones Side of the TV Inserting the Batteries in the Remote Control You can connect a set of headphones to your television if you wish to watch a television programme without disturbing the other people in the room. Plug a set of headphones into the 3.5 mm mini-jack socket on the television panel. -
Page 9: Switching Your Television On And Off
Switching Your Television On and Off The mains lead is attached to the rear of your television. Plug the mains lead into an appropriate socket. Press the ON/OFF button ( Result: The Standby indicator lights up on the front panel. Press the POWER button ( television on. -
Page 10: Becoming Familiar With The Remote Control
Becoming Familiar with the Remote Control POWER MUTE INPUT S.STD P.STD AUDIO TV/TEXT OPEN RETURN /CLOSE The remote control is used mainly to: N Change channels and adjust the volume N Set up the television using the on-screen menu system The following table presents the most frequently used buttons and their functions. -
Page 11: Displaying Information On The Screen
Displaying Information on the Screen You can display various types of information on the screen to help you use your television. Press the DISPLAY button to display the information. To remove the information from the screen, press the DISPLAY Choosing Your Language When you start using your television for the first time, you must select the language which will be used for displaying menus and indications. -
Page 12: Storing The Channels Automatically
Storing the Channels Automatically MENU PICTURE SOUND CHANNEL FUNCTION ADJUST SELECT CHANNEL MANUAL TUNE AUTO TUNE ADJUST SELECT FREQUENCY : 225.00 MHz STOP You can scan for the frequency ranges available to you, (availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. -
Page 13: Storing The Channels Manually (Depending On The Model)
Storing the Channels Manually You can store up to 100 television channels, including those received via cable networks. When storing channels manually, you can choose: N Whether or not to store each of the channels found N The programme number by which you wish to identify each stored channel N To entry the frequency of the channel to be stored directly, if you know it... - Page 14 Storing the Channels Manually CURRENT PR. : P01 NEW PR. : P08 SEARCH FREQUENCY : 192.00 MHz : ON SYSTEM : AUTO S.SYSTEM : B/G : STORE X : CLEAR ADJUST SELECT CURRENT PR. : P01 NEW PR. : P08 SEARCH FREQUENCY : 192.00 MHz...
-
Page 15: Sorting The Stored Channels
Sorting the Stored Channels The Sort operation allows you to change the programme numbers to previously stored channels or to clear channels that you will never watch. This operation may be necessary after you have stored the channels automatically. You can delete those channels you do not want to keep. -
Page 16: Assigning Names To Channels (Depending On The Model)
Assigning Names to Channels CHANNEL MANUAL TUNE AUTO TUNE ADJUST SELECT CURRENT PR. : P01 NEW PR. : P08 NAME : - - - - - SEARCH FREQUENCY : 192.00 MHz : ON SYSTEM : AUTO S.SYSTEM : B/G : STORE X : CLEAR ADJUST SELECT... -
Page 17: Adjusting The Picture (Depending On The Model)
Adjusting the Picture You can select the type of picture which best corresponds to your viewing requirements. Press the MENU button. Result: The main menu is displayed with the PICTURE is selected. Press the LEFT/RIGHT button. Result: The options available in the PICTURE menu are displayed. - Page 18 Adjusting the Picture PICTURE : CUSTOM ADJUST COLOR TONE : NORMAL AUTO WIDE : OFF SIZE : WIDE : OFF TILT ADJUST SELECT PICTURE : CUSTOM ADJUST COLOR TONE : NORMAL AUTO WIDE : OFF SIZE : WIDE : OFF TILT ADJUST SELECT...
-
Page 19: Adjusting The Sound
Adjusting the Sound You can select the type of special sound effect to be used when watching a given broadcast. Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button until the SOUND is selected. Press the LEFT/RIGHT button. -
Page 20: Selecting The Sound Mode (Depending On The Model)
Selecting the Sound Mode MUTE INPUT S.STD P.STD AUDIO TV/TEXT (depending on the model) The “AUDIO I-II” button displays/controls the processing and output of the audio signal. When power is switched ON, the mode is automatically preset to either “Dual-I” or “Stereo”, depending on the current transmission. -
Page 21: Setting The Time And Switching The Tv On/Off Automatically
Setting the Time and Switching the TV On/Off Automatically You can set the television’s clock and the On/Off timers so that the television will switch On/Off automatically. Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button until the FUNCTION is selected. -
Page 22: Setting The Sleep Timer
Setting the Sleep Timer ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P.SIZE Locking the Front Panel MENU PICTURE SOUND CHANNEL FUNCTION ADJUST SELECT FUNCTION LANGUAGE PANEL LOCK : ON TIME ADJUST SELECT You can select a time period of between 15 and 180 minutes after which the television automatically switches to Standby mode. -
Page 23: Using The Melody Function (Depending On The Model)
Using the Melody Function You can hear clear melody sound when the TV is powered on or off. Press the MENU button. Result: The main menu is displayed. Press the UP/DOWN button until the FUNCTION is selected. Press the LEFT/RIGHT button. -
Page 24: Playing A Disc
Playing a Disc S.STD P.STD AUDIO TV/TEXT OPEN RETURN /CLOSE ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P SIZE Playback Press the OPEN/CLOSE button. Place a disc gently into the tray with the disc’s label facing up. Press the PLAY/PAUSE or OPEN/CLOSE button to close the disc tray. - Page 25 Playing a Disc (MP3) Press the OPEN/CLOSE button. Place a disc gently into the tray with the disc’s label facing up. Result: The first song file of the first folder is played. Press the STOP button to stop playback of the first song file, then press the RETURN button to display the music folder menu on the right side of the screen.
-
Page 26: Using The Search And Skip Functions
Using the Search and Skip Functions MUTE INPUT S.STD P.STD AUDIO TV/TEXT OPEN RETURN /CLOSE Searching through a Chapter or Track Press the FWD or REV SEARCH button on the remote control during playback. - Press the FWD or REV SEARCH button on the remote control and press again to search at a faster speed 32X/128X) -
Page 27: Using The Display Function
Using the Display Function When Playing a DVD During playback, press the DISPLAY Result: Current title, chapter number, elapsed time, audio, subtitle and volume control will be displayed. Use the numeric buttons to enter a different title, then press the ENTER button. -
Page 28: Repeat Play
Repeat Play ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P.SIZE OPEN RETURN /CLOSE Chapter Title VCD/CD Track Disc Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc (VCD/CD only). When playing a DVD Press the REPEAT button. -
Page 29: I Programme Play And Random Play
Program Play and Random Play Program Playback Press the PROGRAM button. Use the LEFT/RIGHT button to select PROGRAM. Press the ENTER button. Use the LEFT/RIGHT button to select the first chapter (or track) to add to the program. Press the ENTER selection numbers appear in the Program Order box. -
Page 30: Using The Disc View Function
Using the Disc View Function OPEN RETURN /CLOSE Disc View 1 Track View 2 Index View TRACK VIEW INDEX VIEW Displays the beginning view of each track and the track number (VCD). During playback, press the TOP MENU button. Press the UP/DOWN ENTER button. -
Page 31: Selecting The Audio Language
Selecting the Audio Language You can select a desired language quickly and easily with the AUDIO button. Using the AUDIO Button Press the AUDIO button. Use the UP/DOWN button to select the desired language on a DVD. Result: The audio languages are represented by abbreviations. Use the UP/DOWN button to select (On VCD/CD). -
Page 32: Selecting The Subtitle Language
Selecting the Subtitle Language OPEN RETURN /CLOSE ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P SIZE SETUP MENU 1 Player Menu English 2 Disc Menu English 3 Audio English 4 Subtitle Automatic 5 Parental Unlocked 6 Audio Options 7 Display Options RETURN SUBTITLE LANGUAGE... -
Page 33: Changing The Camera Angle
Changing the Camera Angle When a DVD contains multiple angles of a particular scene, you can select the Angle function. Using the ANGLE button Press the ANGLE button to see if an “ANGLE ( present at the upper right hand corner of the screen. When an “ANGLE ”... -
Page 34: Using The Zoom Function (Dvd/Vcd)
Using the Zoom Function (DVD/VCD) ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P.SIZE During playback or pause mode, press the ZOOM button on the remote. A square will be displayed on screen. Use the UP/DOWN or LEFT/RIGHT part of the screen you want to zoom. Press the ENTER button. -
Page 35: Using The Bookmark Function
Using the Bookmark Function The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a later time. Using the Bookmark Function (DVD/VCD) During playback, press the BOOKMARK button. Result: A marker will be displayed. -
Page 36: Using The Setup Menu
Using the Setup Menu MENU PICTURE SOUND CHANNEL FUNCTION DVDP SETUP ADJUST SELECT SETUP MENU 1 Player Menu English 2 Disc Menu English 3 Audio English 4 Subtitle Automatic 5 Parental Unlocked 6 Audio Options 7 Display Options RETURN The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have. -
Page 37: Setting Up The Language Features
Setting Up the Language Features If you set the player menu, disc menu, audio and subtitle language in advance, it will come up automatically every time you watch a movie. Using the Player Menu Use the Player preference menu to select the language for the player’s on-screen displays. - Page 38 Setting Up the Language Features SETUP MENU 1 Player Menu English 2 Disc Menu English 3 Audio English 4 Subtitle Automatic 5 Parental Unlocked 6 Audio Options 7 Display Options RETURN AUDIO LANGUAGE 1 English 2 Fran ais 3 Deutsch 4 Espa ol 5 Italiano 6 Nederlands...
-
Page 39: Setting Up The Parental Control
Setting Up the Parental Control The Parental Control function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. Press the MENU button. -
Page 40: Setting Up The Audio Options
Setting Up the Audio Options SETUP MENU 1 Player Menu English 2 Disc Menu English 3 Audio English 4 Subtitle Automatic 5 Parental Unlocked 6 Audio Options 7 Display Options RETURN AUDIO OPTIONS 1 Dolby Digital Out 2 MPEG-2 Digital Out 3 DTS 4 Dynamic Compression RETURN... -
Page 41: Setting Up The Display Options
Setting Up the Display Options Press the MENU button. Use the UP/DOWN button to select DVDP SETUP. Use the LEFT/RIGHT button . Result: The SETUP MENU is displayed. Use the UP/DOWN button to select Display Options. Press the ENTER button. Use the UP/DOWN button to select the desired item. -
Page 42: Disc Type And Characteristics
Disc Type and Characteristics The DVD player is capable of playing the following types of discs with the corresponding logos: Disc Types (Logos) VIDEO-CD AUDIO-CD Disc Markings Play Region Number Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. -
Page 43: Teletext Feature
Teletext Feature Most television channels provide a written information service via Teletext. They provide such information as: N Television programme times N News bulletins N Weather forecasts N Sports results N Travel information This information, which you cannot modify, is divided into numbered pages laid out as follows: Part Contents... -
Page 44: Displaying The Teletext Screen
Displaying the Teletext Screen MUTE INPUT S.STD P.STD AUDIO TV/TEXT Selecting Display Options MUTE INPUT S.STD P.STD AUDIO TV/TEXT ZOOM STEP SUBTITLE CLEAR ANGLE REPEAT BOOKMARK PROGRAM SLEEP P.SIZE You can display Teletext information at any time on your television screen. PRE-CH ☛... -
Page 45: Selecting A Teletext Page
Selecting a Teletext Page You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the contents, by pressing the corresponding numeric buttons. Result: The current page number is incremented until the requested page is reached. -
Page 46: Specifications
Specifications General Power Requirements Dimensions (W x D x H) / Weight Operating Temperature Range Operating Humidity Range Monitor Video Out Disc DVD (DIGITAL VERSATILE DISC) CD : 12 Cm (COMPACT DISC) CD : 8 Cm (COMPACT DISC) VCD : 12 Cm Problemes and Solutions Problemes No sound or picture. - Page 47 Problemes and Solutions Problemes No operations can be performed with remote. Disc does not play. 5.1 channel sound is not being reproduced. icon appears on screen. Disc Menu doesn’t appear. Playback mode differs from the Setup Menu selection. The screen ratio can not be changed. No audio.
- Page 48 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-02285B-00 (ENG)
