COLOUR TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PICTURE IN PICTURE (OPTION) TELETEXT Register your product at www.samsung.com/global/register...
◆ C ONNECTING AND REPARING View of Your Television (depending on the model) ... ■ Infrared Remote Control ... ■ Inserting the Batteries in the Remote Control... ■ Connecting to an Aerial or Cable Television Network ... ■ Switching Your Television On and Off... ■...
Page 4
Contents ◆ U SING ELEVISION (continued) Setting the Sleep Timer ... ■ Switching the Television On and Off Automatically ... ■ Setting the Preferred Volume Level/Channel ... ■ Viewing an External Signal Source/Edit Name (depending on the model)... ■ Viewing the Picture In Picture (PIP) (depending on the model) ... ■...
View of Your Television ➢ The actual configuration on your TV may be different, depending on your model. Control Panels 1) Power On/Off 2) Standby Indicator 3) Remote Control Sensor 4) Channel Selection Connection Panels Side of the TV S-Video Input Video Input Audio Input (R, L) (depending on the model)
Infrared Remote Control TELEVISION STAND-BY DIRECT CHANNEL SELECTION SWITCH REPEATEDLY ONE/TWO-DIGIT BETWEEN THE LAST TWO CHANNEL SELECTION CHANNELS DISPLAYED NEXT CHANNEL VOLUME INCREASE EXTERNAL INPUT SELECTION TEMPORARY SOUND SWITCH-OFF PREVIOUS CHANNEL VOLUME DECREASE INFORMATION DISPLAY EXIT FROM ANY DISPLAY MENU DISPLAY MOVE TO THE REQUIRED MENU OPTION/ ADJUST AN OPTION VALUE...
Page 7
Infrared Remote Control TELETEXT PAGE HOLD SUB PICTURE(PIP) NEXT CHANNEL TELETEXT DISPLAY/ MIX BOTH TELETEXT INFORMATION AND THE NORMAL BROADCAST PROGRAMME SELECTION BY NAME SUB PICTURE(PIP) LOCATION SELECTION FASTEXT TOPIC SELECTION TELETEXT SUB-PAGE PIP ON/OFF TELETEXT SIZE SELECTION SUB PICTURE(PIP) SOURCE SELECTION (continued) TELETEXT NEXT PAGE...
Inserting the Batteries in the Remote Control Connecting to an Aerial or Cable Television Network Rear of the TV Cable Television Network English - 8 You must insert or replace the batteries in the remote control when you: ◆ Purchase the television ◆...
Switching Your Television On and Off The mains lead is attached to the rear of your television. Plug the mains lead into an appropriate socket. ➢ The main voltage is indicated on the rear of the television and the frequency is 50 or 60Hz. Press the “...
Becoming Familiar with the Remote Control The remote control is used mainly to: The following table presents the most frequently used buttons and their functions. Button -/-- PRE-CH MUTE MENU EXIT English - 10 ◆ Change channels and adjust the volume ◆...
Plug & Play Feature When the television is initially powered on, three basic customer settings proceed automatically and subsequently: setting the language, channel and clock. If the television is in Standby mode, press the POWER ( on the remote control. Result: The message Plug &...
Viewing the Demonstration Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off Melody : On √ √ Demonstration Move Enter Return Choosing Your Language Setup √ √ Plug & Play Language œ œ English √...
Storing Channels Automatically You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However you can sort numbers manually and clear any channels you do not wish to watch. Press the MENU button.
Sorting the Stored Channels Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort √ √ Name † † More Move Enter Return Sort œ œ P 1 ----- √ √ From : P-- ----- Store œ...
Storing Channels Manually You can store up to 100 television channels, including those received via cable networks. When storing channels manually, you can choose: ◆ Whether or not to store each of the channels found ◆ The programme number of each stored channel which you wish to identify Press the MENU button.
Page 16
Storing Channels Manually Manual Store Programme : P 1 ----- Colour System : AUTO Sound System : DK Search 0MHz œ œ √ √ Channel Store œ œ √ √ Adjust Move Return Manual Store Programme : P 1 ----- Colour System : AUTO Sound System...
Skipping Unwanted Channels You can exclude the channels you have chosen from the channels you scanned. When you scan through the stored channels, those you have chosen to skip are not displayed. All of the channels that you do not specifically choose to skip are displayed during scanning.
Fine Tuning Channel Reception If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, you may have to fine tune the channel manually.
Using the LNA (Low Noise Amplifier) Feature Channel … … More √ √ Fine Tune œ œ On √ √ œ œ √ √ Move Adjust Return English - 20 This function is very useful in the situation that the TV is used in weak signal.
Changing the Picture Standard You can select the type of picture which best corresponds to your viewing requirements. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Picture. Result: The options available in the Picture group are displayed.
Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements simply by pressing the “P.SIZE ( Depending on the model, the following picture sizes are available: ◆ Normal, Zoom1, Zoom2, 16:9 ◆ 16:9, Panorama, Zoom1, Zoom2, 4:3, Auto Wide ➢...
Selecting the Digital NR Picture Mode : Dynamic Size : 16:9 œ œ √ √ Digital NR Tilt œ œ √ √ Move Adjust Return English - 24 If the signal received by your television is weak, you can activate this feature to reduce any static and ghosting that may appear on the screen.
Using the Tilt Control Feature If you find that the picture received is slightly tilted to one side, you can adjust the tilt setting. Press the MENU button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Picture. Result: The options available in the Picture group are displayed.
Freezing the Current Picture Changing the Sound Standard Sound œ œ Custom √ √ Mode √ √ Equalizer Auto Volume : Off SRS WOW : Off Turbo Sound : Off Pseudo Stereo : Off œ œ √ √ Move Adjust Return English - 26 You can freeze the picture when watching a television programme...
Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. Press the MENU button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Sound. Result: The options available in the Sound group are displayed.
Selecting the Sound Mode The “DUAL I-II” button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “DUAL-I” or “STEREO”, depending on the current transmission. Type of broadcast Regular broadcast (Standard audio) Regular +...
Selecting the Melody Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off œ œ On √ √ Melody √ √ Demonstration œ œ √ √ Move Adjust Return English - 30 You can hear clear melody sound when the television is powered on or off.
Setting and Displaying the Current Time You can set the television’s clock so that the current time is displayed by pressing the “INFO ( the time if you wish to use the automatic on or off timers. ➢ When pressing the “...
Setting the Sleep Timer Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off Melody : On √ √ Demonstration Move Enter Return Time Clock 13 : 00 œ œ 30 min √ √ Sleep Timer On Timer -- : -- Off...
Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: ◆ Switch on automatically and tune to the channel of your choice at the time you select ◆ Switch off automatically at the time you select ➢...
Setting the Preferred Volume Level/Channel Setup √ √ Plug & Play Language : English √ √ Time Blue Screen : Off Melody : On √ √ Demonstration Move Enter Return Time Clock 13 : 00 Sleep Timer : 30 min On Timer 06 : 30 On Off Timer...
Viewing an External Signal Source/Edit Name Use the remote control to switch between viewing signal from connected equipment, such as VCR, DVD, Set-Top-boxes and the TV source (broadcast or cable). Press the MENU button. Result: The main menu is displayed. Press the ENTER ( ) button to select Input.
Viewing the Picture In Picture (PIP) Picture Mode Dynamic Size 16:9 Digital NR Tilt √ √ Move Enter Return œ œ Off √ √ œ œ √ √ Move Adjust Return : On œ œ TV √ √ Source √ √ Swap Size : Large...
Page 37
Viewing the Picture In Picture (PIP) Press the ▲ or ▼ button to select Size. Select a size of sub picture by pressing the œ or √ button. Result: The sizes are displayed in the following order: Large - Small - 3 PIP - 4 PIP - 12 PIP ➢...
Viewing the Picture In Picture (PIP) Easy functions of remote control Buttons SWAP SOURCE SIZE English - 38 (depending on the model) (continued) Feature Used to activate or deactivate the PIP function directly. Used to interchange the main picture and the sub picture. ➢...
Teletext Feature Most television channels provide written information services via teletext. Information provided includes: ◆ Television programme times ◆ News bulletins and weather forecasts ◆ Sports results ◆ Travel information The teletext pages are organized according to six categories: Part Contents Selected page number.
Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Using the various display options: To display... ◆ Both teletext information and ◆ Hidden text ◆ The normal screen ◆...
Using FLOF to Select a Page The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control. Display the teletext contents page by pressing the TTX/MIX ) button. Press the coloured button corresponding to the topic that you wish to select;the available topics are given on the status line.
Connecting to the External Input/Outputs ➢ “EXT 1 (RGB)” is used for the equipment with an RGB output, such as video game devices or video disc players. Rear of the TV ① This end can be fitted with: ◆ A SCART connector ◆...
Connecting to the RCA Input ➢ The RCA (VIDEO and AUDIO-L+R) connectors are used for equipment, such as camcorders, video disc players, and some video game devices. Side of the TV Connecting to the S-Video Input ➢ The S-VIDEO IN and RCA (AUDIO-L+R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR.
Viewing Pictures From External Sources Once you have connected up your various audio and video systems, you can view different sources by selecting the appropriate input. English - 44 Check that all the necessary connections have been made. Switch your television on, then press the SOURCE repeatedly.
Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer.
- AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be...
