Page 1
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Web Site Customer Care Centre AUSTRALIA 1300 362 603 www.samsung.com/au CHINA 800-810-5858 www.samsung.com/cn 400-810-5858 010-6475 1880 HONG KONG:3698 - 4698 www.samsung.com/hk...
Page 2
License ❑ Without producing harmful VOC (Volatile Organic Compounds), Samsung’s Eco-friendly “Crystal Design” expresses colour gradation thanks to our dual injection technology. TruSurround HD, SRS and incorporated under license from SRS Labs, Inc. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
CONTENTS SETTING UP YOUR TV ■ Viewing the Control Panel ... 2 ■ Accessories ... 3 ■ Viewing the Connection Panel ... 4 ■ Viewing the Remote Control ... 6 ■ Installing Batteries in the Remote Control ... 7 OPERATION ■...
SETTING UP YOUR TV Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice in order to enhance product performance. Viewing the Control Panel ¦...
Accessories ¦ Remote Control & Batteries (AAA x 2) Program CD ● Owner’s Instructions Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer. Warranty card / Safety Guide / Registration Cards (Not available in all locations) The items colour and shape may vary depending on the model.
Viewing the Connection Panel ¦ [TV Side Panel] The product colour and shape may vary depending on the model. 1 AV IN , [VIDEO] / [R-AUDIO-L] – Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder. –...
Page 7
Connector for software upgrades and Media Play, etc. – You can connect to Samsung’s network wirelessly using the ‘Samsung Wireless LAN Adapter’ (Sold separately). For USB HDD, use the USB(HDD) port. , Y) on the rear of your set and the other ends , Y) on your set.
TV screen. # Use these buttons in the DMA, Media Play and Anynet + modes. (∏: This remote can be used to control recording on Samsung recorders with the Anynet + feature) $ ON/OFF @ : Pressing the ON/OFF @ light button toggles between on and off.
Installing Batteries in the Remote Control ¦ . Lift the cover at the back of the remote control upward as shown in the figure. . Install two AAA size batteries. Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the compartment.
Placing Your Television in Standby Mode ¦ Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example). .
CHANNEL Channel Menu ¦ Area ❑ You can change the area for channels. Auto Store ❑ You can scan for the frequency ranges available to you (and availability depends on your area). Automatically allocated programme numbers may not correspond to actual or desired programme numbers.
Managing Channels ¦ Using this menu, you can add / delete or set favourites channels. All Channels ■ Shows all currently available channels. Added Channels ■ Shows all added channels. Favourites ■ Shows all favourite channels. To select the favourites channels you have set up, press the FAV.CH button on the remote control. Programmed ■...
Page 13
Timer Viewing ■ If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List; even when you are watching another channel. To reserve a programme, set the current time first. (see page 20) Only memorized channels can be reserved.
PICTURE Configuring the Picture Menu ¦ Mode ❑ You can select the type of picture which best corresponds to your viewing requirements. Press the TOOLS button to display the Tools menu. You can also set the picture mode by selecting Tools → Picture Mode. Dynamic ■...
Page 15
Advanced Settings ❑ Samsung’s new TVs allow you to make even more precise picture settings than previous models. Advanced Settings is available in Standard or Movie mode. In PC mode, you can only make changes to Dynamic Contrast, Gamma and White Balance from among the Advanced Settings items.
Page 16
Picture Options ❑ In PC mode, you can only make changes to the Colour Tone and Size from among the items in Picture Options. Colour Tone → Cool / Normal / Warm1 / Warm2 / Warm3 ■ Warm, Warm or Warm is only activated when the picture mode is Movie. Settings can be adjusted and stored for each external device you have connected to an input of the TV.
100Hz Motion Plus → Off / Clear / Standard / Smooth / Custom / Demo ■ Removes drag from fast scenes with a lot of movement to provide a clearer picture. If you enable 00Hz Motion Plus, noise may appear on the screen. If this occurs, set 00Hz Motion Plus to Off. ● Off: Switches 100Hz Motion Plus off. ●...
However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) . First, click on ‘Control Panel’ on the Windows start menu.
Setting up the TV with your PC ¦ Preset: Press the SOURCE button to select PC mode. Auto Adjustment ❑ Use the Auto Adjust function to have the TV automatically adjust the video signals it receives. The function also automatically fine-tunes the settings and adjusts the frequency values and positions.
Auto Volume → Off / On ❑ Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume every time the channel is changed. This feature lets you automatically adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low.
BD Wise → Off / On ❑ Provides the optimal picture quality for SAMSUNG DVD, Blu-ray and Home Theatre products which support BD Wise. You can enjoy a richer picture when using them connected to this Samsung TV. Connect SAMSUNG products that have BD Wise using an HDMI cable.
Melody → Off / Low / Medium / High ❑ A melody sound can be set to come on when the TV is powered On or Off. The Melody does not play When no sound is output from the TV because the MUTE button has been pressed. ...
Contents (when Source is set to USB or TV Memory) ■ You can select a folder on the USB Device/TV memory with music or photo files to be played when the TV turns on automatically. If the folder name is too long, the folder can not be selected. If you are using two of the same type USB device, be sure the folder names are different so the correct USB is read.
Page 24
You can connect the LAN port and the TV directly depending on your network status. The LAN Port on the Wall The terminals (the position of the port and the type) of the external device may differ depending on the manufacturer. If the IP address allocation by the DHCP server has failed, turn the external modem off, turn it on again after at least 10 seconds and then try again.
Page 25
If your AP supports WPS(Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration) or PIN (Personal Indentification Number). WPS will automatically configure the SSID and WPA key in either mode. If the device isn’t certified, it may not connect to the TV via the ‘Samsung Wireless LAN Adapter’. Samsung Wireless...
The internet connection may fail due to a firewall problem. In this case, contact your Internet service provider. If you cannot connect to the Internet even if you have followed the procedures of your Internet service provider, please contact Samsung Electronics.
Page 27
● Select a network Access Point: You can select the IP sharer to use when using a wireless network. If a wireless Access Point is not in the Access Point list, press the Red button. When the connection is made, you will be returned to the screen automatically. If you have selected an Access Point with a security authentication: The Security Key input screen appears.
Page 28
Ad-hoc: You can connect to a mobile device without an access point through the ‘Samsung Wireless LAN Adapter’ by using a peer to peer network. How to connect to new Ad-hoc . Choose Select a network, then a device list is displayed.
Select the currently selected item. Return to the previous menu. Stop the current function and return to the Product Guide main menu. English - Source List Edit Name Source List : - - - - AV1 : - - - - AV2 : - - - - Component1 : - - - - Component2 : - - - - Refresh T Tools Product Guide ▶ Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung...
Software Upgrade ❑ Samsung may offer upgrades for the TV’s firmware in the future. These upgrades can be performed via the TV when it is connected to the Internet, or by downloading the new firmware from samsung.com to a USB memory device.
USB compatibility problem. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss.
Media Play Function ¦ This function enables you to view and listen to photo, music and/or movie files saved on a USB Mass Storage Class (MSC) device. Entering the Media Play (USB & DLNA) Menu . Press the MENU button. Press the ▲ or ▼ button to select Application, then press the ENTERE button.
1 Current Sort key: This field shows the current standard for sorting files. Press the ◄ or ► button to change the standard for sorting files. 2 View Groups: Shows the detailed groups of the files sorted according the selected Sort key. The sort group where the currently selected file is contained is highlighted.
Photo List Option Menu ¦ . Press the MEDIA.P button. . Press the ◄ or ► button to select Photo, then press the ENTERE button. . Press the ▼ button to move to the File List Section. . Press the ◄ or ► button to select the desired photo file. Selecting Multiple Photos ...
Viewing a Photo or Slide Show ¦ Viewing a Slide Show . Press the ▼ button to select the File List Section. . Press the TOOLS button. . Press the ▲ or ▼ button to select Slide Show, then press the ENTERE button. All files in the photo list will be used for the Slide Show.
● Alternatively . In the Photo List, press the Yellow buttons to select the desired photos. . Press the TOOLS button. . Press the ▲ or ▼ button to select Slide Show, then press the ENTERE button. The selected files will be used for the Slide Show. Slide Show Option Menu ¦...
Picture Setting / Sound Setting ❑ You can select the picture and sound settings. Information ❑ The photo file information is displayed. Remove Safely ❑ You can remove the device safely from the TV. Sorting the Music List ¦ You can sort music files in the Music List by a particular standard. .
Music List Option Menu ¦ . Press the MEDIA.P button. . Press the ◄ or ► button to select Music, then press the ENTERE button. . Press the ▲ button to move to the File List Section. . Press the ◄ or ► button to select the desired Music file. Selecting Multiple Music Files ...
Playing a Music ¦ Playing a music file . Press the ▼ button to select the File List Section. . Press the ◄ or ► button to select a music file to be played. . Press the ∂ (Play)/ENTERE button. This menu only shows files with the MP3 file extension. Files with other file extensions are not displayed, even if they are saved on the same USB device.
Music Play Option Menu ¦ Music Play Option Menu Repeat Mode → On / Off ❑ You can play music files repeatedly. Picture Setting / Sound Setting ❑ You can configure the picture and sound settings. Information ❑ The music file information is displayed. Remove Safely ❑...
Movie List Option Menu ¦ . Press the MEDIA.P button. . Press the ◄ or ► button to select Movie, then press the ENTERE button. . Press the ▲ button to move to the File List Section. . Press the ◄ or ► button to select the desired Movie file. Selecting Multiple Movie Files ...
Page 42
Supported Subtitle Formats Name MPEG-4 time-based text SAMI SubRip SubViewer Micro DVD Supported Video Formats File Extension Container *.avi *.mkv *.asf *.wmv (VC1) *.mp4 MP4 (SMP4) *.3gp 3GPP *.mpg *.mpeg *.vro *.vob (ps) others (ts) Video Play Control Buttons Button Operations Play/Pause the movie file ENTERE...
Page 43
Playing the movie group . Press the ▲ button to move to the Sort key Section. . Press the ◄ or ► button to select a sorting standard. . Press the ▼ or ENTERE button to move to the Group List Section. .
Movie Play Option Menu ¦ Movie Play Option Menu Picture Setting / Sound Setting ❑ You can configure the picture and sound settings. Picture Size ❑ ■ Play video at the TV screen size. Original ■ Play video at the original size. Caption Setting ❑...
Using the Setup Menu ¦ Setup displays the user settings of the Media Play menu. . Press the MEDIA.P button. . Press the ◄ or ► button to select Setup, then press the ENTERE button. . Press the ▲ or ▼ button to select the desired option. .
PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) . Connect the PC to which the Samsung PC Share Manager program will be installed and the external modem using a LAN cable.
To play content on the PC on the TV, you have to first install the application. To use the DLNA function smoothly, use the program in the CD-ROM supplied with the TV or use the Samsung PC Share Manager program corresponding to the TV model that can be downloaded from the Samsung web site.
Using the DLNA Application ¦ The Programme Screen Layout . Menus: The following application menus are provided : File, Share, Server, and Help. . Click to share the selected PC server folder. . Click to cancel sharing. . Click to refresh the PC folder and files. .
Page 49
Share ❑ Sharing a Folder ■ You can share a folder from your PC to the TV. The maximum number of folders that can be shared is 32. Your PC will operate as a server to the TV. ● Method 1: Select a folder in My Computer, select the Share menu and then select the Share Folder sub-menu. ●...
The Divx DRM, Multi-audio, embedded caption does not supported. Samsung PC Share manager should be permitted by the firewall program on your PC. The Skip (◄/► keys) or Pause function may not work while a movie is playing for the DLNA of other manufacturers, depending on the corresponding content information.
Anynet + is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet + system can be used only with Samsung devices that have the Anynet + feature. To be sure your Samsung device has this feature, check if there is an Anynet + logo on it.
Setting Up Anynet + ¦ Press the TOOLS button to display the Tools menu. You can also display Anynet + menu by selecting Tools → Anynet + (HDMI-CEC). Setup ❑ Anynet + (HDMI-CEC) → Off / On ■ To use the Anynet + Function, Anynet + (HDMI-CEC) must be set to On. When the Anynet + (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated.
Recording ¦ You can make a recording of a TV program using a Samsung recorder. . Press the TOOLS button. Press the ENTERE button to select Anynet + (HDMI-CEC). . Press the ▲ or ▼ button to select Recording Immediately and press the ENTERE button.
Troubleshooting for Anynet + ¦ Problem Possible Solution Anynet + does not work. Check if the device is an Anynet + device. The Anynet + system supports Anynet + devices ● only. ● Connect only one receiver (home theatre). Check if the Anynet + device power cord is properly connected. ●...
INFORMATION IN THE CONTENTS LIBRARY IS PROVIDED ‘AS IS.’ ALTHOUGH THE INFORMATION PROVIDED TO YOU IN THE CONTENTS LIBRARY IS OBTAINED OR COMPLIED FROM SOURCES WE BELIEVE TO BE RELIABLE, SAMSUNG CANNOT AND DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS OR COMPLETENESS OF ANY INFORMATION OR DATA MADE AVAILABLE TO YOU FOR ANY PARTICULAR PURPOSE.
You can view various recipes and then easily follow them step by step. Enjoy these contents which will give you great ideas for meals. The recipes introduced in the Cooking contents on the Samsung TV are based on recipes published by Anness Publishing. The copyrights of the Cooking contents and all issues related to them are reserved by Practical Pictures.
Downloading New Contents New content other than the built-in content will be provided via the Samsung.com website free of charge. When you download the paid contents, you need UDN number to download contents. Check the UDN number before downloading a new content item.
Getting Started with Internet@TV ¦ Internet@TV provides SAMSUNG’s widget services through a network connection. Internet@TV contents can be changed depending on contents provider. You can access various information such as YouTube, through the Internet@TV service. The configuration of Widgets and their provided services may differ according to the selected country. After changing country, turn off and on the TV.
System Setup ❑ Ticker Autorun, Ticker Duration may not be supported depending on country. Change the Service Lock password ■ The default password number of a new TV set is 0-0-0-0. If you forget the password, press the remote control buttons in the following sequence, which resets the password to 0-0-0-0: POWER (off) → MUTE → 8 → 2 → 4 → POWER (on).
If the device supports DLNA DMC (Digital Media Controller) function, Home Network Centre function is available. The Samsung SCH-i00 mobile phone supports the Home Network Centre. Other models will be added in the future. The mobile device may need additional software installation. For details, refer to each user’s guide.
Setting Up the Home Network Centre ¦ Message ❑ Shows a list of mobile phones which have been set up with this TV to use the message function (the call arrivals, text message contents and schedules set on the mobile phone). Allowed ■...
Using the Message Function ¦ Using this function, you can view the call arrivals, text message contents and schedules set on the mobile phone through the alarm window while watching TV. To disable this Message alarm window, set Message to Off in Setup of the Home Network Centre.
Using the Media Function ¦ An alarm window appears informing the user that the media contents (videos, photos, music) sent from the mobile phone will be displayed on the TV. The contents are played automatically 3 seconds after the alarm window appears. If you press the RETURN or EXIT button when the alarm window appears, the Media Contents are not played.
RECOMMENDATIONS Teletext Feature ¦ Most television stations provide written information services via Teletext. The index page of the Teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons.
The Teletext pages are organized according to six categories: Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information. Teletext information is often divided between several pages displayed in sequence, which can be accessed by: ...
Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
Anti-Theft Kensington Lock ¦ The Kensington Lock is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use. The locking device has to be purchased separately.
Troubleshooting: Before Contacting Service Personnel ¦ Before contacting service personnel Problem Possible Solution No sound or picture Check that the mains lead has been connected to a wall socket. Check that you have pressed the button on your set. Check the picture contrast and brightness settings. Check the volume.
Specifications ¦ Model Name Screen Size (Diagonal) PC Resolution (Optimum) Sound (Output) Dimensions (WxDxH) Without Stand With stand Weight With Stand Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity Stand Swivel (Left / Right) Model Name Screen Size (Diagonal) PC Resolution (Optimum)
This product uses some software programs which are distributed under the GPL/LGPL license. Accordingly, the following GPL and LGPL software source codes that have been used in this product can be provided after asking to vdswmanager@ samsung.com. GPL software: Linux Kernel, Busybox, Binutils...
Page 72
To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation includes copying, distribution (with or without modification), making available to the public, and in some countries other activities as well.
Page 73
b) The work must carry prominent notices stating that it is released under this License and any conditions added under section 7. This requirement modifies the requirement in section 4 to “keep intact all notices”. c) You must license the entire work, as a whole, under this License to anyone who comes into possession of a copy. This License will therefore apply, along with any applicable section 7 additional terms, to the whole of the work, and all its parts, regardless of how they are packaged.
Page 74
warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the operation of the network or violates the rules and protocols for communication across the network.
Page 75
Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this License.
The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number.
GNU Lesser General Public License (LGPL) ¦ Version , June 00 Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The GNU General Public License is a free, copyleft license for software and other kinds of works.
Page 78
The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any non-source form of a work. A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language.
Page 79
the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or legal rights of the compilation’s users beyond what the individual works permit.
Page 80
from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give appropriate copyright permission.
Page 81
A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is based. The work thus licensed is called the contributor’s “contributor version”. A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its contributor version, but do not include claims that would be infringed only as a consequence of further modification of the contributor version.
THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
LICENSE ISSUES ¦ The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org.
