FCC Statements
Moultrie Products
MCG-13036
Panoramic 180i
Panoramic 120i
Note: changes and modifications not expressly approved by the party responsible could void the user' s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- lncrease the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
www.moultriefeeders.com
PRADCO Outdoor Brands • 3280 Highway 31, Ste B • Calera, AL 35040
Moultrie Products
MCG-13269
06212018 / MCG-13036 • MCG-13269
Instructions for P-Series Digital Game Camera
THANK YOU for your purchase of a P-Series Digital Game Camera. Please read this booklet before using the unit. If you should
have any questions about this product or any other Moultrie product, please contact us using the information on the back of
this booklet. Please register your camera at www.moultriefeeders.com/warranty to activate your warranty.
Release for
Battery Compartment
Infrared LED Flash
Light Sensor
Camera Lenses
Motion Sensors
SD Card Slot
LCD Display
Mode Selector Switch
Navigation Buttons
External Power Port
Micro USB Port
Advertisement
Table of Contents
Related Manuals for Moultrie Panoramic 180i
Summary of Contents for Moultrie Panoramic 180i
- Page 1 Panoramic 180i Panoramic 120i have any questions about this product or any other Moultrie product, please contact us using the information on the back of this booklet. Please register your camera at www.moultriefeeders.com/warranty to activate your warranty. Note: changes and modifications not expressly approved by the party responsible could void the user’ s authority to operate this device.
- Page 2 MOULTRIE P-SERIES MENU MAP P IR P IR R ES ET R ES ET P HO TO OR P HO TO OR DETECTIO N DETECTIO N M OTION DETECT M OTION DETECT STAR T MOTI ON STAR T MOTI ON...
-
Page 3: Quick Start Instructions
Time. Other settings are: Detection Delay 30 seconds Accepts the Moultrie power accessories (sold separately) only. Refer to www.moultriefeeders.com for more information. Loops Strap NOTE: The use of any other power source will void your warranty and possibly harm your camera. -
Page 4: Capture Modes
Event Delay Setting CAPTURE MODES D E T E C T I O N D E L A Y Detection Delay determines the number of minutes between pictures when an S E C O N D S animal is detected and remains in range. Choose between (NONE, 10 sec, 30 sec, Setting Capture Mode 1 min, 5min, 10min, or 30 min). - Page 5 Setting Photo or Video Setting Program Stop P H O T O V I D E O T . L . P R O G R A M Choose between Photo, Video or Both. “Both” will take a photo, then a video. When start time is set, the camera will automatically move to the Stop option.
- Page 6 SETTING PHOTO/VIDEO OPTIONS SETTING INFOSTRIP OPTIONS Infostrip Active Setting Photo Quality I N F O S T R I P A C T I V E P H O T O Q U A L I T Y Choose between: Choose between 4 image resolution settings: Y E S H I G H ( 4 M P )
-
Page 7: System Options
NOTE: Please remember your security code. If the code is lost, you can contact NOTE: Nighttime videos are limited to a maximum of 30 seconds. Moultrie customer support to reset the password (charges may apply). Also, use caution when navigating through the Security Code option as not to set a code by mistake. -
Page 8: Field Of View
FIELD OF VIEW Troubleshooting Please visit www.moultriefeeders.com/contact-us for troubleshooting and helpful tips. Moultrie’s P-Series cameras are known for their wider-than-average field of view. Below you will see a quick comparison between the FOV of the P-120i and the P-180i. Returns and Repairs Please visit http://www.moultriefeeders.com/return-policy and complete the form or our Service Department will gladly answer any questions...
