  • Page 1 Instruction Manual DVD-V9700 DVD-V9700 www.samsung.com...

  • Page 2: Safety Instructions

    A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the outlet.

  • Page 3: Precautions

    FCC NOTE (for U.S.A): This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Handling Cautions

    Before connecting other components to this player, be sure to turn them all off. • Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s internal parts may be damaged.

  • Page 5: Before You Start

    E F O R E Y O U S TA R T Before you start Accessories Remote Control AK59-00061J Install Batteries in the Remote Control Open the battery cover on the back of the remote control. Insert two AAA batteries.

  • Page 6: Table Of Contents

    Connecting to a TV (Video)...18 Connection to an Audio System ...19 Connecting to an Audio System (2 Channel Amplifier, Analog) ...19 Connecting to an Audio System (Dolby digital, MPEG2 or DTS Amplifier)...20 Connecting the Power Cord ...21 Chapter 3: Initial Setup Selecting a Menu Language ...22...
  • Page 7 A B L E O F O N T E N T S Selecting the Subtitle Language ...38 Changing the Camera Angle ...39 Using the Bookmark Function (DVD) ...39 Using the Zoom Function (DVD) ...41 Clips Menu for CD Audio/MP3/WMA/JPEG/MPEG4 files ...42 Folder Selection ...42...

  • Page 8: General Features

    Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD- VCR directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy- protected DVD discs.

  • Page 9: Disc Type And Characteristics

    Video AUDIO-CD Audio CD-R,CD-RW and DVD-RW, -R, DVD+RW, +R discs may not be playable in all cases due to the disc ■ type or condition of the recording. Do not run the player with two discs loaded at the same time.

  • Page 10: Description

    Press to open and close the disc VCR Deck Insert a standard VHS video tape. EJECT Press to eject a video tape if the tape is stopped. (POWER) Press to turn the DVD-VCR on and LINE IN 2 Connects to the Video/Audio output jack of your external device.

  • Page 11: Rear Panel

    HDMI OUT Notes ■ Consult your TV User’s Manual to find out if your TV supports Progressive Scan. If Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan settings in the TV’s menu system. ˆ ˆ ¨ ¨...

  • Page 12: Tour Of The Remote Control

    (VCR). TV VOL (+,-) button 11 MENU button Brings up the DVD-VCR player’s menu. 12 ENTER/œ œ ƒ ƒ ¦ ¦ ‹ ‹ buttons This button functions as a toggle switch. DISC MENU button Brings up the Disc menu.

  • Page 13: Before Connecting The Dvd-Vcr

    - If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 19 to 20) - When you connect a STB through the LINE IN 1 jack of the DVD-VCR, you still can see the picture from the STB on your TV set if the DVD-VCR is turned off.

  • Page 14: Connection To A Tv

    TV screen. HDMI VIDEO Specifications When you press the HDMI button on the front panel, 480p, 720p, and 1080i are selected in The first press of the HDMI button on the front panel brings up the current resolution.
  • Page 15 HDMI (High Definition Multimedia Interface) HDMI is an interface that enables the digital transmission of video and audio data with just a single cable. Using HDMI, the DVD player transmits a digital video and audio signal and displays a vivid picture on a TV having an HDMI input jack.

  • Page 16: Connecting To A Tv (Progressive)

    Progressive scan has twice as many scanning lines as the interlace output method. Progressive scanning method provides better and clearer picture quality. The Component Video jacks only output video from the DVD player. To view video from the VCR, you must have the Video/Line Out (yellow) jack connected.

  • Page 17: Connecting To A Tv (Interlace)

    If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 19 to 20) - The component jack of your TV may be marked “R-Y, B-Y, Y” or “Cr, Cb, Y” instead of “PR, PB, Y”...

  • Page 18: Connecting To A Tv (Video)

    - The number and position of jacks may vary depending on your TV set. Please refer to the user's manual of your TV. - If there is one audio input jack on the TV, connect it to the LINE OUT AUDIO OUT Left (white) jack of the DVD-VCR.

  • Page 19: Connection To An Audio System

    Amplifier's audio input. Notes - Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears. Please set the audio in the menu screen according to the Amplifier. (See pages 52 to 53) - The position of jacks may vary depending on the Amplifier.

  • Page 20: Connecting To An Audio System (Dolby Digital, Mpeg2 Or Dts Amplifier)

    Notes - When you connect the DVD-VCR to a DTS Amplifier and play a DTS disc, set the DTS to On in the Audio Setup menu. If it is set to Off, sound will not be heard, or there will be a loud sound.

  • Page 21: Connecting The Power Cord

    O N N E C T I O N S Connecting the Power Cord Your DVD-VCR's power cord should be plugged into a standard 120V/60Hz wall outlet. Turn on the power by pressing the button on the remote control or panel.

  • Page 22: Selecting A Menu Language

    C h a p t e r 3 N I T I A L Selecting a Menu Language Follow these steps to change the on-screen MENU language to English, French or Spanish. Press the MENU button. Press the œƒ buttons to Setup, then press the ‹...

  • Page 23: Setting The Clock

    Setting the Clock This menu is used to set the current time. Setting the Clock Manually Auto Setup fails to set the DVD-VCR’s internal clock by locating a local TV station, follow these steps to set the date and time manually. Note: For accurate Timer Recording, your DVD-VCR's internal clock must be set correctly.

  • Page 24: Setting The Front Panel Display

    N I T I A L Setting the Front Panel Display You can set the Front Panel Display to be bright, dim, or to automatically dim during power off. Press the MENU button. Press the œƒ buttons to Setup, then press the ‹...

  • Page 25: Setting The Auto Power Off

    DVD-VCR will auto shut off 2 hours after the last button ■ is pressed or no signal is received. E T U P off your DVD-VCR if no signal is received and you do not press any buttons for ENG-25...

  • Page 26: Playing A Disc

    Before Play Turn on your TV and set it to the correct Video Input on your TV's remote control. - If you connected an external Audio System, turn on your Audio System and set it to the correct Audio Input. Playback Press the OPEN/CLOSE ( button on the front panel.
  • Page 27 Screen stops, no sound. - To resume, press the (Play/Pause) button once again. Note If the player is left for about 5 minutes in pause mode, it will stop. Each time the button is pressed, a new frame will appear.

  • Page 28: Using The Search And Skip Functions

    P E R AT I O N S Using the Search and Skip Functions During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection. Searching through a Chapter or...

  • Page 29: Using The Display Function

    D V D O P E R AT I O N S Using the Display Function When Playing a DVD/MPEG4 During play, press the INFO button on the remote control. Press the œƒ buttons to select the desired item. Press the ¦‹ buttons to...
  • Page 30 Refers to the subtitle languages available in the disc. SUBTITLE You will be able to choose the subtitle languages or, if you prefer, turn them off from the screen. A DVD disc can have up to 32 different subtitles. ENG-30...

  • Page 31: Using The Disc And Title Menu (Dvd)

    Notes Depending on the disc, the Disc Menu or Title Menu may not work. - You can also use the Disc Menu by using the DISC MENU button on the remote control. - The Title Menu will only be displayed if there are at least two titles on the disc.

  • Page 32: Using The Function Menu (Dvd)

    D V D O P E R AT I O N S Using the Function Menu (DVD) During the playback of a DVD disc, press the MENU button on the remote control. Press the œƒ buttons to select Function, then press ‹...

  • Page 33: Repeat Play

    ENTER button at the point where you want the repeat play to stop (B). To return to normal play, press the CANCEL button. Note REPEAT allows you to set point (B) 5 seconds after point (A) has been set. To return to normal play, press REPEAT...

  • Page 34: Slow Play

    D V D O P E R AT I O N S Slow Play This feature allows you to slowly to repeat scenes containing sports, dancing, musical instruments being played etc., so you can study them more closely. When playing a DVD...

  • Page 35: Adjusting The Aspect Ratio (Ez View)

    The top, bottom, left and right of the screen are cut off and the central portion of the screen is enlarged. Aspect Ratio (EZ View) TV screen so the DVD-VCR will display movies at the appropriate WIDE SCREEN EZ VIEW For 4:3 aspect ratio discs...
  • Page 36 For 16:9 aspect ratio discs - 4:3 Letter Box Displays the content of the DVD title in 16:9 aspect ratio. The black bars will appear at the top and bottom of the screen. 4:3 Pan Scan The left and right portions of the screen are cut off and the central portion of the 16:9 screen is displayed.

  • Page 37: Selecting The Audio Language

    D V D O P E R AT I O N S Selecting the You can select a desired audio language quickly and easily with the AUDIO button. Using the AUDIO button (DVD/MPEG4) During play, press the AUDIO button. Audio languages change ¦...

  • Page 38: Selecting The Subtitle Language

    D V D O P E R AT I O N S Selecting the Subtitle Language You can select a desired subtitle quickly and easily with the SUBTITLE button. Using the SUBTITLE button (DVD/MPEG4) During play, press the SUBTITLE button.

  • Page 39: Changing The Camera Angle

    ) icon, press the CLEAR or RETURN button. Using the Bookmark Function This feature lets you bookmark sections of a DVD so you can quickly find them at a later time. Using the MARK button (DVD) During play, press the MARK button on the remote control.
  • Page 40 D V D O P E R AT I O N S Recalling a Marked Scene During play, press the MARK button on the remote control. Press the ¦‹ buttons to select a marked scene. Press the (Play/Pause) button to play the marked scene.

  • Page 41: Using The Zoom Function (Dvd)

    D V D O P E R AT I O N S Using the Zoom Function (DVD) During the playback of a DVD disc, press the MENU button on the remote control. Press the œƒ buttons to select Function, then press ‹...

  • Page 42: Clips Menu For Cd Audio/Mp3/Wma/Jpeg/Mpeg4 Files

    Clips Menu for CDAudio/ MP3/ WMA/JPEG/ MPEG4 Discs with MP3/WMA/JPEG/MPEG4 contain individual songs and/or pictures that can be organized into folders as shown below. They are similar to how you use your computer to put files into different folders. Open the disc tray.

  • Page 43: Cd Audio/Mp3/Wma Playback

    O f f O f f 0 0 : 0 0 : 2 3 B e c a u s e Y o u 0 0 : 0 0 : 2 3 1 _ m p 3 . . .
  • Page 44 When you record MP3 or WMA files on a CD-R, please refer to the following. - Your MP3 or WMA files should be ISO 9660 or JOLIET format. ISO 9660 format and Joliet MP3 or WMA compatible with Microsoft's DOS and Windows, and with Apple's Mac.

  • Page 45: Mpeg4 Playback

    D V D O P E R AT I O N S MPEG4 Playback MPEG4 Play Function AVI files are used to contain the audio and video data. Only AVI format files with the “.avi” extensions can be played. Open the disc tray.
  • Page 46 These functions may not work depending on MPEG4 file. Notes Some MPEG4 files created on a personal computer may not be able to be played back. That is why Codec Type, Version and Higher resolution higher than the specifications are not supported.

  • Page 47: Picture Cd Playback

    Notes Depending on a file size, the amount of time between each picture may be different from the set interval time. - If you don’t press any button, the slide show will start automatically in about 10 seconds by default.
  • Page 48 Only files with the “.jpg” and “.JPG” extensions can be played. - If the disc is not finalized, it will take longer to start playing and not all of the recorded files may be played. - Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.

  • Page 49: Using The Setup Menu

    Œ Language Setup: Setup of the Language. ´ Audio Setup: Setup of the Audio Options. ˇ Display Setup:Setup of the Display Options. Used to select which type of screen you want to watch and several display options. ¨ Parental Setup: Setup of the Parental Level.

  • Page 50: Setting Up The Language Features

    P E R AT I O N S Setting Up the Language Features If you set the audio and subtitle language in advance, the settings will automatically be applied every time you watch a movie. With the unit in Stop mode,...
  • Page 51 D V D O P E R AT I O N S Language Function Disc Menu To set the Disc Menu Language to your preferred language, follow these steps. If your preferred language is available on a DVD, your Disc Menu Language will automatically be set to the language you selected.

  • Page 52: Setting Up The Audio Options

    D V D O P E R AT I O N S Setting Up the Audio Options allows you to set up sound for use with your external audio system. With the DVD in Stop mode, press the MENU button on the remote control.

  • Page 53: Audio Options

    D V D O P E R AT I O N S Audio Options Dolby Digital Out PCM: Converts to PCM(2CH) audio. - Bitstream: Outputs Dolby Digital via the digital output. Off : Does not output a digital signal - On: Outputs DTS Bitstream Digital via digital output only.

  • Page 54: Setting Up The Display Options

    D V D O P E R AT I O N S Setting Up the Display Options Display options enable you to set various video functions of the With the unit in Stop mode, press the MENU button on the remote control.

  • Page 55: Display Options

    (screen setting). - 4:3 Letter Box: Select when you want to see the total 16:9 ratio screen the DVD supplies, even though you have a TV with a 4:3 ratio screen. Black bars will appear at the top and bottom of the screen.
  • Page 56 - 720p : 1280 x 720 - 1080i : 1920 x 1080 Format This feature can be used to fine-tune the HDMI output of this DVD-VCR unit to your TV or Monitor for the best color reproduction. When connected via HDMI, you can change the HDMI output format.
  • Page 57 The resolutions available for HDMI output depend on the connected TV or see the user’s manual of your TV or projector. ● When the resolution is changed during playback, it may take a few seconds for a normal image to appear. ●...

  • Page 58: Setting Up The Parental Control

    The Parental Control function works in conjunction with DVDs that have been assigned a rating, which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. Setting Up the Rating Level...

  • Page 59: Changing The Password

    Enter your password. Note The default password is 0000. To make the DVD setup menu disappear, press the MENU button. - For example, if you select up to Level 6, discs that contain Level 7 or 8 will not play. ENG-59...
  • Page 60 D V D O P E R AT I O N S Press the œƒ buttons to select Change Password, ‹ or ENTER then press the button. Enter your password, then ‹ or ENTER press the button. Enter your new password, ‹...

  • Page 61: Divx(R) Registration

    D V D O P E R AT I O N S DivX(R) Registration DivX Registration menu has the Registration Code that enables your DivX Certified Player to play DivX(R) Video On Demand file format. With the unit in Stop mode,...

  • Page 62: Inserting And Ejecting A Video Cassette Tape

    P E R AT I O N S In this chapter, you will learn how to play a video cassette tape, how to use the time counter and memory stop features, and how to record a program as you are watching TV.

  • Page 63: Playing A Pre-Recorded Video Cassette Tape

    Note To view VCR playback, you must connect the Video Out (Yellow) to your TV. The VCR does not output video through the Component jacks. Video Cassette Tape For more information on the safety tab, see page 74.

  • Page 64: Special Vcr Playback Features

    P E R AT I O N S Special VCR Playback Features While a videotape is playing, you can enjoy a variety of special playback features, including Still, Frame Skip, Repeat, and more. Press the Play/Pause button again to resume normal playback.

  • Page 65: Using Automatic Tracking

    Tracking adjustment removes the white lines that sometimes appear during playback because of slight differences in recording decks. The TRK button will automatically align the recorded tracks with the playback heads to solve this problem. You may also set tracking manually.

  • Page 66: Selecting The Cassette Type

    P E R AT I O N S Selecting the Cassette If you wish to use the tape counter to display the time remaining on a cassette, you must indicate the type of cassette inserted. Press the MENU button on the remote control.

  • Page 67: Setting The Auto Play

    V C R O P E R AT I O N S Setting the Auto Play If you want your videotapes to play automatically when you insert them, turn on Press the MENU button on the remote control. Press the œƒ buttons to...

  • Page 68: Setting The Auto Repeat

    V C R O P E R AT I O N S Setting the Auto Repeat If you want your videotapes to play Press the MENU button on the remote control. Press the œƒ buttons to select VCR, then press the ‹...

  • Page 69: Using The Tape Counter

    - Is reset when a cassette is inserted in the DVD-VCR. - Allows you to easily find the beginning of a sequence. - If the remaining time is to be calculated correctly, you must indicate the type of cassette being used. Insert a cassette in your DVD- VCR.

  • Page 70: Using The Assemble Edit Function

    P E R AT I O N S Using the Assemble Edit Function This function allows you to start a new recording at a specific position on the cassette while maintaining a very smooth scene change. Insert the cassette to be edited in your DVD-VCR.

  • Page 71: Selecting The Audio Output Mode

    When you have finished recording, press the (Stop) button. Selecting the You can select the mode in which the sound is reproduced on the loudspeakers and AV outputs. The following options are available. Press the AUDIO button on the remote control until the required option is displayed.

  • Page 72: Searching For A Specific Sequence

    Each time you record a cassette on this DVD-VCR, an “index” is automatically marked on the tape when recording starts. The Search function allows you to fast-forward or rewind to a specific index and start playback from that point. Depending on the direction selected, the indexes are numbered as follows: Prev Seq.

  • Page 73: Variable Search System

    The VCR will fast forward, searching for a blank position, and then automatically stop at that position. If the VCR reaches the end of the tape during end search, the tape will be ejected. Scan and Play Use scan and play when you don’t know exactly where a...

  • Page 74: Basic Recording

    You can even add time in 30-minute increments up to 4 hours by pressing the REC button repeatedly; see page 76. Note Be sure your videotape has a Record Safety piece of tape. Warning: Do not cover this opening unless you are sure you want to record over the tape. Before You Begin... Power on the DVD-VCR...

  • Page 75: Special Recording Features

    Press the (Stop) button. Special Recording Features While a recording is in progress, you can watch a DVD, or add recording time in 30-minute increments. To Watch a DVD while Recording Insert a DVD in the DVD tray and press the (Play/Pause).

  • Page 76: Using One-Touch Recording

    P E R AT I O N S Using One-Touch Recording One-Touch Recording (OTR) allows you to add recording time in 30-minute increments up to 4 hours at the touch of a button. Insert a blank VHS tape into the VCR deck.

  • Page 77: Selecting The Recording Speed

    DVD-VCR will automatically be turned off when the OTR finished. Selecting the Recording Speed You can slow down the recording speed from SP to SLP in order to fit six hours of programming on a T-120 tape. Press the SPEED button on the remote control to select the Record Speed.

  • Page 78: Making A Timer Recording

    Timer Recording Insert a blank videotape into the VCR deck. Be sure to leave the Record Safety With the Timer Recording function, you can program up to 7 events at a time to record up to a month in advance.
  • Page 79 Selecting Auto Speed If the length of the videotape is not long enough for a timer recording in the SP mode, set the recording tape speed to “Auto”. Recording will start in the SP mode. If the length is not long enough, the tape speed will automatically change from SP mode to SLP mode.

  • Page 80: Using The Tv Buttons On The Remote Control

    If your television is compatible with the remote control, it will switch off. It is now programmed to operate with the remote control. If several codes are indicated for your television brand, try each one in turn until you find one that works. You can then control the television using the following buttons.

  • Page 81: Troubleshooting

    E M O Troubleshooting Before contacting a Samsung authorized service If you are unable to solve the problem after reading the above instructions, note: - The model and serial number on the rear of your DVD-VCR - The warranty information - A clear description of the problem Then contact your nearest SAMSUNG service center.
  • Page 82 Don't use this unless absolutely necessary. • Go to the contents and find the section of the instruction book If you experience that contains the explanations regarding the current problem, and other problems.

  • Page 83: Technical Specifications

    POWER REQUIREMENT SYSTEM ENVIRONMENT WEIGHT - Samsung Electronics Co., Ltd reserves the right to change the specifications with out notice. - Weight and dimensions are approximate. 2 Stereo audio inputs, RCA Connector, -8dbm, 47KΩ, front and rear 2 Composite video inputs, RCA Connector, 75Ω, 1Vp-p 1 Stereo audio outputs, RCA Connector, -8dbm, 1.5KΩ...
  • Page 84 E M O ENG-84...
  • Page 85 E M O ENG-85...
  • Page 86 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region CANADA North America MEXICO U.S.A ARGENTINE BRAZIL CHILE COSTA RICA ECUADOR EL SALVADOR GUATEMALA Latin America JAMAICA...

  • Page 87: Limited Warranty To Original Purchaser

    One (1) Year Parts / Ninety days (90) Labor This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States, and does not include transportation, installation, removal or reinstallation.
  • Page 88 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. ☎ 1-800-SAMSUNG (7267864) / www.samsung.com Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 1-800-SAMSUNG (7267864) www.samsung.com...
