Summary of Contents for HANNspree HL326HPB
-
Page 2: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................5 PRECAUTIONS....................5 SPECIAL NOTES ON LCD MONITORS ............6 BEFORE YOU OPERATE THE MONITOR ............7 FEATURES......................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 INSTALLATION INSTRUCTIONS ..............8 POWER....................... 8 SETTING THE MONITOR ON THE WALL .......... - Page 3 【Optional, depend on selected model】 Socket-outlet shall be near the equipment and shall be accessible. Trademark Notice: HANNspree products incorporate High-Definition Multimedia Interface (HDMI ) technology. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 4 User’s Manual RECYCLING INFORMATION We, the HANNspree care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels.
-
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the • Power Switch and then turn it on again to make sure the flicker disappears. -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 80,0cm / 31.5”Wide Screen TFT Color LCD Monitor GP Green Product Ergonomic Design Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor Screen Base... -
Page 8: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS INSTALL REMOVE Figure.1. Installing and Removing the Base INSTALLATION: 1. Align the monitor with the opening in the base. 2. Note that the longer section of the base points forward. 3. Snap the monitor into its base. A clear click sound will affirm that the base is connected correctly. -
Page 9: Setting The Monitor On The Wall
*Installing the LCD Monitor requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. HANNspree bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask a... -
Page 10: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC Turn off your computer before performing the procedure below. -
Page 11: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. -
Page 12: Front Panel Control
User’s Manual FRONT PANEL CONTROL • Power Button: Press this button to switch ON/OFF of monitor’s power. • Power Indicator: Blue — Power On mode. Red — Power Saving/Off mode. • MENU / RETURN: Turn the OSD menu on/off or return to the previous menu. •... -
Page 13: Remote Control
User’s Manual REMOTE CONTROL Installing battery Remove the battery cover, and insert two AAA (1.5V) batteries; make sure that the polarity of the battery is consistent with the marks "+/-" in the battery slot. Precautions of remote control usage Point the remote control to the receiver window. The objects between remote control and the receiver window may disturb the normal operation. -
Page 14: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS Press ''MENU'' key on the remote control or on the control panel, then the monitor will display the main menu. Picture Mode S tandard Contrast 1. Press "◄ / ►" key on the remote control or '' ▲/▼ '' Brightness key on the control panel to select the adjustment sort menu, PICTURE... - Page 15 User’s Manual SOUND Operation Range Item Function Selects a sound type when viewing programs or • Standard videos that support multiple sounds. • Music Sound mode *TIPS: You can press SMODE button on the • Movie remote control to change the Sound Mode directly. •...
-
Page 16: Plug And Play
User’s Manual Allow to select the key lock: On, Off. On / Off Key Lock Allow you to restore the factory settings. Reset Sofeware Allow you to update software using USB. Update(USB) SCREEN Item Function Operation Range Press ▼ / ▲ button to select Auto Adjust, then press Auto Adjust OK button to auto adjust Press ▼... -
Page 17: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS Problem Reason Solution screen display, no sound, indicator Power plug is loose, or Check if the power cord is connected is off. power supply isn't properly. connected. Image has no color. 1. - Page 18 60cm / 23.6” (16:9) 62,5cm / 24.6 (16:9) 70cm / 27.5” (16:10) 1920×1200@60Hz 1920×1200@50Hz And if you still have display problem after doing the above procedure, please visit Hanns support and Service Website: http://www.hannspree.eu/en/monitors. Windows is a registered trademark of Microsoft Corporation.
-
Page 19: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, if the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT: Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 20 User’s Manual 1920×1080p@50Hz 1920×1080p@60Hz ** We ensure that the monitor can be lighted under interlace signal mode, but we can not guarantee the image quality.
-
Page 21: Appendix
3.0 kg (6.6 lb) *** The above specification is subject to actual product specification and is subject to change without prior notice. NOTES: The Maximum Resolution will depends on the display card supporting. Related issue can refer to http://www.hannspree.eu/en/monitors FAQ section.
