Specifications; Warranty - Acoustic Energy Aegis Evo Series Owner's Manual

Treble Unit: 25 mm silk fabric dome. Anti-reflection pole. Ferro fluid
cooled and damped. Magnetically shielded. Metal chassis
Mid/Bass Unit: 120 mm pressed-steel chassis. Pressed alloy cone with
32mm thermally bonded voice coil. High-power long-
throw magnet system. Magnetically shielded.
Bass Unit: 160 mm die-cast chassis. Alloy cone, with 25 mm coil,
high power, long throw magnet system. Magnetically
shielded. [Aegis EVO Three ]
Cabinet: 15mm MDF enclosure. Low diffraction front baffle. High-
power, gas-flowed, low-turbulence bass reflex porting.
Terminals: Gold-plated, bi-wire , binding posts.
Aegis Evo One
Treble Unit 1
Mid/Bass Unit 1
Bass Unit 0
Power Handling 100 Watt max.
Crossover 3.3kHz 3 order
rd
Frequency response ± 3dB 50Hz – 20kHz
Frequency response - 6dB 38Hz – 22kHz
Sensitivity 89dB / 1W / 1M
Impedance 8 Ohm
Cabinet 25mm front baffle
Full internal bracing
Weight (excl. packaging) 7kg each
Dimensions (WxHxD) 192 x 362 x 235 mm

Specifications

Aegis Evo Three Aegis Evo Centre
1 1
1 1
1 1
150 Watt max. 150 Watt max.
3.5kHz 3 , 3.1kHz 3 ,
rd rd
330Hz 2 order 275Hz 2 order
nd nd
40Hz – 20kHz 60Hz – 20kHz
36Hz – 22kHz 50Hz – 22kHz
90.5dB / 1W / 1M 91.5dB / 1W / 1M
8 Ohm 8 Ohm
25mm front baffle 21mm front baffle
Full internal bracing Lateral wave absorber
Double enclosure
16kg each 7kg
192 x 880 x 220 mm 460 x 172 x 192 mm
Your Acoustic Energy loudspeakers are guaranteed against original defects in
materials, manufacture and workmanship for 3 years from the date of
purchase. Please retain all original packaging materials for possible future use.
We suggest that you complete details of purchase now and keep this
information in a safe place for future reference.
Under this warranty Acoustic Energy agrees to repair any defect or, at the
company's discretion, replace the faulty component(s) without charge for parts
and labour. This warranty does not imply any acceptance by Acoustic Energy
or its agents for consequential loss or damage and specifically excludes fair
wear and tear, accident, misuse or unauthorised modification.
This warranty is applicable in the United Kingdom only and does not in any
way limit the customer's legal rights. Claims and enquiries under the warranty
for AE products purchased outside the UK should be addressed to the local
importers or distributors.
If you have reason to claim under the warranty please contact your dealer in
the first instance.

Warranty
