Philips BT1005 Manual

Register your product and get support at
www.philips.com/welcome
BT1005, BT1000
4222.002.8569.1
1 2
7
2
5
3
1,5
2
1
1
5
4
7
5
2 1
3
1 5
7 8
2
1
10
11
ENGLISH
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that Philips
offers, register your product at www.philips.com/
welcome.
Important
Read this important information carefully before
you use the appliance and save it for future
reference.
Warning
- This appliance can be used by children aged
from 8 years and above and by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and if they understand the hazards involved.
- Cleaning and user maintenance shall not be
made by children unless they are older than
8 and supervised.
- Keep the appliance out of the reach of children
aged less than 8 years.
- Children should be supervised to ensure that
they do not play with the appliance.
3
Caution
- Always check the appliance before you use it.
Do not use the appliance if any of its parts is
damaged or broken, as this may cause injury.
- Only use this appliance for its intended
purpose as shown in the user manual .
- If the appliance is subjected to a major change
6
in temperature, pressure or humidity, let the
appliance acclimatise for 30 minutes before
you use it.
- For hygienic reasons, the appliance should only
be used by one person.
- Do not immerse the motor unit in water or
any other liquid, nor rinse it under the tap.
9
- Be careful with hot water when you clean
the attachments. Always check if the water
is not too hot, to prevent your hands from
getting burnt.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
- Only run the appliance on one
1.5V LR6 AA battery.
- Use and store the appliance at a temperature
between 15°C and 35°C.
- Do not expose the appliance to direct sunlight.
- Remove the battery from the appliance if you
are not going to use it for some time.
- Maximum noise level: Lc= 75 dB(A).
Compliance with standards
- This Philips appliance complies with all standards
regarding electromagnetic fields (EMF).
Preparing for use
Placing the batteries
Open the battery holder and put the
1
batteries into the battery holder. (Fig. 1)
Make sure your hands are dry when inserting the
batteries.
Make sure the + and - poles of the batteries point
in the right direction.
Close the battery holder.
2
Using the appliance
When you trim for the first time, be careful and
test the appliance on a small part of your arm or
leg. Do not move the trimmer too fast,
make smooth and gentle movements.
Trimming with comb
Slide the comb to the desired hair
1
length (Fig. 2).
The hair length in millimeters appears in the
window in the centre of the comb.
Note: When you trim for the first time, start at the
highest length setting to familiarise yourself with the
appliance.
Switch on the appliance.
2
Place the trimmer on the skin.
3
Move the trimmer slowly over the skin
4
against the direction of the hair growth while
pressing it lightly (Fig. 3).
Make sure the flat surface of the comb always stays
in contact with the skin.
If a lot of hair has accumulated in
the comb:
Make sure the appliance is switched off.
1
Slide the comb to the highest setting and pull
2
it off the appliance (Fig. 4).
Never pull off the comb at the flexible top part,
always pull it off at the bottom part.
Blow and/or shake the hairs out of the
3
comb (Fig. 5).
Trimming without comb
Use the trimmer without comb to trim full bears
and single hairs.
Note: The comb keeps the cutting unit at a certain
distance from the skin. If you use the trimmer without
comb, the hair will be cut off at the point where the
cutting unit touches the hair.
Switch on the appliance.
1
Make well-controlled movements. Touch the
2
hair lightly with the trimmer. (Fig. 6)
Cleaning
Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as
petrol or acetone to clean the appliance.
Switch off the appliance.
1
If the comb is on the appliance, pull it off.
2
Flip the cutting unit open.
3
Clean the cutting unit and the hair chamber
4
with the brush supplied. (Fig. 7)
Close the cutting unit by pushing it back onto
5
the appliance ('click').
Replacement
If the cutting unit is damaged or worn, always
replace it with the original Philips cutting unit.
