- Page 1 SyncMaster 755 Color Monitor Owner’s Instructions...
- Page 2 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Regulatory Information........ -
Page 4: Safety Instructions
Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket. Openings in the monitor cabinet are provided for ventilation. -
Page 5: Unpacking Your Monitor
Unpacking Your Monitor Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Stereo input cable DC input cable Left output cable Speaker Assembly Monitor Warranty Card Driver Installation Diskette Manual... -
Page 6: Your New Monitor
(Note: Left and right speakers are not identical.) Install the two retainers ( a, b ) at the two front-most holes on left and right side of the monitor and then put a third retainer ( c ) in the rear-most hole on left and right side of the monitor. -
Page 7: Connecting Your Monitor & Speakers
Your New Monitor Connecting Your Monitor & Speakers Caution : Turn the power off to the monitor, computer and speakers before connecting or disconnecting the speakers. Signal cable Connect the end of the signal cable to your computer’s video port. If you are... -
Page 8: Control Viewing Angle
Your New Monitor Control Viewing Angle Control the viewing angle to allow the user optimum viewing. (This monitor can tilt up and down from 4 to 11 degrees.) Control Turn the stand feet underneath the monitor to control viewing angle. -
Page 9: Multimedia Speakers
BBS button Push the BBS (Bass Boost Sound) button to amplify a specific frequency band for audio. (The BBS purpose is to amplify 6-8 dB at 100 Hz band. Therefore, the amplification provided by the BBS is dependant on input signal.) -
Page 10: Front Panel
Exit / Source ( ) button [Exit] Exit Closes the OSD. It is also used to return to the previ- ous menu when using the OSD. [Source] With the menu off, selects PC or Video source. Two source indicator LEDs on the right of the control but- ton indicate currently active PC or Video source. -
Page 11: Direct Access Buttons
Your New Monitor Direct Access Buttons Most of the adjustments you make to your monitor will be accessed through the OSD described in the next section. The Contrast and Brightness features can also be accessed directly from the front of your monitor. -
Page 12: Operation
On Screen Display (OSD) Your monitor has an OSD, accessed by the buttons on the front of your monitor, that allows you to adjust characteristics of the screen image. Display changes are indicated by on-screen adjustment icons. Some functions have sub-menus. -
Page 13: Monitor Function Control
Icon Monitor Function Control Brightness Background brightness of screen. – Decreases brightness + Increases brightness Contrast Contrast of screen image. – Decreases contrast + Increases contrast Horizontal Position Horizontal screen position. – Moves screen left + Moves screen right Vertical Position Vertical screen position. -
Page 14: Pincushion
Straightens screen vertical edges. – Curves image inward + Curves image outward Geometry Trapezoid Width of top and bottom of screen. – Widens bottom of screen + Widens top of screen Parallelogram – Skews screen image left + Skews screen image right Rotation –... -
Page 15: Language
+ 6500k more red Halftone – Off + On Zoom – Reduces view of display area + Enlarges view of display area Operation 1 2 3 4 5 6 7 8 + - : English Language English Access Function Exit Menu Advanced... -
Page 16: Video Control
Color Change the richness of color. Tint Change the tone of color. Degauss Removes color distortion caused by magnetic fields. Do not use more than once in 30 minutes. Recall Returns monitor to original settings. – No + Yes Display Timing Monitor display settings. -
Page 17: Troubleshooting
Troubleshooting Before calling for service, check the information in this section to see if you can solve the problem yourself. If you do need assistance, please call the phone number on the warranty card, the phone number on the back cover of this manual, or contact your dealer. -
Page 18: Powersaver
This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you move the computer's mouse or press a key on the keyboard. -
Page 19: Specifications
Video signal Audio signal • 500 mVrms over than 47 kW Power Supply • AC 100-240 V ± 10%, 60 Hz / 50 Hz ± 3 Hz Power Consumption • 100 W maximum Dimensions/Weight • Unit (Without Speakers): 16.53 x 16.81 x 15.04 inch / 37.5 lbs. -
Page 20: Index
Access, 9 Advanced, 13 Brightness, 8, 11,14 Color, 14 Color temperature, 13 Connecting your monitor & Speakers, 5 Contrast, 8, 11,14 Degauss, 14 Dimension, 17 Display modes, 16 Display timing, 14 Driver software, 15 Frequency, 16 Front panel, 8 Geometry, 12 Halftone, 13 H- Moiré, 13... -
Page 21: Regulatory Information
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This... - Page 22 Saturno 44 Col. Nva. Industrial Vallejo Del. Gustavo A. Madero C.P. 07700 Mexico D.F. Tel. 5747-5100 RFC: SEM950215S98 IMPORTADO POR:SAMSUNG ELECTRONICS MEXICO S.A. DE C.V. SATURNO 44 COL. NVA. INDUSTRIAL VALLEJO DEL. GUSTAVO A. MADERO C.P. 07700 MEXICO D.F. RFC: SEM950215S98 EXPORTADO POR: SAMSUNG ELECTRONICS CO.,LTD.
