Lorex ACCANT08 Quick Start Manual

Specifications
Frequency 2400~2500 MHz
Max Gain 8 dBi
Max Input Power =<20 mW
VSWRL <=2.0
Connector N Female
50 Ω
Wave Impedance
Horizontal signal pattern (3 dB beam width): 360°
(H-plane)
Vertical signal pattern (3 dB beam width): 10°
(E-plane)
Mounting Type Mast (optional)
Weight 0.9lbs (390g)
Dimensions 16 × 1.2 × 1.2"
(415 × 35 × 35mm)
Dimensions
16" / 415mm
(without stand)
1.2" / 35mm
(diameter)
Features
• 360° horizontal signal pattern
• 10° vertical signal pattern
Resources
Need Help?
Visit us online for up-to-date software and
complete instruction manuals
1
Visit lorextechnology.com
Search for the model number
2
of your product
Click on your product in the
3
search results
4
Click on the Downloads tab
Copyright © 2017 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves
the right to modify product design, specifications and prices, without
notice and without incurring any obligation. E&OE. All rights reserved.
2.4 GHZ Omni-Directional Antenna
Quick Start Guide
English Version 1.0
ACCANT08_QSG_EN_R1
