Samsung SGH-X210 User Manual

SGH-X210
User's Guide
This guide explains how to set up your phone and gives a quick overview
of the main functions of the phone.
Depending on the software installed or your service provider or country,
*
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
Printed in Korea
Code No.: GH68-10964A
World Wide Web
http://www.samsungmobile.com English(EU). 05/2006. Rev.1.0
Silent disables all sounds on the phone, when pressed and held in Idle
mode mode. To exit, press and hold this key again.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Menu Phonebook Soft key function
indicators
Using the menus
In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of
the display show the current soft
key functions. Press the left soft
key ( ) or right soft key ( ) to
perform the function indicated.
To exit the menu
without changing the
To return to the
menu settings, press
previous menu
this key.
level, press the
soft key or c .
Use the 4-way navigation keys ( ) as
shortcuts to access your favourite menus. Up is fixed
as a shortcut to FM Radio.
1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Short cut.
3. Select a key.
4. Select a menu to be assigned to the key.
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery cover
2. Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description
Received signal strength
Call in progress
Out of your service area; you cannot make or receive calls.
GPRS network
Roaming network
Silent mode or the call ringer set to Vibration
Mute mode
Call diverting feature active
IrDA feature active
New text message
New multimedia message
New voicemail message
Alarm set
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press the
Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select soft key or
the submenu.
If the selected menu contains additional submenus, repeat this step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1. Plug the supplied travel adapter.
To AC wall outlet
2. When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. To switch off the phone, press and hold
Changing the display language
1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Language.
3. Select a language.
Making a call
1. In Idle mode, enter the area code and phone number, and press
2. When you want to end the call, press .
Answering a call
1. When the phone rings, press the Accept soft key or
To reject the call, press the Reject soft key or
2. When you want to end the call, press .
Menu map
1. SIM AT* 4. Sound settings
4.1 Ring tone
2. Call records
4.2 Ring volume
2.1 Missed calls 4.3 Alert type
2.2 Received calls 4.4 Keypad tone
2.3 Dialled calls 4.5 Message tone
2.4 Delete all 4.6 Alert on call
to enter
2.5 Call time 4.7 Folder tone
2.6 Call cost* 4.8 Power on/off
4.9 Extra tones
3. Network services
5. Messages
3.1 Call diverting
3.2 Call barring 5.1 Text messages
3.3 Call waiting 5.2 Multimedia messages
3.4 Network selection 5.3 Push messages
3.5 Caller ID
3.6 Closed user group 6. Funbox
3.7 Band selection
6.1 WAP browser
6.2 Games
6.3 Sounds
6.4 Images
6.5 Delete all
6.6 Memory status
Phone layout and key functions
Web access/
Confirm key
In Idle mode, access the
web browser. Select the
highlighted option or
confirm input in a menu.
Dial key
Make and answer a call.
In Idle mode, retrieve
the most recent calls.
Voluem keys
Adjust the volume level
of the phone sounds.
Cancel/Clear key
Delete characters from
the display. Return the
display to the previous
menu level.

Adjusting the volume

1. In Idle mode, press the
for more than two seconds. 2. Select Sound settings
3. Press Up or Down to adjust the volume level.
4. Press the OK soft key.
While a call is in progress, press the Volume keys to adjust the earpiece
volume.
Changing a ringtone for calls
1. In Idle mode, press the
2. Select Sound settings
.
3. Select a ringtone.
Redialling recent numbers
1. In Idle mode, press
to answer a call.
2. Press Up or Down to scroll to the number you want.
.
3. Press to dial the number.
7. Organiser
7.1 Alarm
7.2 Calendar
7.3 Time & Date
7.4 Calculator
7.5 To do list
7.6 Voice memo
7.7 Currency exchange
8. FM Radio
9. Phone settings
9.1 Infrared activate
9.2 Display settings
9.3 Greeting message
9.4 Own number
9.5 Language
9.6 Security
9.7 Extra settings
9.8 Short cut
9.9 Reset settings
Soft keys
Perform functions
indicated by the
text above the key.
4-way navigation keys
In Menu mode, scroll
through menu options.
In Idle mode, access your
favourite menus directly.
Power/End key
Turn the phone on or
off when pressed and
held. Also end a call.
Silent mode key
Alphanumeric
keys
Menu soft key.
Ring volume.
→
Menu soft key.
→ Ring tone.
.
Press the Phonebook soft key
in Idle mode.
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
8 SDN*
* Show only if supported by your SIM
card.
