- Page 1 Owner's Manual TWO ROW COIN COUNTER WITH VALUE COUNTING FS-2D Please read and retain these instructions. Royal Sovereign International, Inc. To register your product, please go to www.royalsovereign.com...
-
Page 2: Table Of Contents
Thank you for purchasing the Royal Sovereign Two Row Coin Counter - FS-2D. This manual will provide you with safety information, instructions for optimal use, and proper care and maintenance for your product. Please read this manual carefully before operating. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS When using this machine follow these basic safety precautions to reduce risk of fire, electric shock, or injury. WARNING Plug the power cord into a properly grounded wall outlet. Do not alter the electric plug in any way. Do not use the machine if the power cord is damaged. -
Page 4: Box Contents & Product View
BOX CONTENTS Coin Wrapper Starter Pack Coin Counter PRODUCT VIEW COIN HOPPER LCD DISPLAY CONTROL PANEL COIN TUBES POWER SWITCH... -
Page 5: Quick Start Guide
QUICK START GUIDE 1. Plug the power cable into the wall power outlet. 2. On the back of the machine, flip the power switch to power on (A). 3. Insert preformed coin wrappers into the corresponding coin tubes (B). 4. Push the rows back into place. 5. -
Page 6: Front Panel
FRONT PANEL Option A Option B RUN / STOP Press "RUN / STOP" to start and stop the machine. MODE Once the machine is turned on, by default, the display will show the total dollar amount counted (OPTION A). Press the "MODE" button to switch to the count values by denomination (OPTION B). The individual coin count options display the dollar value and total coins counted by denomination. -
Page 7: Product Operation
PRODUCT OPERATION Place the machine on a sturdy and level work surface. Make sure coin rows are pushed back into place. Place coin wrappers into the corresponding tubes. For accurate coin sorting, it is important that the coin wrappers be inserted all the way to the bottom of the tubes and that they do not extend above the top edge of the tube (you may operate the machine without coin wrappers). - Page 8 PRODUCT OPERATION (CONTINUED) 8. When a tube in the front row is full, the machine will stop sorting and the display will indicate which coin tube is full by showing a blinking letter, either Q,N,P,D (quarter, nickel, penny, dime). 9. When a coin tube is full, pull the tube tray, where the full tube is located, forward.
-
Page 9: Coin Wrapping
COIN WRAPPERS Royal Sovereign coin sorters can be used with or without coin wrappers. We recommend using coin wrappers to help with your coin organization. Royal Sovereign preformed coin wrappers easily slide into coin tubes for easy and hassle free coin wrapping. Once full, simply slide the full coin wrappers out of the tubes and crimp the top of the wrapper (SEE BELOW). -
Page 10: Troubleshooting
TROUBLESHOOTING Symptom Check 1. Check that the power cord is plugged in. 2. Check that the power switch is turned on. 1. Motor does not run. 3. Push the 'RUN/STOP' button again. 4. Check that the tube trays are positioned properly. 2. -
Page 11: Product Registration Specifications
Registration is quick and easy! SPECIFICATIONS MODEL FS-2D Speed Up to 312 coins/min Motor Type AC synchronous Power Consumption 9.6 W... -
Page 12: Warranty
ONE YEAR LIMITED WARRANTY Royal Sovereign International, Inc. warranties this product to be free from defects in material and workmanship for a period of one (1) year. This warranty is extended to the original purchaser only. This warranty only covers products that are properly installed, properly maintained, and properly operated in accordance with the instructions provided.
