- Page 1 Open your gate by mobile phone! Installation and user’s manual Release 3.0 Firmware 2.2.4...
- Page 2 A PRODUCT MADE IN ITALY...
- Page 3 This means that the device does not need any programming for use. Simply ring the number of the inserted SIM card and BGates LT will activate the relay. Deactivate this feature if you prefer to have BGates LT open only for memorised numbers.
- Page 4 BGates LT Open your gate with an APP or by calling your BGates LT Open a motorised gate, such as your front gate, Phone calls are always toll-free: BGates LT recognises the caller’s number and opens the gate, thus refusing the call. The only costs...
- Page 5 Installation PRECAUTIONS FOR INSTALLATION Make sure that the product is intact after removing the Do not let the device come into direct contact with water • • packaging. or extreme heat, moisture or heat shock: see the chapter “installation”. The system must be installed in compliance with current •...
- Page 6 Relay: 230V maximum voltage, maximum current 1A with • resistive load (0.4A inductive load). BGates LT can operate in two modes: Action Type: 1 B-U. • Pulse (factory default setting): the device closes the relay for Dimensions: 9-unit module for DIN rail.
- Page 7 Figure 1...
- Page 8 Acceptance of the command will be confirmed by the rapid automate the opening. flashing of the right LED (looking at the label and reading BGates). Once powered, BGates LT will proceed with registration on the GSM network. Registration may last a few minutes.
- Page 9 WIRING INSTRUCTION BGates LT BGates LT - Pulse Bistable/Timer for thermostat consensus...
- Page 10 WIRING INSTRUCTION BGates LT Bistable / Timer for resistive load Bistable / Timer with additional Relay for Poor signal < 9,0 - to use less then 230V/1A inductive load more then 230V/0.4A MMCX GSM external antenna...
- Page 11 ACTIVATION OF BGates LT Use the free APP available in the Apple Store and Google Play Store to make the activation of BGates LT faster and its use easier. BGates LT The APP allows you to open up to four gates (each gate must be controlled by a BGates LT device, each with its own SIM).
- Page 12 The password may contain only 4 numbers. 1. Preliminary steps Add the number of the SIM that you will insert into the BGates LT • Send an SMS using your mobile phone to the number active on •...
- Page 13 Please see the table “COMPLETE LIST OF FUNCTIONS” for instructions on how to delete NB: We strongly recommend that you do not give your BGates enabled numbers, how to enable or disable password to any other users, but instead authorise each mobile the SMS response to commands and all other phone number individually.
- Page 14 Some functions are only available for devices with: *Firmware 2.1.2 and above / ** Firmware 2.2.4 and above. To know the version of your device, use the “13” function. Complete list of functions To change the features of BGates LT, send an SMS to BGates LT writing the “Command Text” Function Command text via SMS...
- Page 15 Function Command text via SMS Note Change password A response SMS “Your password has oldpassword,P,newpassword Default password: 0000 been changed” will be sent to you as ex. to change the default password (0000) confirmation. with a new one (1234) type: 0000,P,1234 Enabling a new mobile phone to You will receive an SMS message password,I,phonenumber...
- Page 16 Function Command text via SMS Note Changing the response SMS text to password,E,T7,new text Default SMS: command 1 “Change Password” “Your password has been changed” (max 160 characters) Activating a response SMS for password,E,A1 This function is already factory Enabling/Deleting activated (default) a mobile phone number Deactivating a response SMS for...
- Page 17 Check the status of the BGates LT password,E,PING You will receive a response SMS with the status of the BGates LT device, the device (status, firmware, antenna) firmware version and the level of antenna signal strength (ex. LT Running, firmware x.y.z, signal 20.0)
- Page 18 Checking status in bistable mode Call and hang up before the time-delayed A response SMS will provide relay status response set (default 10 sec.) (ex. “LT ON” or “LT OFF”) Change bistable response text (ON) password,E,T1,new text default response SMS: “BGates ON”...
- Page 19 DELAY ANSWER Feature that can be activated to solve the problem of double relay opening. On some networks, if the telephone call disconnection is not properly managed, this new feature implements a timed control that verifies the actual disconnection of the telephone call. Function Command text via SMS Note...
- Page 20 Caution: These functions are only available for devices with firmware 2.2.4 and above. To know the version of your device, use the “13” function. TIMER New timed switching off mode. The device closes the relay and reopens it automatically when the set time expires.
- Page 21 SMS COMMANDS As an alternative to calling, you can activate the device relay in the foreseen operating modes (Pulse, Bistable and Timer) by sending an sms. Function SMS Command Notes Device activation in pulse mode password,PULSE,seconds Sets the device to pulse mode and simultaneously activates the relay for the specified duration (max 60 (You can send an sms to activate the relay seconds).
- Page 22 Default SMS response: “Timer ON” (max 160 characters) Change Timer (OFF) response text password,E,T9,new text Default SMS response: “Timer OFF” (max 160 characters) Change pulse state text password,E,T10,new text Default SMS response: “LT in pulse mode” (max 160 characters)
- Page 23 How much does the BGates LT App cost? Is a professional installer required? The BGates LT APP is totally free and can be downloaded from the The BGates LT device is easy to install, just power and connect it to the opening consent (key, button, etc.) of the automation (gate, Apple and Google Android stores.
- Page 24 How much does the call cost to open the gate? Can I customise the response SMS? The call is completely toll-free given that the BGates LT device Sure, you can change all of the SMS texts via App or SMS.
- Page 25 The obligation of the warranty on equipment manufactured or sold by Business Gates Srl, as identified by the BGates brand, covers the Business Gates Srl is not subject to warranty obligations for faults, failures...
- Page 26 Business Gates Srl is not liable for any delays in carrying out work under Gates Srl. Anyone with equipment that meets the expected requirements warranty. and as above but has not purchased it from Business Gates Srl but from Delays or failure to provide payment, even partial, of the supply shall other Companies (retailers, installers and manufacturers of all types) suspend any warranty.
- Page 27 Monday to Friday Only in English 9.00h - 13.00h / 14.00h - 18.00h e-mail Business Gates S.r.l. info@bgates.it Via Ripamonti, 44 20141 Milano Tel. 02 52 20 18 38 - Fax 02 52 20 18 20 www.bgates.it - info@bgates.it...
