- Page 1 HP NJ5000-5G-PoE+ Walljack Switch Getting Started Guide Part number: 5998-7331 Document version: 5W100-20150430...
- Page 2 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an...
-
Page 3: Table Of Contents
Setting terminal parameters ·································································································································· 11 Logging in to the Web interface for the first time ······························································································· 11 Setting the working mode ············································································································································ 13 Support and other resources ········································································································································ 14 Contacting HP ································································································································································· 14 Subscription service ··············································································································································· 14 Related information ························································································································································ 14 Documents ······························································································································································ 14 Websites ·································································································································································... -
Page 4: Preparing For Installation
Keep the chassis and installation tools away from walkways. • Examining the installation site The HP NJ5000-5G-PoE+ must be used indoors. To ensure correct operation and long service life of your switch, install it in an environment that meets the requirements described in Table... -
Page 5: Accessories Provided With The Switch
Accessories provided with the switch × 1 × 1 Wall-mounting bracket Ethernet network cable × 2 × 2 M3.5 × 25 Phillips-head screw(Length:25mm) M3.5 × 12 Phillips-head screw(Length:12mm) × 1 × 1 M2.9 × 4 Phillips-head screw(Length:4mm) M2.9 × 4 security Torx-10 screw(Length:4mm) Installation preparation checklist Before you install the switch, verify the following items: Connect the power cord and connect the switch to the network. -
Page 6: Installing The Switch
The NJ5000-5G-PoE+ Walljack is designed to be mounted on a standard NEMA-WD6 (US) or BS 4662 (International)electrical outlet box. You can also install the HP NJ5000-5G-PoE+ using the optional HP unified wired-WLAN walljack table/flush wall mount kit (JL022A). This kit, which is purchased separately, lets you install the switch on a horizontal surface or wall. - Page 7 Figure 2 Securing the mounting bracket to an electrical outlet box (US) Connect the network cable from the electrical outlet box to the RJ-45 uplink port on the back of the HP NJ5000-5G-PoE+. Figure 3 Connecting the network cable Align the installation hole in the rear of the switch with the standout on the mounting bracket.
- Page 8 Figure 4 Aligning the installation hole Push the HP NJ5000-5G-PoE+ onto the mounting bracket, and then slide it down until it is fully engaged. Then secure the switch to the bracket by using the Phillips-head screw or security-head security Torx-10 screw. Do not release the HP NJ5000-5G-PoE+ until you confirm that it is secured...
-
Page 9: Installing The Switch On A Wall
Figure 5 Securing the HP NJ5000-5G-PoE+ Installing the switch on a wall Before installing the HP NJ5000-5G-PoE+ on a wall, make sure the surface of the wall can support a minimum weight of 0.9 kg (2 lbs) and extra cables. - Page 10 Place the mounting bracket, with the UP arrow pointing up, on the wall mount panel. Use four mounting screws to secure the bracket to the panel. Figure 7 Attaching the mounting bracket to the wall mount panel Connect the network cable from the panel to the RJ-45 uplink port on the back of the HP NJ5000-5G-PoE+.
- Page 11 Align the installation hole in the rear of the switch with the standout on the mounting bracket. Push the HP NJ5000-5G-PoE+ onto the mounting bracket, and then slide it down until it is fully engaged. Then secure the switch to the bracket by using the Phillips-head screws or security-head security Torx-10 screws.
-
Page 12: Installing The Switch On A Horizontal Surface
Place the mounting bracket, on the mount panel, and then use four mounting screws to secure the bracket to the panel. Connect the network cable from the panel to the RJ-45 Uplink port on the back of the HP NJ5000-5G-PoE+. -
Page 13: Accessing The Switch For The First Time
Accessing the switch for the first time Logging in to the CLI Setting up configuration environment The first time you access the switch you must use a console cable (RJ-45 connector for console cable,user supplied) to connect a configuration terminal, for example, a PC, to the console port on the switch, as shown in Figure Figure 10 Connecting the console port to a terminal... -
Page 14: Setting Terminal Parameters
Emulation—VT100 Logging in to the Web interface for the first time IMPORTANT: For security purposes, HP recommends that you change the login information and assign access permissions immediately after the first successful login. By default, HTTP and HTTPS are enabled. - Page 15 If aDHCP server is available, the device obtains an IP address from the server. To identify the ¡ address, log in to the device through the console port, and then execute the display ip interface brief command. The following is the sample output: <HP> display ip interface brief *down: administratively down (s): spoofing Interface...
-
Page 16: Setting The Working Mode
When the switch operates in unmanaged mode, you do not need to configure the switch. • When the switch operates in managed mode, you can configure the switch at the CLI or the Web • interface. HP recommends that you use the Web interface. For more information about switch configuration, see the user guide. -
Page 17: Support And Other Resources
Related information Documents To find related documents, browse to the Manuals page of the HP Business Support Center website: http://www.hp.com/support/manuals For related documentation, navigate to the Networking section, and select a networking category. •... -
Page 18: Conventions
Conventions This section describes the conventions used in this documentation set. Command conventions Convention Description Boldface Bold text represents commands and keywords that you enter literally as shown. Italic Italic text represents arguments that you replace with actual values. Square brackets enclose syntax choices (keywords or arguments) that are optional. Braces enclose a set of required syntax choices separated by vertical bars, from which { x | y | ... - Page 19 Network topology icons Represents a generic network device, such as a router, switch, or firewall. Represents a routing-capable device, such as a router or Layer 3 switch. Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports Layer 2 forwarding and other Layer 2 features.
-
Page 20: Appendix A Chassis Views And Technical Specifications
Appendix A Chassis views and technical specifications Overview Figure 12 shows the back and bottom views of the HP NJ5000-5G-PoE+. Figure 12 HP NJ5000-5G-PoE+ views... -
Page 21: Ports
• the back of the unit. Reset button The reset button is accessible through a hole on the side panel of the HP NJ5000-5G-PoE+. To reboot the HP NJ5000-5G-PoE+: Insert a paper clip into the reset button hole. Press and hold the button for less than 5 seconds. -
Page 22: Weights And Dimensions
86 mm (3.39 in) Depth 35 mm (1.38 in) Weight 200g (7.05 oz) Power consumption Chassis Minimum power consumption Maximum power consumption HP NJ5000-5G-PoE+ 6.7W 26.8 W Storage media and memory specifications Item Description Storage media Flash 32 MB Memory... -
Page 23: Appendix B Leds
Appendix B LEDs Figure 13 shows the status LEDs on the HP NJ5000-5G-PoE+. Figure 13 LED Table 3 LED status descriptions Status Description The switch is powered by 802.3at PoE+ and the power Steady green supply is operating correctly. Flashing green The switch is powered on and is performing a self-test. - Page 24 Status Description The switch is operating in managed mode. Management mode LED The switch is operating in unmanaged mode.
