- Page 1 A / V D I S T R I B U T I O N & C O N T R O L S Y S T E M S Instruction Manual SP503.1 SP523.1 SP522.1...
-
Page 2: Speaker Wire
RUSSOUND speakers, they combine acoustic technology with durabil- ity and will provide years of musical enjoyment. An added feature of model SP503.1 and model SP522.1 is the dual-voice coil design. This is unique in that both left and right signals can function in one speaker, which is ideal for installations in bathrooms, laundry rooms, hallways, etc. -
Page 3: Other Acoustic Considerations
Figure1 Russound ceiling mount speakers may be used for rear surround sound channels by placing them (1) behind, (2) on each side of the viewing position or (3) in the ceiling just behind the viewers. The available SP550.2 & SP650.1 speakers also make excellent, unobtrusive front channel home theater speakers for 5 channel listening. -
Page 4: Speaker Wire Paths
Russound Ceiling Speakers, skip to the section “cutting holes”. But if you want your speakers to completely blend in with a colored wall or accent the surface, now is the time to paint your Russound speakers’ outer frames and perforated grilles. -
Page 5: Hooking Up Your Speakers
- If you want a custom look, install an outlet box against a stud and cover it with a single outlet plate which has one hole in the middle for the wires to exit from OR order from your Russound dealer a Russound Stereo Pair Wall Plate Connector. -
Page 6: At The Speaker End
BLACK speaker terminal. - Make sure that no stray strands of wire have gotten detached and are touching the other main wire. 7. Repeat Steps 1 through 6 for the other Russound Ceiling Speaker. Figure 5 Figure 4 AT THE AMPLIFIER END 1. -
Page 7: Final Assembly
* Swap the wires attached to the left and right speaker terminals. A QUICK TROUBLESHOOTING GUIDE Before returning your Russound Speakers for service, it is a good idea to check out these simple remedies first. No sound from either speaker: 1. - Page 8 TAKING CARE OF YOUR NEW CEILING SPEAKERS RUSSOUND Ceiling Speakers are designed to last the life of your home if you follow a few simple rules. The main “killers” of any loudspeaker system are: • too little power at high volumes •...
-
Page 9: Warranty
Proof of Receipt must accompany all claims. During the warranty period Russound will replace any defective part and correct any defect in work- manship without charge for either parts or labor. For this warranty to apply, the unit must be installed and used according to its written instructions. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS SP503.1 Frequency Response: 68Hz - 18kHz Construction: Dual Voice Coil, Dual Drive 5.25" Polymica cone with coni- cal high frequency driver. Moisture resistant Sensitivity: 88dB Min / Max Power: 10 to 60 W/Channel Impedance: 4 Ohm, 8 Ohm, 16 Ohm (depending on wiring) - Page 11 NOTES...
