SONIQ QMS310B User Manual

CD Micro System for iPod
User's Guide
iPod not included
SAFETY PRECAUTIONS
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE.
TO AVOID ELECTRICAL SHOCK, DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL
ONLY.
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED
WITH LIQUID, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
DO NOT TOUCH THE LENS
CAUTION: INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED
AVOID EXPOSURE TO BEAM
Warnings:
• The AC adaptor is used as disconnect device and it should remain readily operable during intended used. In order to
disconnect the apparatus from the mains completely, the AC adaptor should be disconnected from the mains socket
outlet completely.
• Minimum 10 cm (4 inches) distances around the apparatus for sufficient ventilations.
• Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths,
curtains, etc.
• No naked flame sources such as lighted candles should be placed on the apparatus.
On Safety
As the laser beam used in this disc player could be harmful to the eyes, do not attempt to disassemble the casing. Refer
servicing to qualified personnel only.
• Do not put any foreign objects in the disc compartment. If you do so, the laser beam interlock may be defeated allowing
the laser to remain on when the lid is opened.
• Do not put any foreign objects in the DC IN jack. Should any objects or liquids fall into the unit, disconnect the power
supply and have the unit checked by qualified personnel before any further operation.
On Operation
Since the CD system offers a wide dynamic range, the peaks of the high level inputs are recorded with high fidelity, and
the noise level is very low. Do not turn up the volume while listening to a part of the disc with no audio signals or very low
level inputs. If you do so, the speakers may be damaged when the peak level of the sound is played. The lens of the laser
should be kept clean. Do not touch the lens. If you do so, the lens may be damaged and the unit will not operate correctly.
On Use
Use the apparatus in moderate climates. Never use the unit where it would be subject to:
- Heat sources such as radiators or air ducts.
- Direct sunlight.
- Excessive dust.
- Moisture or rain.
- Mechanical vibration or shock.
- Uneven surface.
• Do not place any heavy objects on top of the unit.
• When the unit is used with an AC power adapter, do not wrap the unit in a cloth, blanket, etc. If you do so, the
temperature inside and outside the unit may rise considerably, resulting in malfunctioning of the unit.
• If the unit is brought directly from a cold to a warm location, or is placed in a very damp room, the moisture may
condense on the lens inside the unit. Should this occur, the unit will not operate. In this case, remove the disc and
leave the unit in a warm place for several hours until the moisture evaporates.
• For the unit to operate at its best, it should not be subject to temperatures below 41°F (5°C) or above 95°F (35°C).
ACCESSORIES
Remote Control ................................................................................................................................................. x 1
AC Adapter ...................................................................................................................................................... x 1
iPod Dock Adaptor ............................................................................................................................................x 6
Hotline ..............................................................................................................................................................x 1
Warranty Card ..................................................................................................................................................x 1
Instruction Manual .............................................................................................................................................x 1
LOCATION OF CONTROLS
Unit
1
2
3
4
5
6
7
8
9
10
19
20
QMS310B
1
2
3
This product contains
a low power laser
4
device.
5
6
7
Using the Remote Control Correctly
• Point the remote control at the REMOTE SENSOR located on the unit.
• When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded,
causing unreliable operation.
• The recommended effective distance for remote operation is about 6 meters (19 feet).
To Change Battery
ATTENTION
Remove the plastic sheet before
operating the remote control.
Battery Replacement
When the battery becomes weak, the operating distance of the remote control is greatly reduced and you will need to
replace it.
Note: If the remote control is not going to be used for a long time, remove the battery to avoid damage caused by
battery leakage corrosion.
WARNINGS:
• Do not dispose of battery in fire; battery may explode or leak.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
CAUTION: When discarding batteries, environmental problems must be considered and local rules or laws governing the
disposal of these batteries must be strictly followed.
1. CD Door
2. Left Speaker
11 3. STANDBY Indicator
4. STANDBY/ON Button
5. Remote Sensor
12
6. PLAY/PAUSE Button
13
14
7. STOP/BAND Button
15
8. / PROG/MEM Button
16
17 9. - VOL + (VOLUME) Buttons
18
10. iPod Docking
11. Right Speaker
12. Display
13. TIMER Indicator
14. FUNCTION Button
15. / TUNING+ Button
16. Earphone Jack
17. / TUNING- Button
18. SLEEP Button
19. DC IN 12V Jack
21
20. AUX IN Jack
21. FM Antenna
REMOTE CONTROL
1. PRESET EQ Button
2. ON/STANDBY Button
8
3. SLEEP Button
9
4. /PROG/MEM Button
10
5. RANDOM Button
11
6. /MEM.UP Button
7. STOP/BAND Button
12
8. FUNCTION Button
9. TIMER Button
13
10. DISPLAY Button
11. / Button
12. VOLUME +/- Buttons
13. PLAY/PAUSE Button
1. Open the battery door.
2. Insert one CR2025 (3V) size battery.
- 1 -
POWER SOURCES
USING THE AC ADAPTER
Using an AC adapter other than the one supplied with the unit may damage the unit. This AC adapter operates on AC
100V~240V,50Hz/60Hz.
To "DC IN 12V" jack
AC adaptor
CAUTIONS:
• Before use, ensure the rated voltage of the adaptor matches your local voltage.
• The included AC adaptor is for use with this unit only. Do not use it with other equipment.
• If you are not going to use the unit for a long time, disconnect the AC adaptor from the wall outlet.
• Whenever the AC adaptor is plugged in to a wall outlet, electricity is running through the unit, even when the power
switch is turned off.
FM ANTENNA
• Do not connect the FM antenna to an outside antenna.
VOLUME ADJUSTMENT
To Adjust the Volume
Use the VOL + / - buttons to adjust the VOLUME levels.
For Personal Listening
Connect headphones(Ø3.5mm stereo mini plug) to the PHONES jack. Adjust the VOLUME levels to obtain the desired
volume.
When headphones are connected, the speakers are automatically disconnected.
CAUTION: Excessive sound pressure from earphones and headphones can cause hearing loss.
CLOCK SETTING
Setting the clock can only be done in STANDBY mode.
• If the unit is plugged in with the supplied AC adapter and the unit is in
standby mode, the standby indicator illuminates.
1. Press and hold the PROG/MEM/ button until the hour digits blink.
2. Press the or button to adjust the desired hours then press the
PROG/MEM/ button once to confirm. The minute digits will blink.
3. Press the or button to adjust the desired minutes then press the
PROG/MEM/ button once to start clock.
Notes:
• After setting clock, if you disconnect the unit from the AC power, then re-
connect it, the unit clock will restore to "0:00", and you can set it again.
• In CD/RADIO/ iPod/ AUX IN mode, press the DISPLAY button once to
display the current time.
LISTENING TO THE RADIO
1. Press the STANDBY/ON button to turn the unit on.
2. Press the FUNCTION button to radio mode.
3. Press the BAND/ STOP button to select a band (MW/FM).
4. Press the or button to tune in to a station.
LISTENING TO THE RADIO
• Adjust the volume levels.
Searching for a Station Automatically
• Press and hold the or button until the tuner starts searching for a station, then release. After tuning in a station,
the search stops.
• The search may not stop at a station with a very weak signal.
To AC
outlet
