Summary of Contents for Philips 243S5
- Page 1 243S5 www.philips.com/welcome EN User manual Customer care and warranty 18 Troubleshooting & FAQs...
-
Page 2: Table Of Contents
4.1 Resolution & Preset Modes ..16 5. Power Management ....17 6. Customer care and warrant ..18 6.1 Philips’ Flat Panel Monitors Pixel Defect Policy ......18 6.2 Customer Care & Warranty ..21 7. Troubleshooting & FAQs ..22 7.1 Troubleshooting ...... -
Page 3: Important
• Please use approved power cord The Philips guarantee applies provided provided by Philips all the time. If the product is handled properly for your power cord is missing, please its intended use, in accordance with... - Page 4 1. Important off immediately and disconnect the Service power cord. Then, remove the for- • The casing cover should be opened eign substance or water, and send it only by qualified service personnel. to the maintenance center. • If there is any need for any docu- • Do not store or use the monitor in ment for repair or integration, locations exposed to heat, direct...
-
Page 5: Notational Descriptions
1. Important 1.2 Notational Descriptions 1.3 Disposal of product and packing material The following subsections describe notational conventions used in this Waste Electrical and Electronic document. Equipment-WEEE Notes, Cautions and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold or italic type. - Page 6 From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails participation in national take- back initiatives and recycling programs whenever possible, preferably...
-
Page 7: Setting Up The Monitor
Top Victory Investments Ltd. or one of its a liates. Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license. - Page 8 2. Setting up the monitor 243S5LJMB/243S5LHMB Connecting to your PC 1. Place the monitor face down on soft 243S5LDAB and smooth surface taking care to avoid scratching or damaging the screen. 2. Hold the stand with both hands. (1) Gently attach the stand to the AC power input VESA mount area.
-
Page 9: Operating The Monitor
2. Setting up the monitor 243S5LHMB 2.2 Operating the monitor Front view product description 243S5LDAB 243S5LJMB/243S5LHMB AC power input HDMI input VGA input Audio input Earphone output Kensington anti-theft lock Connect to PC 1. Connect the power cord to the back of the monitor firmly. -
Page 10: The Osd Menu
On-Screen Display. You can use On-Screen Display (OSD) is a feature in this as a reference when you want to all Philips LCD monitors. It allows an end work your way around the different user to adjust screen performance or adjustments later on. - Page 11 2. Setting up the monitor Swivel Resolution notification This monitor is designed for optimal performance at its native resolution, 1920 × 1080 @ 60 Hz. When the monitor is powered on at a different resolution, an alert is displayed on screen: Use 1920 °...
-
Page 12: Remove Base Stand And Base
2. Setting up the monitor 243S5LJMB/243S5LHMB 2.3 Remove Base Stand and Base 1. Extend the monitor base to its Remove the Base Stand maximum height. Before you start disassembling the monitor base, please follow the instructions below to avoid any possible damage or injury. -
Page 13: Image Optimization
3. Image Optimization 3. Image Optimization 3.1 SmartContrast What is it? A unique technology that dynamically analyzes displayed content and automatically optimizes an LCD monitor's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds. -
Page 14: Technical Specifications
4. Technical Specifications 4. Technical Specifications Picture/Display Monitor Panel Type TN-LCD Backlight W-LED system Panel Size 23.6" W (59.9 cm) Aspect Ratio 16:9 Pixel Pitch 0.272 × 0.272 mm SmartContrast 10,000,000:1 Response Time (typ.) SmartResponse Time (typ.) Optimum Resolution 1920 × 1080 @ 60Hz Viewing Angle 170°... - Page 15 4. Technical Specifications Normal Operation 20.1 W(typ.) 20.2 W(typ.) 20.3 W(typ.) Sleep (Standby) <0.5 W(typ.) <0.5 W(typ.) <0.5 W(typ.) <0.3 W(typ.) <0.3 W(typ.) <0.3 W(typ.) AC Input Voltage AC Input Voltage AC Input Voltage Heat Dissipation* at 230VAC , at 100VAC , 50Hz at 115VAC , 60Hz 50Hz 68.60 BTU/...
- Page 16 4. Technical Specifications <1.706 BTU/ <1.706 BTU/ <1.706 BTU/ Sleep (Standby) hr(typ.) hr(typ.) hr(typ.) <1.024 BTU/ <1.024 BTU/ <1.024 BTU/ hr(typ.) hr(typ.) hr(typ.) Power LED indicator On mode: White, Standby/Sleep mode: White (blinking) Power Supply Built-in, 100-240VAC, 50-60Hz Dimension Product with stand 560 ×...
- Page 17 Finish Texture Note 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net for registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet.
-
Page 18: Resolution & Preset Modes
4. Technical Specifications 4.1 Resolution & Preset Modes Maximum Resolution 1920 × 1080 @ 60 Hz (analog input) 1920 × 1080 @ 60 Hz (digital input) Recommended Resolution 1920 × 1080 @ 60 Hz (digital input) H. freq Resolution V. freq (Hz) (kHz) 31.47 720 ×... -
Page 19: Power Management
5. Power Management The following setup is used to measure 5. Power Management power consumption on this monitor. If you have VESA DPM compliance • Native resolution: 1920 × 1080 display card or software installed in • Contrast: 50% your PC, the monitor can automatically • Brightness: 100% reduce its power consumption when • Color temperature: 6500k with full... -
Page 20: Customer Care And Warrant
Pixel Defect Policy single black pixel. Other combinations of lit and dark sub pixels appear as Philips strives to deliver the highest single pixels of other colors. quality products. We use some of the industry's most advanced manufacturing... - Page 21 'off'. That is, the warranty period, a TFT Monitor a dark dot is a sub-pixel that stands out panel in a Philips flat panel monitor on the screen when the monitor displays must have pixel or sub pixel defects a light pattern.
- Page 22 6. Customer care and warranty BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 5 or fewer 2 adjacent dark subpixels 2 or fewer 3 adjacent dark subpixels Distance between two black dot defects* >15mm Total black dot defects of all types 5 or fewer TOTAL DOT DEFECTS ACCEPTABLE LEVEL...
-
Page 23: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 24: Troubleshooting & Faqs
• Disconnect the monitor from mains • First, ensure that the power button power source immediately for safety on the front of the monitor is in the • Contact with Philips customer OFF position, then press it to the service representative immediately. ON position. -
Page 25: General Faqs
For further assistance, refer to the An "after-image", "burn-in" or "ghost Consumer Information Centers list image" remains after the power has and contact Philips customer service been turned off. representative. • Uninterrupted display of still or static images over an extended period may cause "burn in", also known as... - Page 26 • Shut down your computer, disconnect your old monitor and Q7: How should I clean the LCD reconnect your Philips LCD monitor. surface? • Turn on your monitor and then turn Ans.: For normal cleaning, use a clean, on your PC.
- Page 27 PC, workstation or Mac? repaired. The damage mentioned above Ans.: Yes. All Philips LCD monitors are is not covered under your warranty. fully compatible with standard Q12: Why is my Display not showing PCs, Macs and workstations.
- Page 28 Top Victory Investments Ltd. or one of its affiliates. Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license.
