USER'S MANUAL
The Mounting Bracket: To remove the mounting bracket from the
Heat Alarm base, hold the Heat Alarm base firmly and twist the
mounting bracket counterclockwise. The mounting bracket installs
120V AC/DC POWERED 135ºF FIXED AND 15ºF/MINUTE onto the junction box. It has a variety of screw slots to fit most boxes.
RATE-OF-RISE HEAT ALARM WITH BATTERY BACK-UP
The Power Connector: The power connector plugs into a power
input block on the Heat Alarm. It supplies the unit with AC power.
• The black wire is "hot."
• The white wire is neutral.
• The orange wire is used for interconnect.
If you need to remove the power connector, disconnect AC power
at the electrical panel; insert a flat screwdriver blade between
the power connector and the security tab inside the power input
block. Gently pry back the tab and pull the connector free.
120V AC ~ 60 Hz 0.07Amps
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
This user's manual contains important information about your Smoke The basic installation of this Heat Alarm is the similar whether you want to
install one Heat Alarm, or interconnect more than one Heat Alarm. If you are
Alarm's operation. If you are installing this Smoke Alarm for use by others,
you must leave this manual—or a copy of it—with the end user. interconnecting more than one Heat Alarm, you MUST read "Special Requirements
for Interconnected Heat Alarms" below before you begin installation.
Printed in Mexico CONFORMS TO
Model HD6135FB
M08-0026-008 K1 5/16 UL STD 539
ELECTRICAL SHOCK HAZARD. Turn off power to the area where you will install this
unit at the circuit breaker or fuse box before beginning installation. Failure to turn off
© 2016 BRK Brands, Inc. All rights reserved. Distributed by BRK Brands, Inc. First Alert is
®
the power before installation may result in serious electrical shock, injury or death.
registered trademark of The First Alert Trust. 3901 Liberty Street Road, Aurora, IL 60504-8122
Consumer Affairs: (800) 323-9005 www.firstalert.com www.brkelectronics.com 1. Remove the mounting bracket from the base. Position the screw slots on the
mounting bracket over the screws in the junction box. Tighten the screws.
FIRE SAFETY TIPS
2. Using wire nuts, connect the power connector to the household wiring.
Follow safety rules and prevent hazardous situations: 1) Use smoking materials properly. Never
smoke in bed. 2) Keep matches or lighters away from children; 3) Store flammable materials in
proper containers; 4) Keep electrical appliances in good condition and don't overload electrical
Improper wiring of the power connector or the wiring leading to the power connector
circuits; 5) Keep stoves, barbecue grills, fireplaces and chimneys grease- and debris-free; 6)
will cause damage to the Alarm and may lead to a non-functioning Alarm.
Never leave anything cooking on the stove unattended; 7) Keep portable heaters and open
flames, like candles, away from flammable materials; 8) Don't let rubbish accumulate. STAND-ALONE ALARM ONLY:
Keep alarms clean, and test them weekly. Replace alarms immediately if they are not working • Connect the white wire on the power connector to the neutral wire in the junction box.
properly. Heat and Smoke Alarms that do not work cannot alert you to a fire. Keep at least one
• Connect the black wire on the power connector to the hot wire in the junction box.
working fire extinguisher on every floor, and an additional one in the kitchen. Have fire escape
ladders or other reliable means of escape from an upper floor in case stairs are blocked. • Tuck the orange wire inside the junction box. It is used for interconnect only.
INTERCONNECTED UNITS ONLY:
BEFORE YOU INSTALL THIS HEAT ALARM
Strip off about 1/2" (12 mm) of the plastic coating on
Important! Read "Recommended Locations for Heat Alarms" and "Locations to Avoid
the orange wire on the power connector.
for Heat Alarms" before beginning. This unit monitors the air, and when heat reaches its
• Connect the white wire on the power connector to the neutral wire in the junction box.
sensing chamber, it alarms. It can give you more time to escape before fire spreads. This
unit can ONLY give an early warning of developing fires if it is installed, maintained and
• Connect the black wire on the power connector to the hot wire in the junction box.
located where heat can reach it, and where all residents can hear it, as described in this
manual. This unit will not sense gas, smoke, or flame. It cannot prevent or extinguish fires.
• Connect the orange wire on the power connector to the interconnect wire in the junction
box. Repeat for each unit you are interconnecting. Never connect the hot or neutral
Know Where To Install Your Heat Alarms wires in the junction box to the orange interconnect wire. Damage may result.
See "Recommended Locations For Heat Alarms" and
• Never cross-connect hot and neutral wires between interconnected Alarms. Damage will result
"Locations To Avoid For Heat Alarms" for details.
3. Plug the power connector into the back of the Heat Alarm.
Know What Heat Alarms Can and Can't Do
4. Position the base of the Alarm over the mounting bracket and turn. The Alarm can be
A Heat Alarm can help alert you to fire, giving you precious time to escape. It can only sound
positioned over the bracket every 60°. Turn the Alarm clockwise (right) until the unit is in place.
an alarm once heat reaches the sensor. See "Limitations of Heat Alarms" for details.
5. Check all connections.
Check Your Local Building Codes
STAND-ALONE ALARM ONLY:
This Heat Alarm is designed to be used in a typical single-family home. It
alone will not meet requirements for boarding houses, apartment buildings,
• If you are only installing one Heat Alarm, restore power to the junction box.
hotels or motels. See "Special Compliance Considerations" for details.
INTERCONNECTED UNITS ONLY:
• If you are interconnecting multiple Heat Alarms, repeat steps 1-5 for each Heat
Alarm in the series. When you are finished, restore power to the junction box.
• This device is not intended to alert hearing impaired residents. Smoke Alarms
specifically designed for the hearing impaired, which feature devices like flashing
strobe lights, are available to alert the hearing impaired in case of fire.
ELECTRICAL SHOCK HAZARD. Do not restore power until all Heat
Alarms are completely installed. Restoring power before installation is
• Installation of this Heat Alarm must conform to the electrical codes in your area;
complete may result in serious electrical shock, injury or death.
Articles 210 and 300.3 (B) of the National Electrical Code (NFPA 70), NFPA 72, NFPA
101; SBC (SBCCI); NBC (BOCA); OTFDC (CABO), and any other local or building codes
6. Make sure the Heat Alarm is receiving AC power. Under normal
that may apply. Wiring and installation must be performed by a licensed electrician.
operation, the green light (LED) will shine continuously.
Failure to follow these guidelines may result in injury or property damage.
• This Heat Alarm is not a Smoke Alarm. This unit is not suitable protection
when used alone. Do not use this unit as the only means of fire detection in
a home. This unit is intended for use as a supplement to Smoke Alarms.
• This Heat Alarm must have AC or battery power to operate. If the AC power
fails, battery back-up will allow the alarm to operate for a limited time. If AC
power fails and the battery is dead or missing, the alarm cannot operate.
• This unit must be powered by a 24-hour, 120VAC 60Hz circuit. Be sure the
circuit cannot be turned off by a switch, dimmer, or ground fault circuit
interrupter. Failure to connect this unit to a 24-hour circuit and keeping fresh
The locking features are designed to discourage unauthorized removal of the battery or alarm. It is not necessary to
batteries installed, may prevent it from providing constant protection.
activate the locks in single-family households where unauthorized battery or alarm removal is not a concern.
• Never disconnect the power from an AC powered unit to stop an unwanted
These Heat Alarms have two separate locking features: one to lock the battery compartment, and the other to lock the
alarm. Doing so will disable the unit and remove your protection. In the
Heat Alarm to the mounting bracket. You can choose to use either feature independently, or use them both.
case of a true unwanted alarm, use the Silence Feature by pressing
the Test/Silence button or fan the heat away from the unit. The alarm Tools you will need: Needle-nose pliers or utility knife Standard Flathead screwdriver.
will reset automatically when it returns to normal operation.
Both locking features use locking pins, which are molded into the mounting bracket. Using needle nose pliers or a utility knife,
• NEVER ignore any alarm. Read "If Your Heat Alarm Sounds" for more information remove one or both pins from the mounting bracket, depending on how many locking features you want to use.
on how to respond to an alarm. Failure to respond can result in injury or death.
• Test this Heat Alarm once a week. If it ever fails to test correctly, have it replaced
To permanently remove either lock insert a flathead screwdriver between the locking pin and the lock, and pry the pin out of the lock.
immediately! If the Alarm is not working properly, it cannot alert you to a problem.
• Connect this Heat Alarm ONLY to other compatible units. See "Special
Requirements for Interconnected Heat Alarms" for details. Do not connect
TO LOCK THE BATTERY COMPARTMENT
it to any other type of alarm or auxiliary device. Connecting anything else
to this unit may damage it or prevent it from operating properly.
• DO NOT stand too close to the unit when the alarm is sounding. It is loud to Do not lock the battery compartment until you have activated the battery and tested the battery back-up.
alert you in an emergency. Exposure to the horn at close range may harm your
1. Activate the battery back-up by removing the "Pull to Activate Battery Back-Up" tab.
hearing. When testing the unit, step back when the horn starts sounding.
DO NOT remove the battery activation until AC power is turned on to conserve battery power.
• Do not paint over the Heat Alarm. Paint may clog the openings to the
sensor and prevent the Heat Alarm from operating properly.
2. Press the Test/Silence button until you hear a brief acknowledge (or
feedback) chirp. The alarm will sound: 3 beeps, pause, 3 beeps, pause.

WEEKLY TESTING

If the unit does not alarm during testing, DO NOT lock the battery compartment! Install a new
• NEVER use an open flame of any kind to test this unit. You might accidentally battery and test again. If the Heat Alarm still does not alarm, replace it immediately.
damage or set fire to the unit or to your home. The built-in test switch accurately
3. Using needle-nose pliers or a utility knife, detach one locking pin from the mounting bracket.
tests the unit's operation as required by Underwriters Laboratories, Inc. (UL).
4. Push the locking pin through the black dot on the label on the back of the Heat Alarm.
• If the Alarm ever fails to test properly, replace it immediately.
Products under warranty may be returned to the manufacturer for
replacement. See "Limited Warranty" at the end of this manual.
• DO NOT stand close to the Alarm when the horn is sounding. Exposure at close range
may be harmful to your hearing. When testing, step away when horn starts sounding.
TO UNLOCK THE BATTERY COMPARTMENT
It is important to test this unit every week to make sure it is working properly. Press
and hold the test button until the alarm sends a test command acknowledge "chirp" just
before it sounds continuously (the unit will continue to alarm for a few seconds after you
release the button). If it does not alarm, make sure it is receiving power and has a fresh
Once the Heat Alarm is installed, you must disconnect it from the AC power before unlocking the battery compartment.
battery, and test it again. If it still does not alarm, it should be replaced immediately.
When testing one unit, all interconnected alarms will sound. If they don't, check the connection
with power to the units turned off, restore power and try again. Test all units in a series, ELECTRICAL SHOCK HAZARD. Turn off the power to the area where the Heat Alarm is installed before removing it from
not just one. Using the test button is the ONLY correct way to test the Heat Alarm.
the mounting bracket. Failure to turn off the power first may result in serious electrical shock, injury or death.
HOW THIS HEAT ALARM WORKS
Turn off the AC power at the circuit breaker or fuse box.
Fixed Temperature and Rate-of-Rise.
This Heat Alarm monitors the air and when heat reaches the sensor, it alarms. The 1. Remove the Heat Alarm from the mounting bracket. If the unit is locked to the bracket, see the section "To Unlock the Mounting Bracket."
unit will alarm either when the temperature reaches a fixed 135º F (57º C) or the
2. Disconnect the power connector by gently prying it away from the back of the Heat Alarm.
microprocessor detects a 15º F (8.3º C) per minute rate of rise temperature change.
This allows the unit to sense a heat rise and alarm prior to reaching the fixed
3. Insert a flathead screwdriver under the head of the locking pin, and gently pry it out of the battery
temperature of 135º F (57º C), providing quicker response to a potential fire.
compartment lock. (If you plan to relock the battery compartment, save the locking pin.)
Heat Alarms are intended for use as supplemental safety devices with Smoke Alarms. Heat Alarms
4. To relock the battery compartment, close the battery door and reinsert locking pin in lock.
are designed for use in areas where Smoke Alarms cannot be installed due to temperature and
environmental conditions, as in unheated garages and crawl spaces. A Heat Alarm can only give
5. Reconnect the power connector to the back of the Alarm, reattach the Heat Alarm to the mounting bracket, and restore the power.
early warning of a developing fire if it is properly installed and maintained and located where heat can
reach it. The unit will not sense gas, smoke or flame. Heat Alarms cannot prevent or extinguish fires.
When replacing the battery, always test the Heat Alarm before relocking the battery compartment.
This Heat Alarm is approved for use in single-family residences.
It is NOT designed for marine or RV use.
THE COVER OF YOUR HEAT ALARM
TO LOCK THE MOUNTING BRACKET
4 1. Power Light, Test/Silence Button
1. Using needle-nose pliers, detach one locking pin from mounting bracket.
2. Air Vents
3
2. Insert the locking pin into the lock located on the pivoting hinge of the battery door.
3. (Behind the Cover) Alarm Horn: 85 dB audible
2
alarm for test, alarm, and unit malfunction warning. 3. When you attach the Alarm to the mounting bracket, the locking pin's head will fit into a notch on the bracket.
4. Heat Sensor
1
TO UNLOCK THE MOUNTING BRACKET
HOW TO INSTALL THIS HEAT ALARM
ELECTRICAL SHOCK HAZARD. Turn off the power to the area where the Heat Alarm is installed before removing it
This Heat Alarm is designed to be mounted on any standard wiring junction box to a 4-inch (10
from the mounting bracket. Failure to turn off the power first may result in serious electrical shock, injury or death.
cm) size, on either the ceiling or wall (if allowed by local codes). Read "Recommended Locations
For Heat Alarms" and "Locations to Avoid For Heat Alarms" before you begin installation.
Tools you will need: Needle-nose pliers or utility knife Standard Flathead screwdriver.
Always discharge the branch circuit before servicing an AC or AC/DC Heat Alarm. First, turn
off the AC power at the circuit breaker or fuse box. Next, remove the battery from Alarms
with battery back-up. Finally, press the test button to discharge the branch circuit.
Make sure the Alarm is not receiving excessive noisy power. Examples of noisy
power could be major appliances on the same circuit, power from a generator 1. Insert a flathead screwdriver between the mounting bracket pin and the mounting bracket.
or solar power, light dimmer on the same circuit or mounted near fluorescent
2. Pry the Heat Alarm away from the bracket by turning both the screw- driver and the Heat Alarm counterclockwise (left) at the same time.
lighting. Excessive noisy power may cause damage to your Alarm.
1
THE PARTS OF THIS HEAT ALARM
1
3
The Parts of This Unit
1. Mounting Bracket
2
2. Mounting Slots and Screws
2 3. Locking Pins (break out of bracket)
4. Hot (Black) AC Wire
6
3
5. Neutral (White) AC Wire
4
5
6. Interconnect (Orange) Wire
7
7. Latch to Open Battery Compartment
8
8. Swing-Out Battery Compartment
9 9. Quick-Connect Power Connector
FOLLOW THESE INSTALLATION STEPS
7. If the green power indicator light does not light, TURN OFF POWER TO THE JUNCTION
BOX and recheck all connections. If all connections are correct and the power indicator
still does not light when you restore the power, the unit should be replaced immediately.
8. Test each Heat Alarm. Press the Test/Silence button until you hear a brief
acknowledge (or feedback) chirp. The alarm will sound: 3 beeps, pause, 3 beeps,
pause. When testing a series of interconnected units you must test each
unit individually. Make sure all units alarm when each one is tested.
If any unit in the series does not alarm, TURN OFF POWER and recheck connections.
If it does not alarm during testing when you restore power, replace it immediately.
SPECIAL REQUIREMENTS FOR INTERCONNECTED HEAT ALARMS
• Failure to meet any of these requirements could damage the units
and cause them to malfunction, removing your protection.
Interconnected units can provide earlier warning of fire than stand-alone units, especially if a fire
starts in a remote area of the dwelling. If any unit in the series senses heat, all units will alarm.
Interconnect units within a single family residence only. Otherwise all households will experience
unwanted alarms when you test any unit in the series. Interconnected units will only work
if they are wired to compatible units and all requirements are met. This unit is designed to
be compatible with: First Alert ® Smoke Alarm Model SA520 and BRK
Models 9120, 9120B, SC6120B, SC9120B, 7010, 7010B, 7020B, SC7010B, SC7010BV; BRK
CO Alarm Models CO5120BN, CO5120PDBN; BRK ® Heat Alarm Models HD6135F and
HD6135FB; BRK Auxiliary Devices Models RM4 (Relay Module), SL177 (Strobe Light).
®
See www.brkelectronics.com for most current interconnect list.
Interconnected units must meet ALL of the following requirements:
• A maximum of 18 compatible Smoke, Heat or CO Alarms may be interconnected. To
comply with NFPA limits, no more than 12 of the 18 alarms may be Smoke Alarms.
• The same fuse or circuit breaker must power all interconnected units.
• All wiring must conform to all local electrical codes and NFPA 70 (NEC). Refer to NFPA,
Chapter 2 and/or your local building code for further connection requirements.
}
A
5
5
4 4
3 3
2
1 1
A. Unswitched 120VAC B. To additional units; Maximum = 18 total
60 Hz source (Maximum 12 Smoke Alarms)
1. Heat Alarm 4. Wire Nut 7.
2. Ceiling or Wall 5. Junction Box
8.
3. 6.
Power Connector Neutral Wire (Wht)
LOCKING FEATURES
Locking Pin
2 3
REGULAR MAINTENANCE
This unit has been designed to be as maintenance-free as possible, but there
are a few simple things you must do to keep it working properly.
• Test it at least once a week.
• Clean the Heat Alarm at least once a month; gently vacuum the outside of the
Heat Alarm using your household vacuum's soft brush attachment. Test the Heat
Alarm. Never use water, cleaners or solvents since they may damage the unit.
• If the Heat Alarm becomes contaminated by excessive dirt, dust and/or grime, and
cannot be cleaned to avoid unwanted alarms, replace the unit immediately.
• Relocate the unit if it sounds frequent unwanted alarms. See
"Locations to Avoid for Heat Alarms" for details.
• When the battery becomes weak, the Heat Alarm unit will "chirp" about once a minute (the
low battery warning). You should replace the battery immediately to continue your protection.
Choosing a replacement battery:
Your Heat Alarm's battery back-up requires one standard 9V battery. The following
batteries are acceptable as replacements. This list supplements the list on the Heat
Alarm battery door: Eveready #522 (Energizer); Duracell #MN1604, MX1604 (Ultra). You
may also use a Lithium battery like the Ultralife U9VL-J, U9VL-J-P for longer service life
between battery changes. These batteries are available at many local retail stores.
• Always use the exact batteries specified by this User's Manual. DO NOT use
rechargeable batteries. Clean the battery contacts and also those of the device prior
to battery installation. Install batteries correctly with regard to polarity (+ and -).
• Please dispose of or recycle used batteries properly, following any local
regulations. Consult your local waste management authority or recycling
organization to find an electronics recycling facility in your area. DO NOT
DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
• Keep battery out of reach of children. In the event a battery is swallowed,
immediately contact your poison control center, your physician, or the National
Battery Ingestion hotline at 202-625-3333 as serious injury may occur.
Actual service life depends on the Heat Alarm and the environment in which it is
installed. Constant exposures to high or low temperatures or high humidity may reduce
battery life. All the batteries specified above are acceptable replacement batteries for
this unit. Use of a different battery may have a detrimental effect on Alarm operation.
Regardless of the manufacturer's suggested battery life, you MUST replace the
battery immediately once the unit starts "chirping" (the "low battery warning").
IF YOU SUSPECT A PROBLEM
Heat Alarms may not operate properly because of dead, missing or weak batteries, a
build-up of dirt, dust or grease on the Heat Alarm cover, or installation in an improper
location. Clean the Heat Alarm as described in "Regular Maintenance," and install a
fresh battery, then test the Heat Alarm again. If it fails to test properly when you use
the test button, or if the problem persists, replace the Heat Alarm immediately.
• If you hear a "chirp" once a minute, replace the battery.
® Smoke Alarm • If you experience frequent non-emergency alarms try relocating the Heat Alarm.
®
• If the alarm sounds when no smoke is visible, try cleaning or
relocating the Heat Alarm. The cover may be dirty.
• If the alarm does not sound during testing, make sure it is
receiving AC power from the household current.
Always discharge the branch circuit before servicing an AC or AC/DC Heat Alarm. First,
turn off the AC power at the circuit breaker or fuse box. Next, remove the battery from Heat
Alarms with battery back-up. Finally, press the test button to discharge the branch circuit.
Do not try fixing the alarm yourself – this will void your warranty!
If the Heat Alarm is still not operating properly, and it is still under warranty,
please see "How to Obtain Warranty Service" in the Limited Warranty.
6
}
7 B
IF THIS HEAT ALARM SOUNDS
8
RESPONDING TO AN ALARM
During an alarm, you will hear a loud, repeating horn pattern: 3 beeps, pause, 3 beeps, pause.
• If the unit alarms and you are not testing the unit, it is warning you of a
potentially dangerous situation that requires your immediate attention. NEVER
ignore any alarm. Ignoring the alarm may result in injury or death.
• Never disconnect the AC power or remove the battery back-up to
quiet an unwanted alarm. Disconnecting the power disables the alarm
so it cannot sense heat. This will remove your protection.
• If the unit alarms and you are not absolutely certain of the source
Interconnect
of the heat, get everyone out of the house immediately.
Wire (Orange)
Hot Wire (Blk)
• ELECTRICAL SHOCK HAZARD: Attempting to disconnect the power connector from
the unit when the power is on may result in electrical shock, serious injury or death.
When an interconnected system of units is in alarm, the Red LED on the unit(s) that initiated
the alarm will flash in sync with the horn. The LED will not flash on any remaining units.
WHAT TO DO IN CASE OF FIRE
•
Don't panic; stay calm. Follow your family escape plan.
• Get out of the house as quickly as possible. Don't stop to get dressed or collect anything.
• Feel doors with the back of your hand before opening them. If a door is cool, open it slowly.
Don't open a hot door. Keep doors and windows closed, unless you must escape through them.
• Cover your nose and mouth with a cloth (preferably damp). Take short, shallow breaths.
• Meet at your planned meeting place outside your home, and do
a head count to make sure everybody got out safely.
•
Call the Fire Department as soon as possible from outside. Give your address, then your name.
• Never go back inside a burning building for any reason.
• Contact your Fire Department for ideas on making your home safer.
UNDERSTANDING THE INDICATOR LIGHTS
AND ALARM HORN PATTERNS
Condition LED Horn
AC POWER ON LED shines GREEN Silent; no audible alarm
(Normal operation) continuously
DC POWER (Battery LED flashes GREEN One horn "chirp" to signal
back-up active) once per minute while loss of AC power
battery powers unit
RESUME AC POWER GREEN LED turns ON Horn "chirps" one time to signal
resumption of AC power
DURING TESTING (Under LED flashes RED, the Audible alarm: 3 beeps, pause,
AC or DC power) same pattern as the horn repeating horn pattern
ALARM CONDITION* LED flashes RED, the Audible alarm: 3 beeps, pause,
(Initiating Unit) same pattern as the horn repeating horn pattern
LATCHING ALARM ACTIVE** LED flashes RED once Silent; no audible alarm
(Under AC or DC Power) every 5 seconds
ALARM SILENCE LED flashes RED once No signal
every 5 seconds
LOW BATTERY GREEN LED flashes Horn "chirps" once per minute,
once every minute in sync with LED. NOTE: If
the battery is VERY LOW, the
horn may either chirp once per
second, or sound continuously
MALFUNCTION (Unit LED flashes RED rapidly Horn "chirps" three times, in
MUST be replaced) three times, in sync sync with three LED flashes
with three horn "chirps",
once every minute
*When any Heat Alarm in an interconnected series triggers an alarm, its red LED
will flash rapidly. The red LEDs will not flash on any remaining alarms in the series.
This feature helps responders identify which unit(s) triggered the alarm.
**The Latching Alarm indicator is activated after an Alarm is exposed to alarm
levels of heat. After heat levels drop below alarm levels, the LED begins to flash
RED once every 5 seconds. See "The Latching Alarm Indicator" for details.
USING THE SILENCE FEATURES
If you are absolutely certain the alarm is caused by a non-emergency, on-fire
situation, you may use the Silence Feature to silence the Alarm. The Silence
Feature on this unit can temporarily quiet an unwanted alarm for up to 15 minutes.
The Silence Feature is for your convenience only and will not correct a problem.
The Silence Feature is intended to temporarily silence the Alarm horn. It will not extinguish a fire.
To temporarily silence the alarm:
Press the Test/Silence button on the cover of the Heat Alarm that initiated the alarm.*
*To silence Heat Alarms in an interconnected series:
To silence multiple Alarms in an interconnected series, you must press the Test/
Silence button on the unit(s) that triggered the alarm. Pressing the Test/ Silence
button on a unit that did not trigger the alarm will only silence that Alarm.
NOTE: The red light under the Silence button on the initiating alarm will flash in
sync with the horn. The red light will be off on all other Heat Alarms.
If any unit will not silence and no heat is present install a new battery and re-test
it. If it still will not silence, the unit should be replaced immediately.
LOW BATTERY SILENCE FEATURE
If AC power is on, briefly press the Test/Silence button to silence the low battery "chirp" for
up to 8 hours. A brief "chirp" will let you know that the Alarm has accepted the Low Battery
Silence command. The Alarm will continue to operate as long as AC power is supplied. However,
replace the battery as soon as possible, to maintain protection in event of a power outage.
4
"LATCHING ALARM" INDICATOR

SPECIAL COMPLIANCE CONSIDERATIONS

The following recommendations reference location and usage of Smoke Alarms. Heat Alarms are
only intended as supplemental safety devices. Do not rely solely on Heat Alarms to alert you to fire.
This unit alone is not a suitable substitute for complete fire detection systems in
KEY:
places housing many people—like apartment buildings, condominiums, hotels, motels,
BEDROOM dormitories, hospitals, long-term health care facilities, nursing homes, day care
BEDROOM BEDROOM
LATCHING ALARM:
Unit was exposed facilities, or group homes of any kind—even if they were once single-family homes. It is
to alarm levels of Smoke not a suitable substitute for complete fire detection systems in warehouses, industrial
KITCHEN or Heat
GARAGE
facilities, commercial buildings, and special-purpose non-residential buildings which
HALL
LIVING ROOM LATCHING NOT ACTIVATED:
require special fire detection and alarm systems. Depending on the building codes in
Unit was not exposed
to alarm levels of Smoke your area, this unit may be used to provide additional protection in these facilities.
BASEMENT
or Heat
For your reference: The following is information on Smoke
Alarm usage in various residences and institutions.
The Latching Alarm Indicator is activated after an Alarm is exposed to alarm levels The following information applies to all five types of buildings listed below:
of heat. After heat levels drop below alarm levels, the red LED will begin to flash once
In new construction, most building codes require the use of AC or AC/DC powered Smoke
every 5 seconds. It will continue to flash or "latch" until you clear it using the Test/
Alarms only. AC, AC/DC, or DC powered Smoke Alarms can be used in existing construction
Silence button. Press and hold the Test/Silence button until the horn sounds.
as specified by local building codes. Refer to NFPA 72 (National Fire Alarm Code) and
This feature helps emergency responders, investigators, or service NFPA 101 (Life Safety Code), local building codes, or consult your Fire Department for
technicians identify which unit(s) in your home were exposed to alarm levels detailed fire protection requirements in buildings not defined as "households."
of heat. This can help investigators pinpoint the initiating alarm.
Single-Family Residence: Single family home, townhouse. It is recommended Smoke Alarms
be installed on every level of the home, in every bedroom, and in each bedroom hallway.
RECOMMENDED LOCATIONS FOR HEAT ALARMS
Multi-Family or Mixed Occupant Residence: Apartment building, condominium. This
In Single-Family Residences.
Smoke Alarm is suitable for use in individual apartments or condos, provided a primary fire
For minimum coverage, BRK Brands, Inc. recommends you install Heat Alarms in any area
detection system already exists to meet fire detection requirements in common areas like
not suitable for smoke alarms such as garages, kitchens, utility/laundry rooms, furnace
lobbies, hallways, or porches. Using this Smoke Alarm in common areas may not provide
rooms and crawl spaces. Install where temperatures normally remain between –10º F and
sufficient warning to all residents or meet local fire protection ordinances/regulations.
100º F (–23º C and 38º C). For National Fire Protection Association (NFPA) information,
see "Agency Placement Recommendations for Heat Alarms and Smoke Alarms."
Institutions: Hospitals, day care facilities, long-term health care facilities. This Smoke Alarm
is suitable for use in individual patient sleeping/resident rooms, provided a primary fire
RECOMMENDED PLACEMENT
detection system already exists to meet fire detection requirements in common areas like
lobbies, hallways, or porches. Using this Smoke Alarm in common areas may not provide
sufficient warning to all residents or meet local fire protection ordinances/regulations.
INTERCONNECTED HEAT ALARMS IN
Hotels and Motels: Also boarding houses and dormitories. This Smoke Alarm is suitable
GARAGES, KITCHENS, UTILITY/LAUNDRY
ROOMS, FURNACE ROOMS AND CRAWL for use inside individual sleeping/resident rooms, provided a primary fire detection
SPACES AND ONLY AS A SUPPLEMENT TO
SMOKE ALARMS. system already exists to meet fire detection requirements in common areas like lobbies,
BEDROOM
BEDROOM BEDROOM hallways, or porches. Using this Smoke Alarm in common areas may not provide
FOR MAXIMUM PROTECTION USE sufficient warning to all residents or meet local fire protection ordinances/regulations.
INTERCONNECTED SMOKE ALARMS WITH
KITCHEN BATTERY BACK-UP AS SHOWN.
HALL GARAGE Warehouses/Commercial Buildings: DO NOT use this Alarm in warehouses,
LIVING ROOM
industrial or commercial buildings, special-purpose non-residential buildings,
RVs, boats, or airplanes. This Alarm is specifically designed for residential use,
and may not provide adequate protection in non-residential applications.
BASEMENT
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital
Heat Alarms Recommended in New Home Construction
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
25 ft. 12.5 ft.
(7.8 m) (3.8 m) uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular
50 ft. installation. If this equipment does cause harmful interference to radio or television
(15 m)
reception, which can be determined by turning the equipment off and on, the user is
25 ft.
encouraged to try to correct the interference by one or more of the following measures:
(7.8 m)
25 ft. 25 ft. 12.5 ft. • Reorient or relocate the receiving antenna.
(7.8 m) (7.8 m) (3.8 m)
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that of the receiver.
Heat Alarms should be mounted on the bottom of the joists and not up in the joist channels.
• Consult the dealer or an experienced radio or TV technician for help.
• The recommended location for a Heat Alarm is at the center of the ceiling.
At this location, the Heat Alarm is closest to all areas of the room. Warning: Changes or modifications to the product, not expressly approved by First
Alert / BRK Brands, Inc., could void the user's authority to operate the equipment.
• If it is not practical to install the Heat Alarm in the center of the room, use an
off-center location not less than 4 inches (102 mm) from the sidewall. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
• If it is not practical to install the Heat Alarm on the ceiling, the next logical location
any interference received, including interference that may cause undesired operation.
is on a sidewall. A Heat Alarm mounted on a sidewall should have the top of the
unit between 4 and 12 inches (102 mm and 305 mm) from the ceiling.
LIMITATIONS OF HEAT ALARMS
• The smooth ceiling distance between Heat Alarms shall not exceed spacings as
determined by UL fire tests. This Heat Alarm has a 50 foot (15 meter) spacing.
This Heat Alarm is not a Smoke Alarm. This unit is not suitable protection
• Reduced spacing may be required due to factors such as exposed joists, drafts,
when used alone. Do not use this unit as the only means of fire detection in a
ceiling heights greater than 10 feet (3 meters), and other structural characteristics
home. This unit is intended for use as a supplement to Smoke Alarms.
that may affect Heat Alarm operation. Walls, partitions, doorways, and joists
interrupt the normal flow of heat creating new areas to be protected.
NFPA Standard 72 Appendix A-2-5.2.2.2 part c-d Heat Alarms are not life safety devices.
(c) The Spacing of Detectors: Where a room is too large for protection by a single
Heat Alarms are intended for use as supplements to Smoke Alarms. Because this
detector, several detectors should be used. It is important that they be properly
unit cannot detect smoke, carbon monoxide or other toxic gases, do not rely solely on
located so all parts of the room are covered. (d) Where the Distance Between
this Heat Alarm in a fire emergency. Slow developing fires may produce smoke and
Detectors Should Be Further Reduced: The distance between detectors is based on
toxic gasses without a significant increase in room temperatures. For this reason, Heat
data obtained from the spread of heat across a smooth ceiling. Where the ceiling is
Alarms are only to be installed as supplementary protection with Smoke Alarms.
not smooth, the placement of the detector should be tailored to the situation.
Heat Alarms cannot work without power. AC powered Heat Alarms and Smoke Alarms
For instance, with open wood joists, heat travels freely down the joist channels so that
cannot work if the AC power is cut off for any reason (open fuse or circuit breaker, failure along
the maximum distance between detectors [50 ft (15 m)] may be permitted to be used.
a power line or at a power station, electrical fire that burns the electrical wires, etc.). AC units
However, heat has trouble spreading across the joists, so the distance in this direction
with battery (DC) back-up: will operate if electricity fails, provided the batteries are fresh
should be 1/2 the distance allowed between detectors, as shown in the illustration
and correctly installed. AC and AC/DC units must be installed by a qualified electrician.
above ("Heat Alarms Recommended in New Home Construction") and the distance
to the wall is reduced to 12-1/2 ft. (3.8 m). Since 1/2 x 50 ft. (15 m) is 25 ft. (7.6 m), the Heat Alarms for Solar or Wind Energy users and battery backup power systems:
distance between detectors across open wood joists should not exceed 25 ft. (7.6 m), as AC powered Heat Alarms should only be operated with true or pure sine wave inverters.
shown in "Heat Alarms Recommended in New Home Construction," and the distance to Operating this Heat Alarm with most battery-powered UPS (uninterruptible power supply)
the wall is reduced [1/2 x 25 ft. (7.6 m)] to 12.5 ft. (3.8 m). Paragraph 2-5.2.2.4 requires products or square wave or "quasi sine wave" inverters will damage the Alarm. If you are
that detectors be mounted on the bottom of the joists and not up in joist channels. not sure about your inverter or UPS type, please consult with the manufacturer to verify.
Walls, partitions, doorways, ceiling beams, and open joists interrupt the Heat Alarms cannot sense fires if the heat does not reach them. Heat from fires
normal flow of heat, thus creating new areas to be protected. in chimneys or walls, on roofs, or on the other side of closed doors may not reach the
sensing chamber and set off the alarm. That is why one unit should be installed on every
AGENCY PLACEMENT RECOMMENDATIONS
floor, in the attic, basement and garage and only as a supplement to Smoke Alarms.
FOR HEAT AND SMOKE ALARMS
Heat Alarms may not sense heat from a fire on another level of the home. Example:
NFPA Appendix A-2-5.2.2: While Chapter 2 does not require heat detectors as part of a stand-alone unit on the second floor may not detect heat from a fire in a crawl space
the basic protection scheme, it is recommended that the householder consider the use until the fire spreads. This may not give you enough time to escape safely. That is why
of additional heat detectors...The additional areas lending themselves to protection
recommended minimum protection is at least one Smoke Alarm on every level of your
with heat detectors are: kitchen, dining room, attic (finished or unfinished), furnace home and Heat Alarms in any areas not suitable for Smoke Alarms. Even with a unit on
room, utility room, basement and integral or attached garages. For bedrooms, the every floor, stand-alone units may not provide as much protection as interconnected
installation of a smoke detector is preferable to the installation of a heat detector. units, especially if the fire starts in a remote area. Interconnected units may provide earlier
warning than stand-alone units since all units alarm when one senses heat or smoke.
The following recommendations reference location and usage of
Smoke Alarms. Heat Alarms are intended as supplemental safety
Heat Alarms may not be heard. The alarm horn loudness meets or exceeds the current UL
devices. Do not rely solely on Heat Alarms to alert you to fire. standard. However, if the device is installed outside the bedroom, it may not wake up a sound
sleeper or one who has recently used drugs or has been drinking alcoholic beverages. This is
NFPA 72 Chapter 29
especially true if the door is closed or only partly open. Even persons who are awake may not
hear the alarm horn if the sound is blocked by distance or closed doors. Noise from traffic,
29.5.1* Required Detection.
stereo, radio, television, air conditioner, or other appliances may also prevent alert persons from
29.5.1.1* Where required by other governing laws, codes, or standards for a specific type of
hearing the alarm horn. This alarm device is not intended for people who are hearing impaired.
occupancy, approved single and multiple-station smoke alarms shall be installed as follows:
Heat Alarms may not have time to alarm before the fire itself causes damage,
(1) *In all sleeping rooms and guest rooms
injury, or death, since heat from some fires may not reach the unit immediately.
Examples of this include persons smoking in bed, children playing with matches,
(2) *Outside of each separate dwelling unit sleeping area, within 21 ft (6.4 m) of any
or fires caused by violent explosions resulting from escaping gas.
door to a sleeping room, with the distance measured along a path of travel
This Heat Alarm is not foolproof. Like any electronic device, Heat Alarms are
(3) On every level of a dwelling unit, including basements
made of components that can wear out or fail at any time. You must test the
unit weekly to ensure your continued protection. Heat Alarms cannot prevent or
(4) On every level of a residential board and care occupancy (small facility),
extinguish fires. They are not a substitute for property or life insurance.
including basements and excluding crawl spaces and unfinished attics
Heat Alarms have a limited life. The unit should be replaced immediately if it is
(5) *In the living area(s) of a guest suite
not operating properly. In no case should it be used for more than 10 years.
(6) In the living area(s) of a residential board and care occupancy (small facility)

LIMITED WARRANTY

(Reprinted with permission from NFPA 72 ® , National Fire Alarm and Signaling Code Copyright © 2013
National Fire Protection Association, Quincy, MA 02269. This reprinted material is not the complete BRK Brands, Inc., ("BRK") the maker of First Alert
and official position of the National Fire Protection Association, on the referenced subject which is that for a period of ten years from the date of purchase, this product will be free from defects in
represented only by the standard in its entirety), (National Fire Alarm and Signaling Code and NFPA material and workmanship. BRK, at its option, will repair or replace this product or any component
®
72 ® are registered trademarks of the National Fire Protection Association, Inc., Quincy, MA 02269). of the product found to be defective during the warranty period. Replacement will be made with a
new or remanufactured product or component. If the product is no longer available, replacement
Smoke Alarms shall be installed in each separate sleeping room, outside each sleeping
may be made with a similar product of equal or greater value. This is your exclusive warranty.
area in the immediate vicinity of the bedrooms and on each additional story of the family
living unit, including basements and excluding crawl spaces and unfinished attics. This warranty is valid for the original retail purchaser from the date of initial retail purchase
and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain
In new construction, Alarms shall be so arranged that operation of any one
warranty performance. BRK dealers, service centers, or retail stores selling BRK products do not
Alarm shall cause the operation of all Alarms within the dwelling.
have the right to alter, modify or any way change the terms and conditions of this warranty.
Smoke Detection-Are More Smoke Alarms Desirable? The required number of Smoke
This warranty does not cover normal wear of parts or damage resulting from any of the
Alarms might not provide reliable early warning protection for those areas separated by a door
following: negligent use or misuse of the product, use on improper voltage or current, use
from the areas protected by the required Smoke Alarms. For this reason, it is recommended
contrary to the operating instructions, disassembly, repair or alteration by anyone other than
that the householder consider the use of additional Smoke Alarms for those areas for increased
BRK or an authorized service center. Further, the warranty does not cover Acts of God, such
protection. The additional areas include the basement, bedrooms, dining room, furnace room,
as fire, flood, hurricanes and tornadoes or any batteries that are included with this unit.
utility room, and hallways not protected by the required Smoke Alarms. The installation of Smoke
BRK shall not be liable for any incidental or consequential damages caused by the breach of any
Alarms in kitchens, attics (finished or unfinished), or garages is not normally recommended, as
these locations occasionally experience conditions that can result in improper operation. express or implied warranty. Except to the extent prohibited by applicable law, any implied warranty
of merchantability or fitness for a particular purpose is limited in duration to the duration of the
above warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation
California State Fire Marshal (CSFM)
of incidental or consequential damages or limitations on how long an implied warranty lasts, so
Early warning detection is best achieved by the installation of fire detection equipment
the above limitations or exclusion may not apply to you. This warranty gives you specific legal
in all rooms and areas of the household as follows: A Smoke Alarm installed in each
rights, and you may also have other rights that vary from state to state or province to province.
separate sleeping area (in the vicinity, but outside bedrooms), and Heat or Smoke Alarms
in the living rooms, dining rooms, bedrooms, kitchens, hallways, finished attics, furnace
How to Obtain Warranty Service
rooms, closets, utility and storage rooms, basements, and attached garages.
Service: If service is required, do not return the product to your retailer. In order to obtain
Additional local building and regulatory codes may apply in your area.
warranty service, contact the Consumer Affairs Division at 1-800-323-9005. To assist us in
Always check compliance requirements before beginning any installation.
serving you, please have the model number and date of purchase available when calling.
For Warranty Service return to: BRK Brands, Inc., 1301 Joe Battle, El Paso, TX 79936
Specific requirements for Heat or Smoke Alarm installation vary from state to state and
Battery: BRK Brands, Inc. make no warranty, express or implied, written or oral, including
from region to region. Check with your local Fire Department for current requirements
that of merchantability or fitness for any particular purpose with respect to battery.
in your area. If you install AC or AC/DC units, it is recommended they be interconnected
for added protection. Interconnect Smoke and Heat Alarms for added protection.
Visit www.firstalert.com for more information.
LOCATIONS TO AVOID FOR HEAT ALARMS
This unit works best when it's clean and nothing interferes with the sensor. If exposed to dirt,
grease, extreme temperatures not caused by fire (especially in attics where daily temperatures
can exceed the 135º F (57º C) alarm level or high humidity, it may sound "unwanted"
alarms. If Heat Alarms are installed where heat can't reach them–like in "dead air spaces"
Please record Date and Where Purchased:
or near fans–they may not be able to provide an early enough warning in case of fire.
________________________________________________________________
For best performance, do not install the Heat Alarm:
• Where temperatures are regularly below –20º F (–29º C) or above 115º F
(46º C), including unheated buildings, outdoor rooms, or porches.
• Do not install a Heat Alarm directly over the stove or range. Clean a
laundry room unit frequently to keep it free of dirt or lint.
• Near fresh air vents, ceiling fans, or in very drafty areas. Drafts can blow heat
away from the unit, preventing it from reaching the sensing chamber.
• In "dead air" spaces. Install units according to "Avoiding Dead Air Spaces".
• Less than 12 inches (305 mm) away from fluorescent lights.
Electrical "noise" can interfere with the sensor.
AVOIDING DEAD AIR SPACES
"Dead air" spaces may prevent heat from reaching the Heat Alarm. To avoid dead air spaces, follow
installation instructions in the "Recommended Locations for Heat Alarms" (refer to NFPA72 for details).
For wall mounting (if allowed by building codes), the top edge of Heat Alarms should be placed between
4 inches (102 mm) and 12 inches (305 mm) from the wall/ceiling line, below typical "dead air" spaces.
5
® brand and BRK ® brand products, warrants
Printed in Mexico M08-0026-008 K1 5/16
6
