User Manual
CHECK THE CONTENTS INSIDE THE PACKAGE BOX
The package box should contain the items indicated below plus IKVM-17080 / IKVM-17160. If any item is missing or damaged, please contact the seller
immediately.
Quick Installation Guide
Mounting Installation of KVM Device
STEP 1 : Mount the LCD to the rack
STEP 1 : Mount the LCD onto the rack
Caution:
1. Two installers are needed while installing the KVM
drawer device.
2. Care is needed during installation as the device
might be damaged.
STEP 2 : Install front and rear bracket on
cabinet (Both sides)
STEP 3 : Screw the KVM module into the
console from the back
Quick Guide
CD-ROM
KVM Cable
STEP 4 : Please fix KVM module with the rack mount bracket kit
STEP 5 : Finish installation as shown below
KVM Module
STEP 6 : Pull and turn the lock knobs (left and right at the same
Bracket Kit
time) and then put out the screen and open console to
operate
Knobs
IKVM-17080
IKVM-17160
Screw x 8
Power Cord
KVM Drawer
Knob
Unlock
Lock
