QUICK START GUIDE
Instructions
click
1. Slide the back plate of the flex
hose clip into the opening on the
front of the unit. You will hear a
"click" when it is locked in place.
6. Hold tool right side up and add
BISSELL No-Rinse Dog Shampoo
to the shampoo reservoir.
161-3727 11/17 RevB
BARKBATH
PORTABLE DOG BATH
2. Slide the lower plate of the
3. Insert screw and tighten with a
flex hose storage bracket into the
screwdriver.
opening on the back of the unit.
Make sure the screw hole lines up.
7. Hold the tool horizontally on a flat surface (such as table or counter
top) and attach it to the cleaner by inserting the flex hose connector into
the shampoo tool connector. You will hear a "click" when it locks in place.
Refer to the enclosed user guide for complete
instructions and important safety notices.
4. Get ready to prime the system.
5. With the unit elevated on a
Fill the base unit clean water tank
table, turn unit ON and press flex
with warm-to-the-touch tap water
hose trigger until water dispenses
to the fill line.
onto the mat on the floor.
8. Set Rinse/Shampoo switch to
9. With the base unit and reservoir
desired setting. For Shampoo, the
on a table, extend the hose
reservoir will dispense a mixture
and nozzle to the mat or towel
of shampoo and water; for Rinse,
on floor and spray trigger until
it will dispense just water.
solution dispenses.
1844, 1842, 2290 SERIES
WARNING
