Summary of Contents for Rosen AC 3105
- Page 1 ROSEN a new generation of leadership in mobile video AC 3105 External TV Tuner Owner's Manual and Installation Guide...
- Page 2 The Remote Control ... 6 Installation ... 7 Wiring ... 8 NOTICE OF INTENDED USE ROSEN ENTERTAINMENT SYSTEMS ARE DESIGNED TO ENABLE VIEWING OF VIDEO RECORDINGS ONLY FOR REAR-SEAT OCCUPANTS. MOBILE VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION.
- Page 3 Introduction The AC3105 is a TV Tuner for automotive entertainment systems. It requires a TV antenna suitable for automotive use (not in- cluded, available from your Rosen dealer). It can be connected to systems that use RCA audio and composite video connectors, and is capable of integrating into some Rosen systems (such as the Rosen A7) using an optional harness.
- Page 4 Using the AC3105 The AC3105 operates only when the ignition key switch is in the Run or Accessory positions. Operation of the tuner is performed with the remote control (see opposite page). When used with the Rosen A7, please see the A7 Owner’s manual for additional user instructions.
- Page 5 The Remote Control Before use, slide the battery cover off of the bottom of the remote control and insert two AAA batteries (included) as indicated within the battery compartment. If storing the remote for long periods, place it in a cool dry location, and remove the batteries. Channel Down TV/Video...
- Page 6 Installation and Wiring 1. Before Starting Read these instructions and the precautions carefully. Be sure to disconnect the battery (-) terminal before starting. This is to prevent short cir- cuits during installation. Precautions · This unit is only for cars with negative-ground, 12V electrical systems.
- Page 7 4. The AC3105 Unit: Auxiliary A/V inputs Mounting Screw Holes AC3105 Connectors: Auxiliary Audio/Video Inputs A/V outputs, antenna inputs, power wires, IR receiver input Audio/ Video Antenna Outputs IR Remote Connector and Power Wires AC3105...
- Page 8 5. Wiring Wiring the AC3105 varies with the installation. The AC3105 can be used in two configurations: As an auxiliary source for a monitor or system, using the supplied remote control and IR receiver to control the tuner. In this type of installation, place the IR receiver where the user can see it, so that the remote can operate properly.
- Page 9 Connecting the AC3105 to an audio/video system: Antenna (not included) Connecting the AC3105 to a Rosen A7 system: NOTE: Optional Rosen A7 TV Tuner harness required, RES PN 9100233 TV Antenna (not included) Red = Right-channel audio White = Left-channel audio Yellow = Video Black = IR commands To FM Modulator,...
