Warning!
THE 410X DVD/CD/MP3 PLAYER IS DESIGNED TO ENABLE
VIEWING OF DVD OR CD-VIDEO RECORDINGS ONLY FOR
REAR-SEAT OCCUPANTS.
MOBILE VIDEO PRODUCTS ARE NOT INTENDED FOR VIEW-
ING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION.
SUCH USE MAY DISTRACT THE DRIVER OR INTERFERE WITH
THE DRIVER'S SAFE OPERATION OF THE VEHICLE, AND
THUS RESULT IN SERIOUS INJURY OR DEATH. SUCH USE
MAY ALSO VIOLATE STATE LAW.
ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABIL-
ITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THAT
MAY RESULT FROM ANY IMPROPER OR UNINTENDED USE.
About Installation
Installation of mobile audio and video components requires
experience with a variety of mechanical and electrical proce-
dures. Even though this manual provides general installation
and operation instructions for your new 410X, it does not
show the exact installation methods for your particular
vehicle.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recommend
consulting an authorized Rosen/necvox dealer about profes-
sional installation options.
Table of Contents
Introduction ........................................................................ 2
Care and Maintenance ...................................................... 3
Discs Played by the 410X ................................................. 4
Using the 410X ................................................................... 5
The Remote Control .......................................................... 7
DVD/VCD/CD-Audio Playback .......................................... 8
MP3 Playback on CD-R Discs ......................................... 11
Installation and Wiring ..................................................... 13
Setup ................................................................................. 20
Troubleshooting ............................................................... 27
Specifications ................................................................... 27
Advertisement
Table of Contents
Related Manuals for Rosen 410X
Summary of Contents for Rosen 410X
-
Page 1: Table Of Contents
Installation of mobile audio and video components requires experience with a variety of mechanical and electrical proce- dures. Even though this manual provides general installation and operation instructions for your new 410X, it does not show the exact installation methods for your particular vehicle. -
Page 2: Introduction
410X Note: The 410X is designed to be a component in a full audio/video system. If you have any questions about compatible components, such as monitors, FM modulators, or other audio/video products, please contact your authorized Rosen/necvox dealer. -
Page 3: Care And Maintenance
Liquids and the 410X Keep all liquids, including beverages and cleaning liquids, away from the 410X. Liquids inside the player can damage the electronics, and result in electrical shock or fire. If the unit or the remote control should become wet, turn off all power and contact an authorized Rosen/necvox dealer to have the system inspected. -
Page 4: Discs Played By The 410X
If you still experience problems with playback, you will need to wait for approximately one hour to allow the 410X to warm up, and for the condensation to evaporate. If playback issues continue, please see your authorized Rosen/necvox dealer. -
Page 5: Using The 410X
Any DVD with a Region number other than “1” and “ALL” USING THE 410X In order to operate the 410X, the vehicle ignition key switch must be in the ACC or engine ON position. To prevent the battery from going dead, operate this unit with the engine running, if possible. - Page 6 Audio Forward Title The [ON] button turns the 410X on and off, and is backlit green whenever the ignition switch is in the “accessory” or “run” position. The [POWER] button on the remote can also be used to turn on the unit.
-
Page 7: The Remote Control
The remote control can operate at a 30-degree angle from the front of the unit. If you try to perform an action that is not permitted at the MUTE moment, the 410X displays the following symbol: EJECT TITLE MENU... -
Page 8: Dvd/Vcd/Cd-Audio Playback
Pressing [ ] twice will stop playback and clear the 410X’s memory of the last point played on the disc. Pressing [ at this point will cause the 410X to begin playback from the beginning of the disc. Selecting a Track or Chapter Moving to the Next Track or Chapter Press the [NEXT] button during playback. - Page 9 The Angle Mark appears during scenes that offer multiple viewing angles. (Not all DVD discs support this function.) Use the [ANGLE] button to select from the various angles avail- able. To conceal the Angle Mark, please see the “Setup” section. 410X...
- Page 10 The Parental Control feature allows authorized users to select an upper limit to film ratings that can be played by the 410X. If a DVD is inserted with a film rating higher than that selected, the following screen appears: In order for the film to play, the viewer must select “Yes,” and then the four-digit numeric “password”...
-
Page 11: Mp3 Playback On Cd-R Discs
CDs can be recorded on a CD-R disc, thus allowing longer listening time without having to change CDs. Notes: The 410X cannot play back a disc recorded on a CD-RW unit. Some CDs recorded in CD-R mode may not be usable. Files without MP3 data will not play. - Page 12 “ .MP3” or “.mp3,” the file cannot be played. In addition, if you use upper case and lower case letters (capital and small letters) mixed together for file extensions, normal play may not be possible. 410X...
-
Page 13: Installation And Wiring
3. Installation Requirements 1 Install the unit within 30 degrees of the horizontal plane. Max. 30˚ 2 Use the enclosed screws for installation. Using other screws can cause damage and void the warranty. Chassis Chassis Damage Max. 8 mm (M5 screw) 410X... - Page 14 4. Installing the 410X Installing into the DIN Sleeve First, verify that the opening you will be mounting the 410X into will accommodate the mounting sleeve. Sleeve opening dimensions 7-3/16" (182 mm) Hole Note: Some car models require special mounting kits for proper installation.
- Page 15 DIN Sleeve clip 1 Remove the radio from the dash. Determine that the screw holes on the side of the 410X match up to the factory radio mounting brackets. Pre-threaded holes Pre-threaded holes...
- Page 16 2 Remove the clips on the sides of the 410X. 2-Screw Spring clip Screwdriver 410X 3 Mount the unit to the factory radio brackets, and bolt the brackets to the dashboard. Reassemble the dash. Note: In some cases the factory trim panel may require some slight DIN sleeve spring clip trimming, or there may be a slight gap that requires filling.
- Page 17 Pocket Factory Trim Bezel 5. Wiring the 410X The following pages display wiring diagrams for 410X configu- rations. Read the following precautions before wiring your system. Disconnect the negative battery terminal before making any wiring connections. Be particularly careful where you route wires. Keep them away from the engine, exhaust system, etc.
- Page 18 410X Rear-panel Connections Audio L and R Output (White - L, Red - R) NOTE: Not all Rosen/necvox four-pin connectors use identical wire assignments - ONLY USE THE FOUR-PIN CONNECTOR SUPPLIED WITH THIS UNIT! Black Wire side of - Ground...
- Page 19 410X in a typical system Video Output (Yellow) Optional External IR input Audio L and R Output (White - L, Red - R) Digital output To Radio and Antenna FM Mod Power Supply Module for Monitor Power Harness, Monitor Fuse/...
-
Page 20: Setup
All language options set to English Parental control off, and default password of 3308. Note: The 410X is very flexible. For more advanced setting options, please see the “Setup Options List” at the end of this section. 410X Changing Settings The following sections explain how to customize various features of the 410X. - Page 21 The default “MULTI” will automatically output NTSC video from NTSC discs, and PAL video from PAL discs. Many video monitors can automatically handle either type of video signal. NTSC is the North American standard, and the only type of disc many North American users will encounter. 410X...
- Page 22 Concealing the “Angle Mark” To display or conceal the “angle mark,” which appears during scenes that support the multiple-viewing-angle feature, select GENERAL and ANGLE MARK. 410X Activating Captions and Subtitles To enable or disable captions or subtitles, select GENERAL and CAPTIONS.
- Page 23 Some digital audio processors will require you to select an LPCM output frequency. Selecting an LPCM Output Frequency To select an LPCM output frequency (when a digital audio processor is in use), select AUDIO and LPCM OUTPUT. 410X...
- Page 24 Several language settings can be customized on the 410X. Notes: Not all language settings are supported by all discs. The languages supported by the 410X vary by individual option setting. To change the on-screen display language, select GEN- ERAL and OSD LANG.
- Page 25 To change the soundtrack language, select PREFER- ENCES and AUDIO. To change the subtitle or caption language, select PREF- ERENCES and SUBTITLE. To change the disc menu language, select PREFERENCES and DISC MENU. 410X...
- Page 26 DOWNMIX: LT/RT, STEREO AUDIO SETUP AUDIO OUTPUT: ANALOG, SPDIF/RAW, SPDIF/PCM DYNAMIC: OFF to FULL (eight steps) LPCM OUTPUT: LPCM 48K, LPCM 96K 410X PREFERENCES PAGE AUDIO: ENGLISH, FRENCH, SPANISH, CHINESE, JAPANESE, GERMAN, ITALIAN SUBTITLE: ENGLISH, FRENCH, SPANISH, CHINESE, JAPANESE, GERMAN, ITALIAN, OFF...
-
Page 27: Troubleshooting
Distortion: 0.02% (1 kHz) Digital audio output: SPDIF optical output (IEC 958) * Note: Use of the 410X beyond the safe operating ranges listed can cause temporary or permanent damage to the unit, and such damage may not covered by the manufacturer’s warranty. - Page 28 410X...
